3HNE00009-1-11 DSQC352A Product Details
3HNE00009-1-11 DSQC352A Technical Specifications
Product Model 3HNE00009-1-11
Manufacturer ABB
Product Type Servo Drive
Compatible Systems ABB S4C+/IRC5 Robot Controllers
Number of Controlled Axes:1
Input Voltage:200-240V AC
Output Voltage:Three-phase AC,for servo motors
Operating Temperature:0°C to+55°C
Storage Temperature:-20°C to+70°C
Humidity Range:5%to 95%non-condensing
Mounting Method:Backplane mount,plug-in design
Insulation Grade:High insulation grade
Power Consumption:To be determined,varies with load
3HNE00009-1-11 DSQC352A Product Overview
ABB 3HNE00009-1-11 The DSQC352A servo drive is the core board in ABB’s S4C+and IRC5 robot control systems.Within the robotic automation unit,it’s a key component driving the motors in the robot’s joints.It receives motion commands from the controller and precisely controls the current and voltage of the servo motors,enabling accurate control of each robot axis.Without this 3HNE00009-1-11 module,the robot would be like a skeleton without muscles,unable to perform any movements.
The 3HNE00009-1-11 DSQC352A goes beyond simply providing power;it also provides powerful feedback control and protection capabilities.It monitors the motor’s position,speed,and torque in real time and feeds this information back to the controller,forming a closed-loop control system.This control approach ensures precise and repeatable robot movements,which is crucial for applications requiring extreme precision,such as welding,gluing,and assembly.It also features multiple built-in protection features,including overload,overvoltage,overcurrent,and overtemperature.Once an anomaly is detected,it quickly shuts off the power supply,protecting the expensive servo motor and robot from damage.The ABB 3HNE00009-1-11 is the key to a robot’s power and precision,and the cornerstone for ensuring the robot can complete its tasks efficiently and stably.
Main Features and Advantages
The ABB 3HNE00009-1-11 DSQC352A boasts a wealth of capabilities.First,its high precision and dynamic response are well-known.This driver rapidly responds to controller commands,enabling rapid acceleration,deceleration,and precise positioning of the motor.This rapid response is crucial in robotic motion,especially in applications requiring high speed and precision,such as automotive spot welding lines.Its advanced control algorithm effectively suppresses vibration and ensures the stability of the robot’s end effector.
Second,the 3HNE00009-1-11 boasts powerful diagnostic and protection features.It monitors the operating status of the drive and motor in real time.If problems such as overheating,overload,or encoder failure occur,it immediately sends an alarm to the controller,allowing the operator to quickly locate and address the problem.This proactive fault diagnosis capability significantly improves system maintainability and reduces potential risks.Furthermore,its rugged design withstands the harsh environments of industrial sites,such as temperature fluctuations,vibration,and electromagnetic interference(EMI).Finally,as part of the ABB robot system,the ABB 3HNE00009-1-11 module seamlessly integrates with the IRC5/S4C+controller,ensuring efficient communication and stable data transmission,fully maximizing the performance of the entire system.This seamless integration,unmatched by general-purpose drives,ensures the real-time and accurate robot movements.
The ABB 3HNE00009-1-11 DSQC352A is a fundamental component within the IRC5 and S4C+robot control platforms,engineered for precise and dynamic motion control.This single-axis servo drive is the core of the robot’s motion system,converting electrical power into controlled mechanical movement.A key advantage is its high-speed processing capabilities,which allow it to rapidly interpret commands from the main controller and translate them into precise motor actions.This is crucial for demanding applications high accuracy and repeatability.The 3HNE00009-1-11 is designed to provide robust protection for the connected servo motor,with built-in features for overcurrent,overvoltage,and over-temperature detection.This proactive approach to fault prevention safeguards expensive hardware and minimizes downtime.Its compact,card-based form factor is optimized for integration into the robot controller cabinet,simplifying installation and maintenance.The module’s robust construction ensures its durability in harsh industrial environments,withstanding common issues like vibration and electrical noise.Its seamless integration with ABB’s control systems ensure a high-bandwidth,low-latency communication link,essential for real-time control and dynamic performance.
Applications
The 3HNE00009-1-11 DSQC352A servo drive is the”core engine”of robotic automation,found in nearly every industry using ABB S4C+or IRC5 robots.In automotive manufacturing,it controls the movement of every joint in welding,painting,and assembly robots,ensuring precise and accurate spot welds and coats of paint.In material handling and palletizing systems,it drives every robot axis,enabling fast and stable grasping and placement of materials,improving logistics efficiency.
In welding and cutting,the ABB 3HNE00009-1-11 DSQC352A is widely used to control the posture and trajectory of robot end-of-line tools,ensuring the accuracy and consistency of welds and cutting paths.In machine tool loading and unloading scenarios,it drives the robot arm,enabling rapid grasping and placement of workpieces,thus enabling machine tool automation.In short,wherever high-precision,high-dynamic robot motion is required,the 3HNE00009-1-11 module plays a crucial role,ensuring efficient,safe,and stable automated production.
Selection Guide/Purchasing Recommendations
Followers,choosing this precious 3HNE00009-1-11 is no small feat.First,confirm whether your robot controller is an S4C+or IRC5 series.This module is dedicated to your system;installing it on another manufacturer’s system will be useless.Second,carefully verify the model number,including the version number”-1-11,”to ensure it matches the old module you are replacing to avoid compatibility issues.Finally,and most importantly,source it from a reliable source.Core industrial control spare parts like these are a mixed bag on the market,and unidentified sources can lead to unstable performance at best,and even damage the entire robot.As a veteran of the 3HNE00009-1-11,we can provide you with genuine,original products.We not only sell products,but also provide technical support and after-sales service,so you can buy with confidence and use with peace of mind.
Related Products
ABB 3HNE00009-1-2:This servo drive is from the same series.It may be a different version or have slightly different functions.It is a drop-in replacement for the 3HNE00009-1-11.
ABB 3HNE00009-1-13:This servo drive is from the same series.It is typically used to control different axes and works with the 3HNE00009-1-11 in the same robot controller.
ABB 3HAC14550-1:The power supply unit of the robot controller provides stable power to all modules,including the 3HNE00009-1-11.
The ABB 3HAC025779-001 digital I/O module works with the 3HNE00009-1-11 in the same control cabinet to control external devices.
The ABB 3HAC023456-001 main computer board is the”brain”of the robot system,responsible for sending motion commands to the 3HNE00009-1-11.
Installation and Maintenance
Pre-installation Preparation:Before installing the 3HNE00009-1-11 module,ensure that the robot control cabinet is powered off and all related power supplies are released.Safety is paramount and must be taken seriously.Carefully inspect the module slot to ensure it is free of foreign objects and damage.When installing the 3HNE00009-1-11,align the guide rails with the slot and insert it slowly and steadily until you hear a click,indicating the module is locked into place.Because the ABB IRC5 system supports hot-swappable operation,please refer to the system manual to confirm the operating procedures and take precautions against electrostatic discharge.
Maintenance Recommendations:The 3HNE00009-1-11 module itself requires minimal maintenance.Daily maintenance primarily involves keeping its operating environment clean.Regularly clean the interior of the control cabinet with a vacuum cleaner or oil-free compressed air to prevent dust accumulation that affects heat dissipation.Check the module’s indicator light.If a fault light illuminates,promptly investigate the cause and address the issue according to the controller’s alarm.If the module itself is faulty,contact a professional technician for a replacement.Never disassemble it yourself to avoid secondary damage or electric shock.
Product Guarantee
Our commitment to the ABB 3HNE00009-1-11 is unwavering.We understand that the quality of industrial spare parts is the lifeblood of your production line.Every 3HNE00009-1-11 undergoes rigorous incoming inspection to ensure it is genuine and performs flawlessly.We provide more than just a product;we offer peace of mind.From the moment you place your order,to delivery,and to ongoing technical support,we’ll provide comprehensive support.Our technical team at www.cnplcdcs.com are veterans with years of experience.Any problem is just a phone call or a WeChat message away,and we can quickly resolve it.Choosing Shenzhen Changxin means choosing reliability,expertise,and a long-term partnership.
Our commitment to the ABB 3HNE00009-1-11 and all our industrial automation products is unwavering.We understand that in the world of control systems,reliability is not just a feature—it’s a necessity.We stand by the quality of the 3HNE00009-1-11 and offer a comprehensive product guarantee that gives our clients peace of mind.Every unit undergoes rigorous quality inspection to ensure it meets original manufacturer specifications and performs flawlessly in demanding industrial environments.Our promise extends beyond the sale;it includes a dedicated after-sales service and technical support system staffed by seasoned experts.We provide a seamless experience from initial inquiry to final implementation,offering expert advice and rapid issue resolution.
