Application Scenario
During a chemical plant expansion project,the site needed to quickly expand I/O modules within the limited control cabinet space.Using the ABB 3BSC840157R1 mounting bracket,engineers were able to quickly insert and remove modules,significantly improving construction efficiency and ensuring system stability over long periods of operation.
Product Specifications
Main Parameters
Description
Model:3BSC840157R1
Manufacturer:ABB
Product Type:Module Mounting Bracket
Applicable Systems:ABB DCS/PLC Systems
Function:Secures modules and provides a reliable electrical and mechanical interface
Mounting Method:DIN-rail mounting/control cabinet mounting
Material:Durable industrial-grade material
Operating Temperature:-20°C to+70°C
Compatibility:Compatible with a variety of ABB control modules
Maintenance:Reusable for easy replacement
Technical Principle and Innovation
Innovation 1:Precision-designed snap-in mechanism ensures secure module installation.
Innovation 2:Optimized contact point layout reduces signal interference and contact resistance.
Innovation 3:Hot-swappable modules simplify maintenance.
Innovation 4:Highly compatible design,compatible with ABB’s diverse range of control modules,reduces spare parts inventory pressure.
Application Cases and Industry Value
Case 1:During a power plant’s boiler control system renovation,the ABB 3BSC840157R1 chassis was used to install the next-generation control modules,enabling rapid system upgrades and reducing downtime.
Case 2:At a paper mill,engineers used this chassis to expand I/O modules,achieving stable operation for over five years with significantly reduced maintenance frequency.
Related Supporting Products
Products commonly used with the ABB 3BSC840157R1 base include:
ABB 3BSE018168R1 control module
ABB 3BHE039203R0101 signal processing module
ABB 3BSE032402R1 power supply unit
ABB 3BSE018293R1 redundant control module
ABB 3BHB003431R0101 drive module
Installation and Maintenance
The ABB 3BSC840157R1 base supports either DIN-rail or rack mounting.Field engineers simply insert the module into the base to secure and connect the electrical connections,making installation simple and efficient.Routine maintenance requires only regular inspection of contact points for dust and oxidation,and cleaning as necessary.Its design allows for quick assembly and disassembly,ensuring module replacement without extended downtime.
In short:
The ABB 3BSC840157R1 chassis is the foundation of the ABB module,providing stability and reliability,making installation and maintenance hassle-free.
