ABB LTC745A101 3BHE039905R0101

The ABB LTC745A101,with the part number 3BHE039905R0101,is a specialized power master board used in ABB’s medium-voltage drives and power electronics.It’s a critical component that controls the voltage drive crowbar circuit,which is an overvoltage protection mechanism.

Key Features and Functionality⚙️

This board’s function is to serve as a safety and control module for the power section of a drive.It’s a complex circuit board that monitors and protects the drive’s power semiconductors from damage caused by grid transients or other overvoltage events.

Product Type:Power Master Board/Voltage Drive Crowbar Circuit Board.

Part Number:3BHE039905R0101.

Model Name:LTC745A101.

Manufacturer:ABB.

Function:The board’s main role is to manage a crowbar circuit.A crowbar is an electrical circuit that’s designed to protect a system from overvoltage by shorting out the power supply when the voltage exceeds a predefined threshold.This board,specifically,is a control unit that activates the crowbar when a high-voltage event is detected,such as a grid voltage loss or a short circuit.

Compatibility:This board is used in various ABB drive and converter platforms that require robust overvoltage protection.Some sources suggest it’s part of systems that support grid-stabilization functions.

Context in a Drive System

In a medium-voltage drive,the power electronics are highly sensitive to voltage spikes and other grid disturbances.The LTC745A101 board is a crucial safety component that monitors the grid’s voltage.If an anomaly is detected,it will engage a high-power resistor via the crowbar circuit to safely dissipate the excess energy.This action protects the drive’s main components,such as the IGCTs or IGBTs,from permanent damage.Without such a protection circuit,a single grid transient could lead to a catastrophic failure of the entire drive system.The board’s role is therefore vital for the reliability and safety of the power converter.

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 ABB GRID BREAKER UNIT GBU72 3BHE055094R0002 3BHE031197R0001 3BHB030310R0001 In stock!!! Interested parties please inquire
