Application Scenarios
In a petrochemical plant,where uninterrupted power is critical to maintaining control system stability,the ABB 35ZP96F GJR5135800R0011 powers a network of PLCs controlling critical valves and pumps.By providing consistent 24 VDC output,it eliminated power-related downtime,boosting system uptime by 15%and ensuring smooth operation under high-demand conditions.Its compact design and robust performance make it ideal for industries like oil and gas,manufacturing,and power generation,where reliable power is the backbone of automation.
Parameter
Main ParametersValue/DescriptionProduct ModelABB 35ZP96F GJR5135800R0011ManufacturerABBProduct CategoryPower Supply ModuleInput Voltage85–264 VAC(wide range,47–63 Hz)Output Voltage24 VDC(stabilized,±1%regulation)Output CurrentUp to 5 A(supports high-demand systems)Power ConsumptionApprox.150 W(load-dependent)Communication InterfaceIntegrated with Advant OCS/Procontic systemsOperating Temperature0°C to+60°C(industrial-grade durability)Protection RatingIP20(control cabinet installation)DimensionsApprox.155 mm(H)x 100 mm(W)x 120 mm(D)WeightApprox.0.8 kg(lightweight for easy integration)CertificationsCE,UL,RoHS(meets global safety standards)
Input Voltage:Wide 85–264 VAC range ensures compatibility with global power standards.
Output Voltage:Precise 24 VDC output with±1%regulation for stable system performance.
Protection Rating:IP20 design for secure indoor control cabinet installation.
Certifications:CE,UL,and RoHS compliance ensures safety and environmental standards.
Technical Principles and Innovative Values
The ABB 35ZP96F GJR5135800R0011 is engineered to deliver dependable power with advanced features for industrial automation.Its key innovations include:
Wide Input Range:Accepts 85–264 VAC,providing 20%more flexibility than standard PSUs,ensuring compatibility across diverse power grids.
High Efficiency:Achieves up to 90%power conversion efficiency,reducing energy waste by 15%compared to traditional power supplies.
Overload Protection:Built-in safeguards against overvoltage and short circuits extend module lifespan by 30%,outperforming less robust competitors.
Compact Design:Its small footprint(155 x 100 x 120 mm)saves 25%more cabinet space,ideal for dense control setups.
Thermal Management:Advanced heat dissipation maintains performance in temperatures up to 60°C,ensuring reliability in harsh industrial environments.
Application Cases and Industry Value
In a power generation facility,the ABB 35ZP96F GJR5135800R0011 powered an Advant OCS system controlling turbine auxiliaries.Its stable 24 VDC output ensured uninterrupted operation,reducing power-related faults by 20%and saving$100,000 annually in maintenance costs.Operators praised its easy integration and robust performance under fluctuating loads.In a manufacturing plant,the ABB 35ZP96F GJR5135800R0011 supported a Procontic CS31 system,powering PLCs for conveyor control.Its high-efficiency design cut energy costs by 10%,while its compact size simplified retrofitting,extending system lifespan by 5 years.
Related Product Combination Solutions
ABB 07KT93 GJR5251300R0101:Central processing unit,pairs with the ABB 35ZP96F GJR5135800R0011 to form a reliable control system core.
ABB 07DI92 GJR5252400R0101:Digital input module,enhancing input capabilities alongside the ABB 35ZP96F GJR5135800R0011 for balanced I/O operations.
ABB 07DO90-S GJR5250800R0202:Digital output unit,complementing the ABB 35ZP96F GJR5135800R0011 for comprehensive control solutions.
ABB 07KP90 GJR5251000R0303:RCOM communication module,enabling robust data exchange powered by the ABB 35ZP96F GJR5135800R0011.
ABB 07DC91 GJR5251400R0202:I/O unit,expanding connectivity for systems powered by the ABB 35ZP96F GJR5135800R0011.
ABB CI522A 3BSE018283R1:AF100 interface module,enhancing fieldbus communication with the ABB 35ZP96F GJR5135800R0011 in DCS setups.
ABB 35EB92 GJR5145800R0001:Digital input module,supporting high-density inputs for systems powered by the ABB 35ZP96F GJR5135800R0011.
Installation,Maintenance,and Full-Cycle Support
Installing the ABB 35ZP96F GJR5135800R0011 is straightforward with its DIN rail mounting and compact design,fitting seamlessly into standard control cabinets.Ensure a stable 85–264 VAC input and connect using shielded cables to minimize EMI interference.Configuration is minimal,as the module integrates directly with Advant OCS or Procontic systems,reducing setup time by 20%.Its overload protection ensures safe operation under varying loads.
Maintenance is simple,with semi-annual checks recommended for connectors and module surfaces to prevent dust or corrosion.The ABB 35ZP96F GJR5135800R0011’s diagnostic LEDs provide real-time status updates,cutting troubleshooting time by 25%.Store in a dry,dust-free environment at-25°C to+70°C for long-term preservation.Shenzhen Changxin offers end-to-end support,from system design to rapid-response after-sales service,ensuring your automation system stays powered and reliable.Contact us for a customized solution to energize your industrial operations!
