Application Scenarios:
At an automotive stamping plant in Michigan, inconsistent press tonnage was causing part dimensional drift during high-speed cycles. Engineers traced the issue to aging solenoids on the 4WRTE16 valves controlling the main cylinder. After replacing them with genuine 2263117 coils, the system regained ±0.5% flow repeatability thanks to the solenoid’s tight magnetic hysteresis (<3%) and thermal stability. The integrated M12 connector and IP65-rated housing also eliminated intermittent faults previously caused by coolant mist ingress. This intervention restored production quality within hours—highlighting how the 2263117 serves as the critical electromechanical link between digital commands and physical force.
Main Parameters Value/Description
Product Model 2263117
Manufacturer Bosch Rexroth
Product Category Proportional Solenoid Coil (for 4WRTE valves)
Nominal Voltage 24 V DC
Coil Resistance ～32 Ω (at 20°C)
Power Consumption ～18 W (continuous)
Control Type Analog current-controlled (typically 0–1.2 A or ±1.2 A for differential models)
Connector Type Integrated M12 4-pin (IEC 60529 compliant)
Protection Rating IP65 (dust-tight and protected against water jets)
Operating Temperature –20°C to +80°C (ambient)
Compatibility 4WRTE10. 4WRTE16. and select 4WRDE proportional valves
Hysteresis <3% (typical, with temperature-compensated design)
Duty Cycle Continuous (S1)
Certifications CE, UL recognized component
Technical Principles and Innovative Values:
• Innovation Point 1: The 2263117 features a temperature-compensated winding design that maintains consistent force-current characteristics across wide thermal swings—critical for maintaining valve linearity in hot forging or plastic extrusion lines.
• Innovation Point 2: Its low-inductance architecture enables rapid current response (<10 ms rise time), allowing high-frequency PWM control without signal lag—ideal for dynamic applications like active vibration damping or robotic hydraulics. • Innovation Point 3: The molded IP65 housing with integrated M12 connector eliminates loose wires and external junction boxes, reducing installation errors and improving reliability in washdown or outdoor environments. • Innovation Point 4: Precision-machined pole pieces and guided armature minimize mechanical play, delivering sub-micron spool positioning repeatability when paired with Rexroth’s valve electronics (e.g., VT-MSPA control cards). Application Cases and Industry Value: A European manufacturer of blow-molding machines integrated the 2263117 into their clamp and ejector circuits to replace generic aftermarket solenoids that failed every 6–8 months. After switching to genuine 2263117 units, mean time between failures (MTBF) increased to over 36 months—even under 24/7 operation with 200+ cycles/hour. Machine builders also leveraged the solenoid’s linear response to implement closed-loop cavity pressure control, reducing cycle time by 12%. Customers reported fewer scrap parts and lower service costs, proving that authentic 2263117 coils are not just components—but enablers of process excellence. Related Product Combination Solutions: • 4WRTE10-1X/…: Proportional directional valve body directly actuated by the 2263117 solenoid. • VT-MSPA1-1: Rexroth amplifier card that provides precise current control and diagnostics for the 2263117. • 2263118: Dual-coil version (for differential control) used in 4WRTE valves requiring two 2263117-equivalent actuators. • R900249001: Genuine Rexroth seal kit for 4WRTE valves—recommended during 2263117 replacement to ensure leak-free performance. • M12 Extension Cable (0821100001): Shielded cable for extending 2263117 connections in large machinery. • Sytronix FvP: Rexroth’s hybrid servo-hydraulic system that relies on 2263117-class solenoids for energy-efficient motion. • IndraDrive HCS: Motion controller that outputs optimized PWM signals to drive 2263117 coils with minimal heat generation. • 2263120: Spare mounting nut and washer kit for secure 2263117 installation on valve bodies. Installation, Maintenance, and Full-Cycle Support: Installing the 2263117 requires aligning the solenoid over the valve’s armature pin and securing it with the provided hex nut (torque: 35–40 Nm). Ensure the M12 connector is fully seated and locked to maintain IP65 integrity. Avoid bending or straining the connector cable during machine reassembly. While the 2263117 is maintenance-free, periodic inspection for oil contamination around the base and connector corrosion is recommended in harsh environments. If resistance deviates >10% from 32 Ω or leakage current exceeds 1 mA, replacement is advised.
Every 2263117 we supply undergoes functional validation—including inductance sweep, insulation resistance (>100 MΩ), and connector integrity testing—to ensure OEM-equivalent performance. We also provide cross-reference support for obsolete part numbers and compatibility verification with third-party amplifiers. Our technical team can assist with troubleshooting valve instability, overheating, or signal noise issues related to solenoid performance.
Contact us for a customized solution—whether you need a single 2263117 for emergency press repair or bulk procurement for OEM production. Keep your hydraulic systems responsive, reliable, and ready for precision.
