Application Scenarios
During a naval combat system upgrade,engineers faced frequent system resets due to unstable power delivery in the ship’s VME-based command and control rack.The existing generic power supplies couldn’t handle voltage fluctuations from the vessel’s electrical grid,leading to data corruption and operational downtime.The integration of the VME162PA344SE resolved the issue:its robust AC/DC conversion and triple-output regulation(+5V,+12V,–12V)provided clean,stable power even under harsh marine conditions.With built-in protection against overvoltage,overcurrent,and short circuits,the VME162PA344SE eliminated unexpected shutdowns.This deployment underscores how the VME162PA344SE acts as the silent guardian of mission-critical VME systems—ensuring uninterrupted data flow and system stability in environments where failure is not an option.
Parameter
Main Parameters Value/Description
Product Model VME162PA344SE
Manufacturer GE Intelligent Platforms
Product Category VMEbus AC/DC Power Supply Module
Input Voltage 90–264 V AC,47–63 Hz(Universal Input)
Output Power 160 W(Total)
Output Voltages+5V 20A,+12V 2A,–12V 0.5A
Efficiency>80%
Protection Features Overvoltage,Overcurrent,Short Circuit,Thermal Shutdown
Cooling Method Convection(Fanless)or Forced Air(depending on chassis)
Installation Type VME64 Standard(6U,160mm depth)
Operating Temperature 0°C to+55°C
Compliance MIL-STD-461(EMI),IEC/EN 60950-1
Technical Principles and Innovative Values
Innovation Point 1:The VME162PA344SE integrates a universal AC input stage with active power factor correction(PFC),enabling stable operation across global voltage standards(90–264V AC)and reducing harmonic distortion on the power line—critical for compliance in sensitive installations.
Innovation Point 2:Engineered specifically for the VME64 architecture,the VME162PA344SE delivers precisely regulated+5V,+12V,and–12V outputs directly to the backplane,eliminating the need for additional DC/DC converters and minimizing voltage drop across long traces.
Innovation Point 3:With a compact 6U form factor and convection cooling design,the VME162PA344SE fits seamlessly into ruggedized VME chassis without requiring internal fans,enhancing system reliability in dusty or high-vibration environments.
Innovation Point 4:The VME162PA344SE supports N+1 redundancy configurations when used with compatible VME power shelves,allowing hot-swappable replacement and ensuring continuous uptime in critical control systems.
Application Cases and Industry Value
At a European rail signaling test facility,legacy VME systems were experiencing intermittent failures due to aging power supplies unable to maintain clean+5V rails under load.After replacing them with the VME162PA344SE,system stability improved dramatically.Over a six-month trial,zero power-related faults were recorded,even during simulated grid fluctuations.Engineers noted a significant reduction in electromagnetic noise affecting adjacent signal processing modules.The VME162PA344SE not only restored system reliability but also extended the operational life of the entire VME rack,delaying costly hardware overhauls and ensuring compliance with EN 50121(railway EMC)standards.
Related Product Combination Solutions
VME167PA344SE:Higher-power(167W)variant of the VME162PA344SE,suitable for systems with increased current demands on the+5V rail.
VMECHS-4U-6U:4U/6U VME chassis designed to house the VME162PA344SE,offering proper airflow and mechanical support for industrial deployment.
VME-PS-BACKPLANE:VME64 backplane with integrated power distribution optimized for use with VME162PA344SE,ensuring low-impedance power delivery.
VME-5V-REG-MODULE:Optional secondary regulator module that can be used with the VME162PA344SE to provide ultra-stable power for sensitive analog or RF boards.
GE VMIC-7611:High-performance 6U VME single-board computer that draws power directly from the VME162PA344SE,ideal for real-time control applications.
Abaco PP750:Modern 6U VME PowerPC processor,compatible with systems powered by VME162PA344SE,for system upgrades.
VME-SURGE-PROT:In-line surge protection module for AC input lines,enhancing the durability of the VME162PA344SE in lightning-prone or industrial environments.
GE VME-IO-48DI:Digital I/O module that operates reliably when powered by the VME162PA344SE,forming a complete control subsystem.
Installation,Maintenance,and Full-Cycle Support
Installing the VME162PA344SE is simple:slide the module into the designated power slot in a VME64 chassis,ensure proper grounding,and connect the AC input via the front panel or rear transition module.The module automatically synchronizes with the backplane and begins power delivery—no configuration required.Its LED status indicators provide immediate visual feedback on power health and fault conditions.
Maintenance is minimal due to the absence of moving parts and the use of long-life electrolytic capacitors.The VME162PA344SE is designed for over 100,000 hours of MTBF(Mean Time Between Failures).In redundant setups,failed units can be replaced on-the-fly without powering down the system.We provide full lifecycle support,including technical documentation,compatibility verification,and access to legacy firmware and test reports,ensuring seamless integration and long-term operational confidence.
