ABB DSTD 108P Technical Specifications
Product Model: DSTD 108P
Manufacturer: ABB
Product Type: Digital Input Module
Part Number: 3BSE018333R1
Number of Channels: 8 relay input channels
Input Voltage: 24-250V AC/DC
Isolation Type: Relay isolation, provides high voltage protection
Compatible Systems: ABB Advant Controller 400 Series
Physical Dimensions: 99mm x 234mm x 36mm
Mounting Method: Slot-mounted in an Advant rack
Operating Temperature: -10°C to +55°C
Protection Rating: IP20
Wiring Method: Screw Terminals
ABB DSTD 108P Product Overview
If you maintain ABB’s Advant Controller 400 series control systems in the field, you’re undoubtedly familiar with the ABB DSTD 108P module. Its official part number is 3BSE018333R1. It’s not a CPU, but a specialized input/output (I/O) module. Think of it as the “sensory” system of the entire control system, specifically responsible for converting physical signals from the field into digital information that the controller can understand. Through this module, the controller can monitor the operating status of equipment in real time, such as whether a valve is open or closed, whether a motor is started or stopped, or whether an emergency stop button has been pressed.
The ABB DSTD 108P module is designed with the practical needs of industrial sites in mind. It provides eight independent relay input channels, each capable of accepting a wide range of voltage signals, from 24VDC to 250VAC. This wide voltage support makes it compatible with a wide variety of field devices. More importantly, its relay isolation design provides strong electrical protection for the module and controller, effectively preventing high field voltages from impacting sensitive electronic components, thereby ensuring the stability and safety of the entire control system. This robust design makes the DSTD 108P an indispensable component in many applications requiring the highest levels of reliability and safety.
Key Features and Advantages
The ABB DSTD 108P’s key strengths lie in its wide input voltage range and high channel density. Its eight digital input channels can handle signals from 24-250V AC/DC, making it compatible with virtually all common industrial switching devices, from low-voltage sensors to high-voltage contactor feedback. This not only simplifies system design but also reduces spare parts management complexity.
Secondly, its high electrical isolation and protection capabilities are significant advantages. The ABB DSTD 108P utilizes relay isolation technology, achieving complete electrical isolation between field signals and the module’s internal logic circuitry. This effectively isolates field devices from potential surge voltages and electrical noise, significantly enhancing the module’s immunity to interference and protecting the main controller from external electrical damage. This highly reliable design ensures the ABB DSTD 108P operates stably in a variety of harsh industrial environments. In addition, its compact design and convenient screw-type terminal connections make installation and maintenance extremely easy, enabling rapid troubleshooting and ensuring high system availability.
The ABB DSTD 108P (part number 3BSE018333R1) is a high-performance digital input module, a core component of the legacy ABB Advant Controller 400 series. Its primary function is to serve as a reliable interface between the control system and the field devices, capturing on/off status signals from a wide range of industrial equipment. The DSTD 108P features 8 galvanically isolated relay input channels, which can accept a broad voltage from 24 to 250V AC/DC. This versatility is a major advantage, as it simplifies system design and reduces the need for multiple module types. The relay-based isolation is a key feature, providing robust protection against voltage spikes and electrical noise from the field, thereby safeguarding the sensitive electronics of the controller. This durable and reliable design makes the ABB DSTD 108P an indispensable component in mission-critical applications where high availability and system integrity are paramount.
Application areas
ABB DSTD The 108P is primarily used in industrial automation scenarios where reliability and compatibility of digital signal acquisition are critical, particularly in the following areas:
Power Industry: In power plant switchgear, circuit breakers, protective relays, and other equipment, it collects device status and alarm signals to ensure safe and stable operation of the power system.
Water Treatment and Environmental Engineering: In pumping stations and sewage treatment plants, it monitors the on/off status of pumps, valves, level switches, and other equipment, enabling automated control and remote monitoring.
Manufacturing and Process Control: In various production lines and automated equipment, it collects signals from devices such as pushbuttons, limit switches, and photoelectric sensors to achieve precise control and monitoring of production processes.
Petrochemical and Chemical Industry: In various control cabinets and field instruments, it receives the on/off status and alarm signals of various process equipment to ensure safety and continuity of production processes.
Related Products
ABB DSTK 108: A terminal block specifically designed for the DSTD 108P, used to connect field signal cables and is used in conjunction with it.
ABB DSDO 115A: Another digital output module from the same series, corresponding to the DSTD 108P, used to send control signals to the field.
ABB DSDI 110A: Another digital input module, which may differ in terms of channel number or input voltage range.
ABB DSTD 108S: A module from the same series but different models, which may have slightly different functions or technical specifications.
ABB CP400 Series: The CPU controller series compatible with the DSTD 108P, such as the CP435T, is used to execute control logic.
Installation and Maintenance
Pre-installation Preparation: Before installing the ABB DSTD 108P, the first step is to ensure that the entire system is completely powered off. Then, locate the correct slot on the Advant rack, ensure that the pins on the module align with the socket, and firmly push it in until it locks securely. When wiring, be sure to use the designated terminal blocks and strictly follow the wiring diagram to ensure that the power and signal cables are connected correctly.
Maintenance Recommendations: The ABB DSTD 108P is a very durable device, requiring minimal attention in most situations. However, if the input signal is abnormal, first check the field equipment and terminal blocks for proper function and any loose screws. Because it contains sophisticated electronic components, damage is usually irreparable and requires complete replacement. If spare parts are difficult to find, contact us immediately. We have a large inventory of DSTD 108Ps available to quickly resolve your downtime.
Product Guarantee
Brother, choose the ABB DSTD 108P from our Shenzhen Changxin branch for absolute peace of mind. We understand that the quality of these discontinued legacy spare parts is crucial to the stable operation of your entire production line, so we treat every DSTD 108P as a precious treasure. Every board undergoes rigorous inspection and performance testing by our experienced engineers to ensure it’s ready to go and rock-solid. We provide more than just a board; we guarantee the stable operation of your system. If you have any technical questions, feel free to contact us. We’re your reliable support!
