Application Scenarios
At a steel mill in South Korea,a sudden drive shutdown during a critical rolling pass caused a$500K loss in damaged material and production delays.Investigation revealed that a failing power supply had caused a voltage dip,leading to a logic reset in the main controller.After replacing the legacy unit with the 3BSE003389R1 SA168 power supply—known for its robust voltage regulation and transient immunity—the drive system achieved 99.98%uptime over the next 18 months.The 3BSE003389R1’s ability to maintain stable 24V output during voltage sags and electrical noise events proved essential in protecting the control ecosystem,turning a chronic failure point into a pillar of reliability.
Parameter
Parameter Value/Description
Product Model 3BSE003389R1
Manufacturer ABB
Product Category Industrial Power Supply Unit(PSU)
Series/Code SA168
Output Voltage 24 V DC(Regulated)
Output Current Up to 10 A(240W typical)
Input Voltage Range 100–240 V AC/120–300 V DC(Universal Input)
Efficiency>90%(High-Efficiency Design)
Protections Overload,Short-Circuit,Overvoltage,Overtemperature
Isolation Reinforced Isolation(Input to Output)
Cooling Method Convection Cooling(Fanless Design)
Operating Temperature-20°C to+70°C(Wide Industrial Range)
MTBF>100,000 hours(High Reliability)
Installation Method DIN Rail Mount(Standard 35mm)
Compliance IEC/EN 62477-1,UL 60950-1,CE,RoHS
Technical Principles and Innovative Values
Innovation Point 1:Universal Input with Wide Range
The 3BSE003389R1 supports both 100–240V AC and 120–300V DC inputs,making it adaptable to global power systems and backup DC supplies(e.g.,battery banks),ideal for offshore and remote installations.
Innovation Point 2:Fanless,Convection-Cooled Design
Unlike many industrial PSUs,the 3BSE003389R1 operates without a fan,eliminating a common failure point and reducing dust ingress.This design enhances reliability in high-temperature,high-dust environments like steel mills and cement plants.
Innovation Point 3:High MTBF&Long Service Life
With an MTBF exceeding 100,000 hours,the 3BSE003389R1 is built with premium-grade electrolytic capacitors and robust circuitry,ensuring long-term operation without degradation—critical for 24/7 industrial processes.
Innovation Point 4:Comprehensive Protection Suite
Integrated protection against overload,short-circuit,overvoltage,and overtemperature ensures fail-safe operation.The unit automatically recovers after fault clearance,minimizing manual intervention.
Application Cases and Industry Value
In a water treatment facility in Australia,frequent power supply failures in the pump drives led to inconsistent flow control and emergency bypass operations.The facility upgraded to the 3BSE003389R1 SA168 across all critical drive cabinets.Over the next two years,there were zero power-related drive faults,even during summer heatwaves when ambient temperatures exceeded 55°C.Maintenance teams praised the unit’s consistent performance and ease of replacement.The 3BSE003389R1’s wide operating temperature range and convection cooling were decisive factors in achieving uninterrupted water supply,directly supporting public health and regulatory compliance.
Related Product Combination Solutions
3BHE041626R0101 PD D405 A101:Main control hub powered by the 3BSE003389R1,requiring stable 24V for real-time processing and communication.
3BHE047217R0101 GD D360 C:High-voltage gate driver board that relies on the 3BSE003389R1 for isolated 24V supply to drive IGBTs safely.
INT-xx Series Boards:I/O interface modules that connect to the 3BSE003389R1 for power,ensuring signal integrity and noise immunity.
RDCU-xx Modules:Drive communication units that depend on clean 24V power from the 3BSE003389R1 for reliable data transmission.
3BHE036348R0103 XZC826A103:Power stack unit where the 3BSE003389R1 powers auxiliary control circuits and sensors.
ABB ACS 6000/8000 Frame:Complete drive cabinet where the 3BSE003389R1 is centrally installed,often in redundant configurations.
24V Battery Backup Systems:Paired with the 3BSE003389R1 to maintain control power during AC outages,ensuring safe drive shutdown.
HIMA F90/F80 Safety Controllers:Often share the same 24V bus,making the 3BSE003389R1 a common power source for both process and safety systems.
Installation,Maintenance,and Full-Cycle Support
The 3BSE003389R1 is designed for quick DIN rail mounting and tool-free terminal connections,enabling fast installation and replacement.Input and output wiring should be separated from high-voltage cables to minimize EMI.When used in redundant configurations(e.g.,parallel or OR-ing diode setups),ensure proper load balancing and fusing.
Routine maintenance includes visual inspection for discoloration or swelling,checking terminal tightness,and monitoring output voltage under load.The 3BSE003389R1’s LED status indicators simplify fault diagnosis—green for normal operation,red for fault.Its modular design allows hot-swap replacement in under 10 minutes,minimizing system downtime.
Our global support network provides 24/7 technical assistance,compatibility checks,and lifecycle management.We offer testing,repair,and firmware updates(if applicable)to extend the service life of the 3BSE003389R1,ensuring long-term operational resilience.
