Application Scenarios
In a steel manufacturing plant,the ABB UN0802A-P HIER452076R1 was integrated into an ABB Advant OCS system to manage sensor signals for a rolling mill.The facility previously faced signal disruptions due to electromagnetic interference,causing 15%downtime.By deploying the UN0802A-P HIER452076R1,the plant reduced signal errors by 20%and improved operational uptime by 18%,addressing critical pain points like unreliable signal transmission and boosting production efficiency.
Parameter
Main ParametersValue/DescriptionProduct ModelUN0802A-P HIER452076R1ManufacturerABBProduct CategoryPCB Circuit BoardInput Voltage24V DC(±10%,stable power supply)Signal Channels8-16 configurable digital I/O channelsResponse Time<10ms(fast signal processing)Isolation Voltage500V AC(channel-to-channel and channel-to-ground isolation)Operating Temperature-25°C to+70°C(suitable for harsh industrial conditions)DimensionsApprox.95 x 75 x 12.5 mm(compact for control cabinet integration)WeightApprox.0.15 kg(lightweight for easy installation)Communication ProtocolABB Advant OCS bus(seamless system integration)CertificationsCE,UL,IEC 61131-2(global safety compliance)
Technical Principles and Innovative Values
Innovation Point 1:The ABB UN0802A-P HIER452076R1 employs advanced signal conditioning,delivering 20%faster response times(<10ms)than standard PCBs,ensuring real-time control in dynamic processes.
Innovation Point 2:Its 500V AC galvanic isolation reduces electromagnetic interference by 30%,outperforming typical boards in noisy environments like metallurgical plants.
Innovation Point 3:The UN0802A-P HIER452076R1 features a compact design,saving 25%of cabinet space compared to traditional control boards,ideal for space-constrained setups.
Innovation Point 4:Integrated LED diagnostics enable 30%faster troubleshooting,minimizing downtime in critical applications,such as power generation.
Application Cases and Industry Value
In a chemical processing facility,the ABB UN0802A-P HIER452076R1 was used in an Advant OCS system to handle valve control signals.Previous boards suffered from frequent failures due to high temperatures,leading to$100,000 in annual maintenance costs.The UN0802A-P HIER452076R1’s robust design and wide operating temperature range(-25°C to+70°C)reduced failures by 25%and maintenance costs by 20%,enhancing process reliability and safety.
In an oil and gas refinery,the UN0802A-P HIER452076R1 managed sensor inputs for pipeline monitoring.Its high isolation and fast response time improved signal accuracy by 15%,reducing false alarms and boosting throughput by 12%.Operators valued its durability in corrosive environments,underscoring its critical role in ensuring operational continuity.
Related Product Combination Solutions
TU830V1 3BSE013234R1:Terminal unit,ensures secure connections for the UN0802A-P HIER452076R1.
CI854AK01 3BSE030220R1:PROFIBUS-DP module,enhances communication with the UN0802A-P HIER452076R1.
DO810 3BSE008510R1:Digital output module,complements the UN0802A-P HIER452076R1 for output processing.
AI810 3BSE008516R1:Analog input module,pairs with the UN0802A-P HIER452076R1 for mixed-signal applications.
SDCS-POW-4 3ADT315100R1001:Power supply module,provides stable 24V DC for the UN0802A-P HIER452076R1.
TB521 3BSE018167R1:Terminal block,improves wiring reliability with the UN0802A-P HIER452076R1.
UPC090AE01 HIEE300661R1:Digital input module,extends input capacity alongside the UN0802A-P HIER452076R1.
RLM01 3BDZ000398R1:PROFIBUS redundancy module,boosts communication stability for the UN0802A-P HIER452076R1.
Installation,Maintenance,and Full-Cycle Support
Installing the ABB UN0802A-P HIER452076R1 is a breeze:power off the DCS,ground the control cabinet to mitigate EMI,and secure the PCB to a DIN rail or module slot.Connect 24V DC power and 0.14-1.5 mm²shielded cables,then configure via ABB’s Control Builder software,completing setup in under 20 minutes.The compact design(95 x 75 x 12.5 mm)ensures seamless integration into tight spaces.
Maintenance is minimal:inspect the UN0802A-P HIER452076R1 quarterly for dust and verify connections.Its LED diagnostics accelerate fault detection by 30%,and an MTBF exceeding 100,000 hours reduces maintenance frequency by 20%.Calibrate biennially to maintain signal precision.Store spares in a dry,ESD-safe environment.Our 24/7 global support team offers remote diagnostics,on-site service,and tailored training,ensuring optimal performance throughout the PCB’s lifecycle.
