Product Overview
The ABB DSQC611 3HAC13389-2-06 NSNP is a high-performance digital input/output(I/O)module designed specifically for ABB’s industrial robot controllers,particularly the IRC5 platform.As a critical component in robot automation systems,it serves as the interface between the robot controller and various peripheral devices,such as sensors,grippers,and actuators,enabling the exchange of digital signals that drive robot operations.
ABB DSQC611 3HAC13389-2-06 NSNP is engineered to handle the demands of industrial environments,providing reliable signal transmission even in noisy or vibration-prone settings.Its design ensures seamless integration with ABB’s robot ecosystem,making it a go-to choice for applications where precise control of I/O signals is essential,such as in automotive assembly,material handling,and packaging.
In the IRC5 controller setup,ABB DSQC611 3HAC13389-2-06 NSNP expands the controller’s I/O capabilities,allowing it to manage multiple peripheral devices simultaneously.This flexibility is key in complex automation cells where robots interact with conveyors,vision systems,and other equipment,ensuring coordinated and efficient operation.
Technical Specifications
Parameter Name
Parameter Value
Product Model
ABB DSQC611 3HAC13389-2-06 NSNP
Manufacturer
ABB
Product Type
Digital Input/Output Module
Compatible Controller
ABB IRC5 Robot Controller
Input Channels
16 digital inputs
Output Channels
16 digital outputs
Input Voltage
24V DC
Output Voltage
24V DC
Output Current
0.5A per channel(max)
Power Consumption
Max 10W
Operating Temperature
0°C to 45°C
Storage Temperature
-25°C to 70°C
Relative Humidity
5%to 95%(non-condensing)
Dimensions(HxWxD)
110mm×70mm×50mm
Weight
Approximately 0.3kg
Mounting Type
DIN rail or panel mount
Main Features and Advantages
Versatile I/O Capacity:With 16 digital inputs and 16 digital outputs,ABB DSQC611 3HAC13389-2-06 NSNP provides ample capacity to connect a wide range of peripheral devices.This allows robot systems to interact with multiple sensors(e.g.,proximity switches,photoelectric sensors)and actuators(e.g.,gripper solenoids,conveyor motors)simultaneously,making it ideal for complex automation tasks like assembly lines with multiple workstations.
Robust Signal Integrity:ABB DSQC611 3HAC13389-2-06 NSNP is designed to maintain signal integrity in harsh industrial environments.It features built-in protection against electromagnetic interference(EMI)and voltage spikes,ensuring that digital signals from sensors are accurately transmitted to the controller and commands to actuators are executed without error.This reliability is crucial in automotive plants,where machinery noise can disrupt unprotected signals.
Seamless IRC5 Integration:As a native component of ABB’s IRC5 ecosystem,ABB DSQC611 3HAC13389-2-06 NSNP offers plug-and-play compatibility,reducing setup time and minimizing integration issues.It is fully supported by ABB’s RobotWare software,allowing technicians to configure I/O channels,monitor signal status,and troubleshoot issues through a user-friendly interface—simplifying both initial setup and ongoing maintenance.
Compact and Durable Design:The module’s compact size(110mm×70mm×50mm)makes it easy to install in space-constrained control cabinets,while its rugged construction ensures long-term performance in temperatures ranging from 0°C to 45°C.This durability reduces the need for frequent replacements,lowering maintenance costs in high-throughput facilities.
Application Field
The ABB DSQC611 3HAC13389-2-06 NSNP is widely used in automotive manufacturing,where it enables robots to interact with assembly line equipment.For example,in car body welding cells,it connects the robot controller to proximity sensors that detect part presence,ensuring the robot only initiates welding when the part is correctly positioned.Its 16 input channels can monitor multiple sensors simultaneously,while the 16 outputs control weld guns,clamps,and conveyor stops—coordinating every step of the process.
In material handling applications,ABB DSQC611 3HAC13389-2-06 NSNP allows robots to communicate with grippers and conveyor systems.It receives signals from gripper sensors indicating whether a part is securely held,and sends commands to release or activate the gripper,as well as to start/stop conveyors.This ensures smooth transfer of goods in warehouses or distribution centers,where timing and precision prevent damage to products.
Packaging facilities also rely on ABB DSQC611 3HAC13389-2-06 NSNP to coordinate robot operations with packaging machinery.It connects to vision systems that inspect package alignment and triggers the robot to adjust its placement accordingly,while controlling sealing devices and label applicators.Its ability to handle multiple I/O signals simultaneously ensures that packaging lines run at optimal speeds with minimal errors.
Additionally,in electronics manufacturing,the module supports robots in handling small components by interfacing with delicate sensors that detect part orientation,ensuring accurate placement on circuit boards.
Related Products
ABB DSQC651 3HAC025909-001:A complementary I/O module with extended channel capacity,often used alongside ABB DSQC611 3HAC13389-2-06 NSNP in large automation cells.
ABB IRC5 Controller:The central robot controller that works with ABB DSQC611 3HAC13389-2-06 NSNP to process I/O signals and execute robot movements.
ABB DSQC679 3HAC028357-001:A communication module that,when paired with ABB DSQC611 3HAC13389-2-06 NSNP,enhances data transfer between the controller and I/O devices.
ABB RobotWare Software:The programming platform for IRC5 controllers,which configures and monitors ABB DSQC611 3HAC13389-2-06 NSNP to optimize I/O signal management.
ABB DSQC1031 3HAC050991-001:A teach pendant interface module that allows operators to test and troubleshoot ABB DSQC611 3HAC13389-2-06 NSNP I/O signals manually.
Installation and Maintenance
Pre-installation preparation:Before installing ABB DSQC611 3HAC13389-2-06 NSNP,ensure the IRC5 controller is powered off to avoid electrical damage.Verify that the mounting surface(DIN rail or panel)is clean and secure,as loose mounting can cause vibration-related signal issues.Check the module’s connectors for dirt or corrosion,and clean them with a dry cloth if necessary—contaminants can disrupt signal transmission.Refer to the controller’s wiring diagram to correctly connect input/output devices to ABB DSQC611 3HAC13389-2-06 NSNP,ensuring polarities match to prevent short circuits.
Maintenance recommendations:Regularly inspect the connections of ABB DSQC611 3HAC13389-2-06 NSNP during routine checks,as industrial vibration can loosen terminal screws over time.Use ABB’s RobotStudio software to monitor I/O signal status periodically,identifying stuck or erratic signals that may indicate a failing channel.Keep the module free of dust and debris,as accumulation can block cooling vents and cause overheating.If a channel fails,isolate the module from power before replacing it,and test the new unit with a signal generator to confirm functionality.Avoid exposing ABB DSQC611 3HAC13389-2-06 NSNP to temperatures beyond its operating range,as extreme heat or cold can degrade internal components.
Product Guarantee
We guarantee that ABB DSQC611 3HAC13389-2-06 NSNP is a genuine ABB product,rigorously tested to meet the manufacturer’s quality and performance standards.Each unit comes with a 12-month warranty covering defects in materials and workmanship,ensuring reliable operation in your robot system.Our technical support team is available to assist with installation guidance,wiring configuration,and troubleshooting,helping you integrate ABB DSQC611 3HAC13389-2-06 NSNP seamlessly into your automation setup.In the event of a malfunction,we offer prompt replacement or repair services to minimize downtime,reflecting our commitment to providing dependable industrial automation components.
