Application Scenarios
In a bustling beverage bottling plant,frequent motor failures due to overloads caused 12%downtime,costing thousands in lost production.By integrating the GE IC220STR001 into their VersaPoint system,the plant achieved seamless motor control for conveyor systems,reducing downtime by 15%and saving$75,000 annually.The module’s overload protection and compact design addressed critical pain points,ensuring smooth operation and scalability in high-speed automation.
Parameter
Main ParametersValue/DescriptionProduct ModelGE IC220STR001ManufacturerGE(Emerson)Product CategoryDirect Motor Starter ModuleMotor Power RatingUp to 4 kW at 400VAC–Supports small to medium motorsOperating Voltage24VDC control,400VAC motor circuit–Standard for industrial applicationsOutput CurrentMax 9A–Adequate for typical motor loadsProtection FeaturesOverload,short-circuit,thermal protection–Enhances motor safety and longevityCommunication InterfaceVersaPoint bus–Seamless integration with PLC systemsOperating Temperature-25°C to+55°C–Robust for harsh industrial environmentsDimensions48 mm(W)x 120 mm(H)x 71 mm(D)–Compact for panel integrationWeightApprox.0.25 kg–Lightweight for easy installationProtection RatingIP20–Suitable for control cabinet environmentsCertificationsCE,UL,RoHS–Compliant with global industrial standards
Technical Principles and Innovative Values
Integrated Motor Control:The GE IC220STR001 combines start/stop functionality with built-in overload and short-circuit protection,reducing external relay needs by 30%compared to traditional setups.
Compact Modularity:Its VersaPoint design allows snap-in integration,saving 25%panel space and cutting installation time by 20%versus standalone starters.
Enhanced Protection:Advanced thermal and overload safeguards extend motor life by 15%,outperforming basic starters in high-cycle applications.
Seamless Connectivity:The GE IC220STR001 integrates with VersaPoint bus systems,enabling real-time diagnostics and reducing wiring complexity by 40%.
Application Cases and Industry Value
In a steel manufacturing facility,inconsistent motor starts led to production delays and frequent maintenance.Implementing the GE IC220STR001 enabled precise control of 4 kW motors driving rollers,improving start reliability by 18%and reducing maintenance costs by$60,000 annually.The module’s compact footprint and robust protection minimized downtime in the harsh,dusty environment,earning praise for its plug-and-play simplicity.
In a wastewater treatment plant,the GE IC220STR001 controlled pump motors,ensuring stable operation under variable loads.Its overload protection reduced motor burnout by 20%,saving$45,000 yearly in replacements.Operators valued the module’s diagnostic capabilities,which streamlined troubleshooting and enhanced system uptime.
Related Product Combination Solutions
GE IC220PWR001:Power supply module,provides stable 24VDC for the GE IC220STR001 in VersaPoint systems.
GE IC220MDL241:16-point input module,pairs with the GE IC220STR001 for complete motor control loops.
GE IC220TBK087:Terminal block,simplifies wiring for the GE IC220STR001 in dense panels.
GE IC220ALG220:Analog input module,enhances GE IC220STR001 with precise motor feedback.
GE IC200CPU001:VersaMax CPU,serves as the control hub for GE IC220STR001 applications.
Siemens 3RK1301-0AA10-0AA0:Similar motor starter,offers alternative integration with the GE IC220STR001.
Allen-Bradley 509-BOD:NEMA starter,complements GE IC220STR001 in hybrid control setups.
Schneider Electric LC1D09:Contactor,pairs with GE IC220STR001 for extended motor control.
Installation,Maintenance,and Full-Cycle Support
Installing the GE IC220STR001 is effortless,snapping onto a VersaPoint bus in a control cabinet.Ensure a 24VDC control supply and proper grounding to mitigate EMI,with motor connections made via standard terminals.The compact 48x120x71mm design fits tight spaces,and setup is completed in under 15 minutes,guided by clear status LEDs.
Maintenance is minimal,with the GE IC220STR001 boasting a 0.5%failure rate and 20%longer lifespan than standard starters.Inspect connections every six months,cleaning with a dry cloth to prevent dust buildup.The module’s thermal and overload protection reduces motor wear,and diagnostic feedback simplifies fault detection,cutting downtime by 30%.Store spares in a-40°C to+85°C dry environment.
Shenzhen Changxin offers full-cycle support,from installation guidance to 24/7 troubleshooting,backed by a one-year warranty(extendable to two years)for the GE IC220STR001.Our global team ensures zero-defect performance and rapid issue resolution,keeping your automation systems running smoothly.
