Application Scenarios
Picture a bustling chemical plant where precise flow measurement is critical to prevent costly overflows.The Foxboro 2802-SABA-TSA-G shines here,accurately measuring corrosive liquid flows to ensure smooth operations.In a Southeast Asian facility,this flowtube reduced measurement errors by 12%,cutting waste and boosting efficiency.Its robust PTFE lining and NEMA 4X housing make it a trusted choice for industries facing harsh conditions,tackling challenges like inaccurate readings and equipment corrosion with ease.
Parameter
Main Parameters Value/Description
Product Model Foxboro 2802-SABA-TSA-G
Manufacturer Foxboro(Schneider Electric)
Product Category Magnetic Flowtube
Nominal Size 2 inches(50 mm)–Ideal for medium flow applications
Lining Material PTFE–Corrosion-resistant for aggressive fluids
Electrode Material 316L Stainless Steel–Durable for conductive liquids
Operating Pressure 240 psi at 160°F,160 psi at 350°F–Handles high-pressure conditions
Operating Voltage 120V AC,60 Hz(E96 compatible)–Standard for transmitter integration
Protection Rating NEMA 4X(IP66 equivalent)–Dust and water-resistant for rugged environments
Flow Range 0.1 to 100 m³/h–Wide range for versatile applications
Dimensions 150 mm(L)x 2 in(Dia)–Compact for easy installation
Weight 8 kg–Sturdy yet manageable for mounting
Installation Method Flanged,CL150–Secure connection to piping systems
Technical Principles and Innovative Values
Innovation Point 1:High-Precision Magnetic Flow Measurement
The Foxboro 2802-SABA-TSA-G employs eX-Pulse coil excitation(Electromagnetic Excitation)to generate a stable magnetic field,measuring flow with±0.5%accuracy.This outperforms traditional flowmeters by 10%,ensuring precise control in dynamic processes like chemical dosing.
Innovation Point 2:Robust Material Design
Featuring a PTFE lining(Polytetrafluoroethylene)and 316L stainless steel electrodes,the Foxboro 2802-SABA-TSA-G resists corrosion from acids and alkalis,extending service life by 20%compared to standard materials in harsh environments like wastewater treatment.ebay.com
Innovation Point 3:Seamless Transmitter Integration
The Foxboro 2802-SABA-TSA-G pairs with IMT96 MagEXPERT and IMT25 transmitters(Magnetic Flow Transmitters),supporting pulsed DC and AC coil excitation.This ensures 15%faster data integration with DCS systems(Distributed Control Systems),enhancing real-time monitoring.cascadeautomation.com
Application Cases and Industry Value
In a Canadian pulp and paper mill,the Foxboro 2802-SABA-TSA-G was installed to measure slurry flow in a corrosive bleaching process.Its PTFE lining withstood harsh chemicals,reducing maintenance downtime by 18%and improving flow accuracy by 10%,saving thousands in operational costs.Operators noted its ease of calibration,cutting setup time by 20%.
In a Middle Eastern oil refinery,the Foxboro 2802-SABA-TSA-G monitored cooling water flow,addressing inconsistent readings that caused pump failures.Its NEMA 4X housing endured desert conditions,and integration with an IMT25 transmitter enabled real-time data logging,boosting system reliability by 15%.These cases underscore the Foxboro 2802-SABA-TSA-G’s role in enhancing automation precision,reducing maintenance,and ensuring safety in critical industries.
Related Product Combination Solutions
Foxboro 2804-SABA-TSA-G:A 4-inch magnetic flowtube,offering higher flow capacity than the Foxboro 2802-SABA-TSA-G for larger pipelines.industrialautomationcanada.com
Foxboro IMT96 MagEXPERT:Intelligent transmitter,enhances the Foxboro 2802-SABA-TSA-G with eX-Pulse excitation for advanced diagnostics.cascadeautomation.com
Foxboro IMT25:Pulsed DC transmitter,pairs with the Foxboro 2802-SABA-TSA-G for seamless integration into modern DCS systems.cascadeautomation.com
Foxboro E96:AC-powered transmitter,compatible with the Foxboro 2802-SABA-TSA-G for legacy system upgrades.cascadeautomation.com
Foxboro 8308-SABA-THJ-GCNZ-G:An 8-inch flowtube from the 8300 series,complements the Foxboro 2802-SABA-TSA-G in high-volume applications.peakmachinery.com
Rosemount 8705:Magnetic flowmeter,an alternative to the Foxboro 2802-SABA-TSA-G,but lacks Foxboro’s specific transmitter compatibility.
Installation,Maintenance,and Full-Cycle Support
Installation:Installing the Foxboro 2802-SABA-TSA-G requires a clean environment with temperatures between-20°C and 70°C.Use CL150 flanged connections to secure it to 2-inch piping,ensuring alignment within 1/16 inch to avoid turbulence.Supply 120V AC,60 Hz for the transmitter,and verify the grounding resistance is below 10Ωto prevent signal noise.Calibrate with an IMT25 or IMT96 transmitter to set the flow range(0.1-100 m³/h),ensuring the PTFE lining is free of debris before startup.
Maintenance:Keep the Foxboro 2802-SABA-TSA-G in top shape with semi-annual inspections.Check electrodes for buildup and clean with non-abrasive solutions to maintain±0.5%accuracy.Verify flange bolts and grounding annually to ensure NEMA 4X integrity.Store spare units in a dry,-30°C to 80°C environment to prevent corrosion.Regular transmitter diagnostics via Modbus RTU(Real-Time Unit Protocol)can reduce downtime by 15%.
Support:Shenzhen LX Automatic backs the Foxboro 2802-SABA-TSA-G with a 12-month warranty,covering repairs or replacements for defects.Our 24/7 global technical support ensures rapid solutions for installation,calibration,or troubleshooting.With 20 years of automation expertise,our vast inventory and swift logistics deliver within 5 days.Contact us for a customized solution to keep your flow measurements precise and reliable!
English Description:
The Foxboro 2802-SABA-TSA-G,a 2-inch magnetic flowtube from Foxboro(Schneider Electric),delivers precise volumetric flow measurement for conductive liquids in industrial applications.Featuring a PTFE lining and 316L stainless steel electrodes,it ensures±0.5%accuracy and 20%longer service life in corrosive environments.Certified for NEMA 4X(IP66 equivalent),it operates reliably from-20°C to 70°C,with a 15%lower failure rate than competitors.Compatible with IMT96 MagEXPERT and IMT25 transmitters,the Foxboro 2802-SABA-TSA-G supports eX-Pulse and pulsed DC excitation,enabling seamless DCS integration.Ideal for oil and gas,chemical,and water treatment industries,its robust design and flanged CL150 mounting ensure easy installation.Backed by Shenzhen LX Automatic’s 12-month warranty and 24/7 global support,the Foxboro 2802-SABA-TSA-G guarantees dependable performance and rapid delivery for critical flow measurement needs.
