Application Scenarios
In a large-scale manufacturing plant,the GE IC200ALG264 played a pivotal role in optimizing the production line’s efficiency.By accurately capturing and processing analog signals from various sensors,it enabled real-time monitoring and control of critical parameters.This not only improved product quality but also reduced downtime significantly,addressing the plant’s key pain points of inefficiency and high maintenance costs.
Parameter
Main Parameters Value/Description
Product Model GE IC200ALG264
Manufacturer General Electric
Product Category Analog Input Module
Input Channels 15 single-ended analog inputs
Input Range 4-20 mA or 0-20 mA(configurable via terminal jumper)
Resolution 15 bits per channel
Update Rate 7.5 ms per channel
Backplane Current 100 mA
Isolation Rating 350 VAC continuous,1500 VAC for 1 minute
Environmental Temperature-20°C to 70°C(-4°F to 158°F)
Installation Method DIN rail mounting
Technical Principles and Innovative Values
Innovation Point 1:The GE IC200ALG264 features independent analog-to-digital converters(ADCs)for each channel,ensuring high accuracy and minimizing cross-talk between channels.This is a significant advantage over modules with shared ADCs,which can suffer from signal degradation.
Innovation Point 2:With its configurable input range(4-20 mA or 0-20 mA),the GE IC200ALG264 offers flexibility to adapt to various sensor types and applications.This reduces the need for additional signal conditioning equipment,saving both time and cost.
Innovation Point 3:The module’s robust isolation rating of 350 VAC continuous and 1500 VAC for 1 minute provides excellent protection against electrical noise and surges,ensuring reliable operation in harsh industrial environments.
Application Cases and Industry Value
In a chemical processing plant,the GE IC200ALG264 was integrated into the plant’s distributed control system(DCS)to monitor and control the flow rates of various chemicals.The module’s high accuracy and fast update rate enabled precise control,resulting in improved product quality and reduced waste.The plant reported a 20%increase in production efficiency and a significant reduction in maintenance costs due to the module’s reliability.
Related Product Combination Solutions
GE IC200ALG260:A similar analog input module with 8 channels,ideal for smaller-scale applications.
GE IC200ALG322:A high-density analog input module with 32 channels,suitable for large-scale automation projects.
GE IC200ALG324:Another high-density option with 64 channels,offering maximum flexibility for complex systems.
GE IC200ALG262:An analog output module that complements the GE IC200ALG264,providing a complete analog signal processing solution.
GE IC200CHS006:A chassis for housing multiple VersaMax I/O modules,including the GE IC200ALG264,for centralized control.
GE IC200PWR002:A power supply module designed to work seamlessly with the GE IC200ALG264 and other VersaMax I/O modules.
Installation,Maintenance,and Full-Cycle Support
The GE IC200ALG264 is designed for easy installation and maintenance.Its DIN rail mounting method allows for quick and secure placement in control cabinets.The module’s LED indicators provide real-time status feedback,simplifying troubleshooting and maintenance tasks.
For routine maintenance,the GE IC200ALG264 requires minimal attention.Its robust design ensures long-term reliability,reducing the need for frequent replacements.In the event of a fault,the module’s diagnostic capabilities help pinpoint the issue quickly,minimizing downtime.
General Electric provides comprehensive technical support and after-sales service for the GE IC200ALG264.Our team of experts is available to assist with installation,commissioning,and ongoing maintenance,ensuring your automation system operates at peak performance.
