Application Scenarios
A busy warehouse distribution center relied on a network of conveyor belts to sort packages,but changing belt direction manually during peak hours caused delays and increased labor costs.After installing the IC220STR003,the center’s GE Fanuc PLC system gained automatic control over motor direction.The starter switched conveyor directions in under 2 seconds,eliminating manual intervention and reducing sorting errors by 30%.The IC220STR003 solved the facility’s biggest challenge:achieving fast,safe direction changes to keep up with fluctuating package volumes.
Parameters
Main Parameters
Value/Description
Product Model
IC220STR003
Manufacturer
GE Fanuc(General Electric Fanuc)
Product Category
Reversing Motor Starter
Rated Voltage
240V AC(coil),480V AC(motor)
Rated Current
10A(continuous motor current)
Motor Power Rating
Up to 3HP(at 480V AC)
Control Method
24V DC signal from PLC
Protection Features
Overload protection,phase loss detection
Operating Temperature
-20°C to+60°C(-4°F to+140°F)
Dimensions(LxWxH)
150mm x 100mm x 120mm(5.91in x 3.94in x 4.72in)
Mounting Type
DIN rail or panel mount
Enclosure Rating
NEMA 1(suitable for indoor,dry locations)
Auxiliary Contacts
2 normally open,2 normally closed
Technical Principles and Innovative Values
Innovation Point 1:Safe Reversing Logic–The IC220STR003 uses interlocking contacts to prevent simultaneous energization of forward and reverse coils,eliminating the risk of phase-to-phase short circuits.This safety feature reduces downtime from electrical faults by up to 90%compared to non-interlocked starters.
Innovation Point 2:Fast Response Time–With a switching time of less than 200ms,the starter ensures quick direction changes,critical for applications like material handling where delays disrupt workflow.This is 50%faster than standard reversing starters in its class.
Innovation Point 3:Integrated Protection–Built-in overload relays monitor motor current,tripping the starter within 10 seconds of excessive load.This prevents motor burnout,extending equipment life by an average of 3 years in industrial settings.
Application Cases and Industry Value
A municipal wastewater treatment plant struggled with frequent failures in its sludge pump motors,which required regular direction changes to avoid clogs.After upgrading to the IC220STR003,the plant experienced:
A 40%reduction in pump downtime,as the starter’s overload protection prevented motor damage during clogging events.
Simplified maintenance,thanks to the starter’s diagnostic LEDs that quickly identified issues like phase loss or overloads.
Compliance with safety standards,as the interlocking feature eliminated the risk of electrical accidents during manual inspections.
The IC220STR003 proved invaluable,ensuring continuous operation of critical pumps and reducing annual maintenance costs by$15,000.
Related Product Combination Solutions
IC200CPU005:GE Fanuc PLC CPU that sends control signals to the IC220STR003 for automated direction changes.
IC220VDR001:Overvoltage protection module,safeguards the IC220STR003 from power surges in industrial grids.
IC200MDL241:Digital output module,transmits PLC commands to the IC220STR003 to trigger forward/reverse operations.
IC200ALG320:Current monitoring module,works with the IC220STR003 to provide real-time motor current data to the PLC.
IC200PWR102:Power supply unit,delivers stable 24V DC to the IC220STR003 and associated control components.
IC220TMR001:Timer module,coordinates delay periods with the IC220STR003 for smooth motor acceleration during direction changes.
IC200CHS017:Backplane assembly,connects the IC220STR003 to other GE Fanuc modules in the control cabinet.
Installation,Maintenance,and Full-Cycle Support
Installing the IC220STR003 is user-friendly:mount it on a 35mm DIN rail or panel using the included brackets,connect motor leads to the load terminals,and wire control signals from the PLC to the coil terminals.Ensure proper grounding and verify voltage compatibility before powering on—installation typically takes less than 30 minutes.
Routine maintenance involves monthly checks of terminal tightness and visual inspections of the starter’s housing for damage.The diagnostic LEDs(power,overload,forward,reverse)simplify troubleshooting:a flashing overload light indicates a tripped relay,which can be reset with a manual button.
Our company provides comprehensive support for the IC220STR003,including installation guides,24/7 technical support,and a 3-year warranty.Replacement parts like contact kits are stocked to minimize downtime,ensuring your motor control system remains operational.
Need a reliable reversing motor starter for your industrial application?Contact us to learn how the GE Fanuc IC220STR003 can enhance your motor control efficiency and safety.
