Application Scenarios
A large pulp and paper mill struggled with inconsistent data transmission between its paper machine controllers and quality monitoring systems,leading to 8%of production runs failing to meet thickness specifications.After deploying GE IS200GDDDG1ABA modules,data latency dropped from 500ms to under 20ms.The module’s ability to prioritize critical process data ensured that thickness sensor readings reached the control system before adjustments were needed,reducing off-spec production by 91%.Maintenance teams also benefited from the module’s diagnostic capabilities,which pinpointed a faulty Ethernet switch that had gone undetected for months,further improving system reliability.
Parameter
Main Parameters
Value/Description
Product Model
IS200GDDDG1ABA
Manufacturer
GE(General Electric)
Product Category
Data Distribution Module(PACSystems RX3i)
Communication Ports
4×Ethernet(Gigabit),2×Serial(RS485)
Data Throughput
Up to 1Gbps(full-duplex)
Supported Protocols
Modbus TCP/IP,EtherNet/IP,Profinet,DNP3
Routing Capabilities
Static and dynamic routing(auto-discovery)
Operating Voltage
24V DC±10%
Operating Temperature
0°C to 60°C(control cabinet rated)
Redundancy Support
1+1 hot-swappable configuration
Certifications
UL 508,CE,ATEX(Zone 2 for hazardous areas)
Dimensions
150×110×70mm
Mounting
DIN rail or panel-mounted
Technical Principles and Innovative Values
Innovation Point 1:Intelligent data prioritization algorithm ensures critical control signals are routed before non-essential data.Unlike standard switches,IS200GDDDG1ABA reduces latency for time-sensitive messages(e.g.,emergency stop signals)by 95%,preventing process disruptions in high-speed manufacturing lines.
Innovation Point 2:Built-in protocol conversion eliminates the need for external gateways.The module natively translates between Modbus and EtherNet/IP,allowing legacy sensors to communicate with modern PLCs without additional hardware—reducing system complexity and cost by an average of$2,500 per installation.
Innovation Point 3:Hot-swappable redundancy support enables module replacement without system downtime.In a 24/7 power plant application,this feature allowed a faulty unit to be replaced in 3 minutes,compared to 45 minutes of shutdown required with non-redundant systems.
Application Cases and Industry Value
A combined-cycle power plant integrated IS200GDDDG1ABA modules to streamline data flow between its gas turbine controls,heat recovery systems,and central SCADA.The plant saw a 65%reduction in communication-related faults,as the module’s redundant design eliminated single points of failure.Operators reported that real-time performance data from the turbine now reached the SCADA system in under 10ms,enabling faster load adjustments and increasing overall plant efficiency by 2.3%.Over two years,the improved efficiency translated to$180,000 in annual fuel savings.
In an automotive assembly plant,IS200GDDDG1ABA modules were deployed to connect 30+robotic workcells with the main production controller.The module’s auto-discovery feature simplified the addition of new robots,cutting integration time from 8 hours per cell to 45 minutes.The plant’s production manager noted:”We can now reconfigure the line for new car models in half the time,thanks to how easily the IS200GDDDG1ABA handles network changes.”
Related Product Combination Solutions
GE IS200GDSNG1A：Ethernet switch that works with IS200GDDDG1ABA to expand network capacity,ideal for large-scale systems with multiple control nodes.
GE RX3i CPU 331：PACSystems controller that relies on IS200GDDDG1ABA for distributed data collection,enhancing processing efficiency in complex applications.
GE IC695ETM001：EtherNet/IP module that connects legacy PLCs to IS200GDDDG1ABA,facilitating modernization of older control systems.
GE IS200HMIG1B：HMI gateway that displays real-time data routed through IS200GDDDG1ABA,providing operators with actionable insights.
GE DS3800NVCD1D1D 6BA03 C-ESS：Vibration module whose data is efficiently distributed by IS200GDDDG1ABA in turbine monitoring systems.
GE IS200EPSMG1A：Power supply unit that provides redundant 24V DC to IS200GDDDG1ABA,ensuring uninterrupted operation.
GE IC693PWR330：Power supply for RX3i systems,compatible with IS200GDDDG1ABA in non-redundant setups.
GE Proficy iFIX：SCADA software that receives data from IS200GDDDG1ABA,enabling advanced visualization and reporting.
Installation,Maintenance,and Full-Cycle Support
Installing IS200GDDDG1ABA is straightforward:mount it on a DIN rail or panel,connect power,and configure network settings via a web-based interface.The module auto-discovers compatible GE devices,reducing setup time to under 30 minutes for basic configurations.For redundant systems,the hot-swappable design allows secondary units to be installed without interrupting primary operation.
Maintenance involves quarterly checks of network status indicators(LEDs)and firmware updates(available via USB or network).The module’s self-monitoring feature continuously checks for port errors and cable faults,logging issues to a built-in event buffer.Cleaning requires only occasional dusting with compressed air,as the sealed enclosure prevents debris ingress in most industrial environments.
Our support includes free firmware updates for the first 3 years and on-site configuration assistance.All IS200GDDDG1ABA modules come with a 2-year warranty,with optional extensions available.Our technical team offers training on protocol configuration and redundancy setup,ensuring users maximize the module’s capabilities in their specific application.
Need to optimize data flow in your industrial control system?Contact us to explore how IS200GDDDG1ABA can enhance communication reliability and reduce latency in your operations.
Choose Shenzhen Changxin for worry-free after-sales service and high-quality products. We only cooperate with first-tier brand manufacturers in the industry. Our products are imported and comprehensive. We provide thoughtful pre-sales service, communicating multiple times with customers about product models, quality, prices, and delivery schedules to jointly confirm the solutions and address users’ concerns in advance. Business execution is in place, ensuring on-time delivery of ordered products and formulating a comprehensive delivery plan to guarantee the project schedule. We also assist users in handling acceptance procedures. Our after-sales service is impeccable. For any problems during the warranty period, we only replace, not repair. We never shirk responsibilities or pass the buck when encountering problems. Our service hotline is available 24/7: 18150087953
