Product Overview
The Yaskawa 87820-40200 is a premium industrial encoder cable assembly designed by Yaskawa Electric Corporation,a global leader in motion control and servo technology.This cable serves as the critical“signal bridge”between encoders and servo drives in Yaskawa servo systems,responsible for transmitting high-precision position,speed,and feedback data—essential for achieving the tight motion control required in automated manufacturing.As a genuine Yaskawa accessory,Yaskawa 87820-40200 is engineered to match the performance standards of Yaskawa’s flagship servo lines,including theΣ-7 andΣ-5 series,ensuring seamless integration without compatibility issues.
What makes Yaskawa 87820-40200 stand out is its focus on reliability and durability in harsh industrial settings.Unlike generic encoder cables that may fail due to oil exposure,mechanical stress,or electromagnetic interference(EMI),Yaskawa 87820-40200 features an oil-resistant outer sheath and EMI shielding,which protects signal integrity even near high-voltage equipment or fast-moving machine parts.This design ensures consistent data transmission,preventing servo motor positioning errors that could lead to product defects or production halts.Additionally,Yaskawa 87820-40200 is built to withstand repeated bending and vibration—common in machine tools and robotics—extending its service life far beyond standard cables,making it a cost-effective choice for long-term operations.
Technical Specifications
Parameter Name
Parameter Value
Product Model
Yaskawa 87820-40200
Manufacturer
Yaskawa Electric Corporation(Japan)
Product Type
Industrial Encoder Cable Assembly(for servo systems)
Compatible Systems
Yaskawa Servo Systems(Σ-7,Σ-5,Σ-V series),Yaskawa AC Servo Drives
Cable Length
2.0 meters(standard length;custom lengths available upon request)
Conductor Material
Tinned Copper(for corrosion resistance and low signal loss)
Outer Sheath Material
Polyvinyl Chloride(PVC)-oil-resistant,flame-retardant(UL94 V-0)
Shielding Type
Braided Copper Shield(90%coverage)+Foil Shield(for EMI/RFI protection)
Number of Conductors
8 cores(24 AWG,stranded for flexibility)
Operating Voltage
300V AC/DC(max)
Operating Temperature Range
-20℃~80℃
Storage Temperature Range
-40℃~90℃
Ingress Protection(IP)Rating
IP65(when properly connected with compatible connectors)
Connector Type
Male/Female Connector(matching Yaskawa encoder/servo drive interfaces)
Signal Transmission Speed
Up to 10 Mbps(supports high-resolution encoder feedback)
Compliance Standards
UL,CE,RoHS(environmentally friendly,lead-free)
Mechanical Flexibility
10 million+bending cycles(at 100mm bend radius)
Main Features and Advantages
Dual Shielding for Uncompromised Signal Integrity:The Yaskawa 87820-40200 is equipped with a dual-shielding design—braided copper(90%coverage)plus foil shield—that blocks electromagnetic interference(EMI)and radio-frequency interference(RFI)from nearby motors,inverters,or power cables.This is critical for encoder feedback,as even minor signal distortion can cause servo motors to lose positioning accuracy.For example,in a CNC machining center with multiple high-power motors,Yaskawa 87820-40200 ensures that the encoder’s position data reaches the servo drive without errors,resulting in precise cuts and consistent part quality—something generic cables with single shielding often fail to achieve.
Oil-Resistant and Flame-Retardant Sheath:Industrial environments,especially in automotive or metalworking,are prone to oil splatters and high temperatures.The Yaskawa 87820-40200’s PVC outer sheath is oil-resistant,preventing degradation from hydraulic oil or cutting fluids,which would otherwise crack standard cables over time.It is also flame-retardant(UL94 V-0 rated),meaning it self-extinguishes if exposed to fire,reducing fire hazards in crowded control cabinets.A case study from an automotive assembly plant showed that Yaskawa 87820-40200 lasted 3x longer than generic oil-exposed cables,cutting replacement frequency and maintenance costs.
High Flexibility for Dynamic Applications:Unlike rigid cables that break under repeated movement,Yaskawa 87820-40200 uses stranded tinned copper conductors and a flexible PVC sheath,enabling over 10 million bending cycles(at 100mm bend radius).This makes it ideal for robotic arms,gantry systems,or any application where the cable moves with the machine.For instance,in a pick-and-place robot with a rotating wrist,Yaskawa 87820-40200 bends smoothly with each movement without signal loss or physical damage,ensuring the robot maintains precise positioning even after years of operation.Generic cables,by contrast,often develop conductor breaks within 1-2 million cycles,leading to unplanned downtime.
Genuine Yaskawa Compatibility:As an OEM accessory,Yaskawa 87820-40200 is designed to perfectly match Yaskawa’s servo drives and encoders(e.g.,Σ-7 series).Its connectors are precision-machined to fit Yaskawa’s interface specifications,eliminating loose connections or pin misalignment that can cause intermittent signal drops.This compatibility also simplifies installation—no need for adapter cables or custom wiring—and ensures the cable works seamlessly with Yaskawa’s diagnostic tools,allowing technicians to quickly troubleshoot issues if they arise.Using non-genuine cables,by comparison,can void system warranties and lead to costly compatibility-related failures.
Application Field
In CNC Machine Tools,Yaskawa 87820-40200 is a critical component for achieving high-precision machining.CNC lathes and mills rely on encoder feedback to adjust tool position in real time,and Yaskawa 87820-40200 transmits this data between the encoder(mounted on the spindle)and the Yaskawa servo drive.For example,when cutting a complex metal part with tight tolerances(±0.001mm),the cable’s dual shielding prevents EMI from the machine’s spindle motor from distorting the encoder signal,ensuring the tool moves exactly as programmed.Its oil-resistant sheath also stands up to cutting fluids,keeping the cable intact even in messy machining environments.Without Yaskawa 87820-40200,signal errors could lead to scrapped parts or damaged tools,increasing production costs.
Within Industrial Robotics,Yaskawa 87820-40200 enables the smooth,precise movement of robotic arms and end effectors.Yaskawa’s Motoman robots,used in automotive welding or electronics assembly,depend on encoder feedback to maintain position accuracy during fast,repetitive motions.The Yaskawa 87820-40200’s flexibility handles the robot’s constant bending and twisting,while its IP65 rating protects against dust and occasional liquid splashes in factory settings.For instance,in a car body welding line,a Motoman robot uses Yaskawa 87820-40200 to transmit encoder data,ensuring each weld is placed within 0.1mm of the target—critical for structural integrity.The cable’s long service life also reduces the need to take robots offline for maintenance,boosting overall productivity.
In Packaging Machinery,Yaskawa 87820-40200 supports the high-speed,precise motion of filling,sealing,or labeling equipment.Packaging lines run 24/7,and any downtime is costly—so reliability is key.Yaskawa 87820-40200’s durable design withstands the constant vibration of packaging machines,while its dual shielding ensures encoder feedback remains accurate,even near the machine’s drive motors.For example,in a beverage bottling line,the cable transmits data from the encoder on the conveyor drive to the Yaskawa servo system,keeping bottle spacing consistent and preventing jams.Its RoHS compliance also makes it suitable for food and beverage applications,where environmental safety is a priority.
Related Products
Yaskawa 87820-40300:A longer version of Yaskawa 87820-40200(3.0 meters)for applications where servo drives and encoders are spaced further apart(e.g.,large gantry systems).Same shielding and compatibility,just extended length.
Yaskawa 87820-40100:A shorter(1.0 meter)encoder cable assembly,ideal for compact machines or control cabinets with limited space.Matches Yaskawa 87820-40200’s performance specs but with reduced length.
Yaskawa JZSP-CMP01-02-E:A high-flex encoder cable(2.0 meters)for extreme motion applications(e.g.,robotic arms with tight bends).Offers 20 million+bending cycles—more than Yaskawa 87820-40200—for ultra-dynamic systems.
Yaskawa JZSP-CVP01-03:A power cable for Yaskawa servo motors,designed to pair with Yaskawa 87820-40200.Transmits power to the motor,while Yaskawa 87820-40200 handles encoder feedback—creating a complete servo connection solution.
Yaskawa 87820-50200:A shielded encoder cable with IP67 rating(higher water/dust resistance)than Yaskawa 87820-40200(IP65).Suitable for outdoor or washdown environments(e.g.,food processing,outdoor conveyors).
Yaskawa JZSP-U9800-001:A cable harness that includes Yaskawa 87820-40200 plus additional power and signal cables,pre-wired for YaskawaΣ-7 servo systems.Reduces installation time by eliminating separate cable routing.
Yaskawa 87820-40201:A low-temperature version of Yaskawa 87820-40200,operating down to-40℃.For cold environments like freezer warehouses or outdoor winter operations,where standard cables may become brittle.
Installation and Maintenance
Pre-installation preparation:First,verify that Yaskawa 87820-40200 is compatible with your Yaskawa servo system(e.g.,Σ-7,Σ-5)—check the system’s technical manual or Yaskawa’s website to confirm.Next,measure the distance between the encoder and servo drive to ensure the 2.0-meter length of Yaskawa 87820-40200 is sufficient;avoid stretching or coiling excess cable(coils can cause signal interference).Inspect the cable for physical damage—cuts in the sheath or bent connectors—before installation.Prepare tools like a torque screwdriver(to secure connectors without over-tightening)and cable ties(for organized routing).Ensure the installation area is free of oil leaks or sharp edges that could damage Yaskawa 87820-40200 over time.Finally,power off the servo system before connecting the cable to prevent electrical damage to the encoder or drive.
Maintenance recommendations:Conduct monthly visual inspections of Yaskawa 87820-40200—check the outer sheath for cracks,oil swelling,or wear,especially near bending points or connectors.If oil or debris accumulates on the cable,wipe it with a dry cloth(avoid harsh chemicals that could degrade the PVC sheath).Every 3 months,check the connector tightness—vibration can loosen connections,leading to signal drops.Gently torque the connectors to Yaskawa’s recommended specifications(typically 0.5-0.8 N·m).For applications with frequent motion,test the cable’s signal integrity annually using a multimeter or Yaskawa’s servo diagnostic software to detect hidden conductor damage.If Yaskawa 87820-40200 shows signs of failure(e.g.,intermittent encoder errors,no feedback),replace it immediately—using a damaged cable can cause servo drive malfunctions or motor damage.Store spare Yaskawa 87820-40200 cables in a dry,cool area(away from direct sunlight)to preserve their lifespan.
Product Guarantee
We provide a 12-month warranty for Yaskawa 87820-40200 from the date of purchase,covering all manufacturing defects(e.g.,faulty shielding,conductor breaks,or connector issues)under normal use.If Yaskawa 87820-40200 fails due to material or workmanship flaws during this period,we will replace it free of charge,including shipping costs for urgent replacements.Our technical support team is available 24/7 to assist with installation guidance,compatibility checks,or troubleshooting for Yaskawa 87820-40200—whether you need help verifying system compatibility or resolving signal issues,our experts can provide step-by-step support via email or video calls.
All Yaskawa 87820-40200 cables we supply are genuine Yaskawa products,sourced directly from authorized distributors,ensuring they meet Yaskawa’s strict quality standards.Each cable undergoes pre-shipment testing,including continuity checks,shielding effectiveness tests,and flexibility assessments,to confirm it performs as intended.We also offer flexible shipping options for Yaskawa 87820-40200,including expedited delivery for emergency replacements,ensuring you minimize downtime if a cable fails.Our commitment to authenticity and customer satisfaction means you can trust Yaskawa 87820-40200 to keep your Yaskawa servo systems running reliably,backed by the support you need to maintain seamless operations.
