Description
The ABB 3BHB030310R0001 is a fully assembled,water-cooled thyristor power stack incorporating the high-power 5SHY4045L0006 disc thyristor,designed for extreme-duty applications in high-voltage direct current(HVDC)transmission and industrial power conversion.As a critical building block in ABB’s HVDC converter valves and large-scale rectifier systems,this module delivers unmatched current handling and voltage blocking capability with military-grade reliability.
Application Scenarios
At a major HVDC transmission station in northern China,engineers faced recurring failures in aging thyristor stacks used in±500kV converter valves.Frequent thermal stress and voltage transients led to unbalanced current sharing and premature device failure,causing costly outages.The plant upgraded to the ABB 3BHB030310R0001 power stack,integrating the robust 5SHY4045L0006 thyristor.Each 3BHB030310R0001 stack was installed in series within the valve tower,forming part of a 12-pulse converter bridge.The precise pressure contact design,integrated RC snubber network,and optimized water-cooling manifold ensured uniform thermal distribution and voltage sharing across thousands of volts.Within six months,system availability improved from 92%to 99.8%,with zero thyristor-related faults reported—proving the 3BHB030310R0001’s superiority in mission-critical energy infrastructure.
Main Parameters
Parameter Value/Description
Product Model 3BHB030310R0001(Assembly)/5SHY4045L0006(Core Thyristor)
Manufacturer ABB
Product Category High-Power Thyristor Stack/Power Semiconductor
Thyristor Rating(5SHY4045L0006)4000 A(IT(AV)),4500 V(VRRM/VDRM)
Cooling Method Forced deionized water cooling(direct dielectric contact)
Mounting Configuration Press-pack(non-soldered,pressure-contact design)
Insulation Level>50 kV impulse withstand(system-dependent)
RC Snubber Circuit Integrated for dynamic voltage sharing
Mechanical Preload 70–90 kN(ensures low contact resistance and thermal stability)
Operating Temperature-40°C to+85°C(junction),5–45°C(coolant)
Compliance IEC 60700,IEC 61000,ABB internal HVDC standards
Typical Applications HVDC valves,industrial rectifiers,SVC,large motor drives
Technical Principles and Innovative Values
Innovation Point 1:Press-Pack Technology with 5SHY4045L0006 Core
The 5SHY4045L0006 thyristor uses ABB’s proprietary press-pack design—eliminating solder and wire bonds.This allows for superior thermal cycling endurance(>100,000 cycles)and mechanical robustness under high-vibration conditions.When assembled into the 3BHB030310R0001 stack,the uniform pressure contact ensures low on-state voltage and minimal thermal resistance.
Innovation Point 2:Integrated Water-Cooled Manifold
Unlike air-cooled or indirect cooling systems,the 3BHB030310R0001 features a direct water-cooling path through copper electrodes.This achieves thermal resistance as low as 0.005 K/W,enabling continuous 4000A operation with junction temperatures below 100°C—critical for long-term reliability in HVDC valves operating 24/7.
Innovation Point 3:Dynamic Voltage Balancing
Each 3BHB030310R0001 stack includes precision RC snubber networks across the thyristor.These components ensure equal voltage distribution during fast switching transients,preventing overvoltage stress on individual devices—especially vital when hundreds of stacks are connected in series.
Innovation Point 4:Modular&Maintainable Design
The 3BHB030310R0001 is engineered for rapid replacement in HVDC valve halls.Its modular construction allows technicians to remove and replace a single stack without disturbing adjacent units,reducing outage time from days to hours.This plug-and-play capability is a cornerstone of ABB’s HVDC system availability.
Application Cases and Industry Value
In a large steel mill in South Korea,the main rolling mill drive suffered from frequent rectifier failures due to load surges and poor cooling.The original thyristor stacks lacked integrated water cooling and failed every 18–24 months.After retrofitting with ABB 3BHB030310R0001 stacks,each housing a 5SHY4045L0006 thyristor,the rectifier system achieved unprecedented stability.The new stacks handled 4000A continuous current and 10kA surge peaks with minimal temperature rise.Over three years,there were no thyristor replacements needed,and energy efficiency improved by 3.2%due to lower conduction losses.Maintenance teams reported a 70%reduction in power electronics downtime,directly increasing mill throughput and profitability.
Related Product Combination Solutions
ABB 3BHB030311R0001:Companion stack with identical specs,used in parallel or series configurations for higher power systems.
ABB 5SNG 4045:Alternative thyristor variant with similar ratings for legacy systems.
ABB 5SDF 4045:High-power diode stack,often paired with 3BHB030310R0001 in full-wave rectifier bridges.
ABB TCS(Thyristor Control System):Control electronics that provide precise gate triggering to the 5SHY4045L0006.
ABB Water Cooling System(WCS):Deionized water loop with pumps,heat exchangers,and conductivity sensors,essential for 3BHB030310R0001 operation.
ABB 3BSE020899R1:Mounting kit and pressure calibration tool for safe installation of the stack.
ABB 3BHB030310R0002:Upgraded version with enhanced snubber components for higher dv/dt environments.
ABB 5SHX 4545:Next-generation thyristor with improved turn-off characteristics for advanced converter designs.
Installation,Maintenance,and Full-Cycle Support
Installing the ABB 3BHB030310R0001 requires strict adherence to ABB’s HVDC assembly procedures.Prior to installation,verify the mechanical preload using a calibrated torque wrench or hydraulic press(70–90 kN).Ensure the water-cooling manifold is clean and free of debris;flush the system with deionized water before connection.Align the stack precisely within the valve frame and secure all electrical busbars with proper contact compound.After installation,perform insulation resistance and coolant conductivity tests.
Routine maintenance focuses on the cooling system:monitor water conductivity(<1μS/cm),flow rate,and temperature daily.Perform annual visual inspections and infrared thermography to detect hot spots.The 5SHY4045L0006 thyristor inside the 3BHB030310R0001 stack typically lasts 20+years under normal conditions,but periodic electrical testing(e.g.,reverse leakage current)is recommended.We offer full technical support,including on-site commissioning,failure analysis,and lifecycle management.Our team ensures seamless integration and long-term performance of your high-power systems.
Contact us for a customized solution and expert technical c
