ABB GJR2368900R2550 (87TS01I-E): Advant Controller Digital/Analog I/O

Technical Specifications

Main Features and Advantages

The ABB 87TS01I-E GJR2368900R2550​ delivers exceptional performance through its distributed intelligence architecture. Its core feature is a dedicated onboard microprocessor that autonomously manages a defined group of I/O modules. This local processing power enables deterministic, high-speed scanning of I/O points, which is critical for fast control loops and interlocking logic. By handling time-critical I/O tasks locally, the 87TS01I-E​ significantly reduces the communication load on the central controller and the fieldbus network, leading to improved overall system response times and stability. The module implements precise timestamping of I/O events, which is essential for sequence of events (SOE) recording and advanced diagnostic functions.High availability and robust communication are fundamental advantages. The module supports connection to the high-speed, deterministic AF 100/400 fieldbus, which is the backbone of the Advant OCS. It is designed for 1:1 hardware redundancy; a pair of 87TS01I-E​ modules can be configured for redundant operation, ensuring continuous I/O processing even in the event of a single module failure, a crucial feature for safety and critical process applications. The module’s extensive diagnostic capabilities provide clear visibility into system health. Status LEDs on the front and detailed diagnostic data accessible via the engineering software report on module state, communication integrity, and the status of its connected I/O modules. This facilitates rapid troubleshooting and predictive maintenance. Furthermore, the ABB 87TS01I-E​ is engineered for maximum reliability in harsh industrial environments, with robust electrical design for noise immunity and stable operation over a wide temperature range, ensuring long-term performance in control cabinets.

Application Field

The ABB 87TS01I-E GJR2368900R2550​ is deployed in demanding process automation environments that utilize ABB’s Advant OCS or System 800xA architecture, where distributed control, high availability, and fast, reliable I/O processing are required. Its primary application is in the power generation sector, including fossil fuel plants, nuclear facilities, and combined-cycle plants. Here, the 87TS01I-E​ controls and monitors critical I/O clusters for systems like boiler control, turbine sequencing, fuel handling, and emission monitoring. Its deterministic scanning and redundancy support are essential for the millisecond-level control and safety functions needed to ensure grid stability and plant safety.In the oil & gas industry, this module is found in upstream, midstream, and downstream applications. It manages I/O for compressor control stations, safety instrumented systems (SIS) on offshore platforms, and complex process units within refineries and petrochemical plants. The ABB 87TS01I-E​ provides the reliable data acquisition and command execution needed for precise pressure, flow, and temperature control. Similarly, in large-scale chemical and pharmaceutical manufacturing, it controls batch processes, reactor units, and utility systems. The module’s ability to handle diverse I/O types and its seamless integration with ABB’s control and safety systems make it ideal for complex, integrated automation solutions. In essence, the GJR2368900R2550​ control module is a workhorse for any large-scale, continuous, or batch process controlled by an ABB Advant or 800xA system, forming the reliable link between the digital control world and the physical process.
