ABB 3HAC4776-1/1

Product introduction of ABB 3HAC4776-1/1,covering its core functions,technical features,and application scenarios:

1.Core functions and positioning

ABB 3HAC4776-1/1 is an industrial automation control module mainly used as a digital input/output expansion module,suitable for signal acquisition and control in industrial control systems.Its core functions include:

Multi channel digital signal processing:supports 10 point digital input and 6-point digital output,compatible with PNP/NPN signal types,suitable for connecting sensors,actuators,and other devices.

High reliability and anti-interference:Through optoelectronic isolation technology(500V AC,1 minute)and electromagnetic isolation design,the stability and anti-interference ability of signal transmission are ensured.

Flexible Expansion:Modular design that can be integrated into ABB control systems(such as AC 800M or robot controllers),supporting signal management in complex industrial scenarios.

2.Technical parameters

Input characteristics

Rated voltage:24V DC(continuous allowable voltage 30V DC).

Logic level range:

Logic”0″:5V DC(1mA).

Logic”1″:15V DC(1mA).

Input delay:4.5ms,supports quick response to requirements.

Signal type:PNP/NPN switch input,compatible with industrial standard signals.

output characteristic

Output type:Relay output,supporting 24V DC or 250V AC voltage.

Rated current:2.0A/point,common terminal rated current 10A.

Mechanical lifespan:10 million cycles(under rated load).

Contact resistance:≤0.2Ω,ensuring low loss signal transmission.

Electrical and environmental adaptability

Bus consumption current:80mA,total power consumption 3W.

Working temperature:not clearly indicated,but meets industrial grade equipment standards(usually-20°C to+60°C).

Environmental anti-interference:Supports shielded cables(up to 500m)or unshielded cables(up to 300m),suitable for complex industrial environments.

3.Application scenarios

Industrial automation control:

Digital signal processing for scenarios such as robot joint control,multi axis linkage of CNC machine tools,and conveyor belt synchronization.

Equipment status monitoring:

Detect the start stop status of the device and sensor trigger signals(such as proximity switches and limit switches)through digital input.

Actuator control:

Drive solenoid valves,relays and other actuators through digital output to achieve automated process control.

4.Core advantages

High compatibility:Supports ABB control systems and third-party devices,compatible with industrial protocols such as Modbus and EtherNet/IP.

Modular design:can be quickly installed in control cabinets or racks,simplifying the system integration process.

Long lifespan and low maintenance:Relay contact design ensures long-term stable operation and reduces failure rates.
