ABB 1MRK000161-AAR01 Control Board – Regulation & Interface PCB for ABB UNITROL Excitation & Protection IED Cubicles

Technical Specifications

Main Features and Advantages

1MRK suffix discipline — AAR01 matters.​ Like the 5366168-A/12 and the 086351-504/-004 pairs earlier in this catalog, the ABB 1MRK000161-AAR01​ makes sense only when the suffix matches the removed board. ABB’s 1MRK000161 base number appears with multiple three-letter+two-digit tails (AAR00, AAR01, AASxx, etc.), and those tails track firmware handshake expectations with the cubicle’s measurement board and power-stage board. Seating an AAR00 where the BOM calls AAR01 can produce a “board recognized but regulation loop unstable” fault that takes hours to trace. The buying rule: photograph the removed 1MRK000161-AAR01​ label, match the full suffix, order.Regulation-loop horsepower in a cubicle-internal PWA.​ In UNITROL excitation hosts, the ABB 1MRK000161-AAR01​ is where the generator-field PID (and, on newer UNITROL builds, PSS2A/SEDC/bypath-compounding) actually executes — not on the HMI PC, not on the station DCS, but on this board’s DSP/ASIC. That architectural choice is why excitation response can hit tens-of-milliseconds even if the station LAN blips: the 1MRK000161-AAR01​ talks to the power-stage firing board over the cubicle internal bus, which is independent of the station network. For a hydro governor-excitation co-sim or a steam-turbine black-start path, that independence is the reliability story.Bridging cubicle ↔ station communication.​ The AAR01 typically exchanges with the cubicle’s COM board (or integrates COM function on mid-builds) so that the station DCS or excitation engineer’s laptop sees PT secondary, field current, regulator mode, and limit status. In IEC 61850-equipped UNITROL 6020 builds, that means MMS GOOSE; in older 1020/3020 retrofits, Modbus RTU over RS-485 to the DCS. The ABB 1MRK000161-AAR01​ doesn’t decide the protocol — the cubicle BOM does — but the board has to carry the right firmware image for the protocol the COM side expects, which again circles back to suffix matching.Industrial-grade substrate for cubicle environments.​ Excitation cubicles live next to generator PT boxes, thyristor bridges, and (sometimes) cooling-fan turbulence that pulls in humid air. The 1MRK000161-AAR01​ uses FR-4 with conformal coating on shipped units, rated for the cubicle interior envelope rather than a climate-controlled server room. For coastal or hydro-mountain plants where the cubicle sees seasonal humidity swings, that coating is the difference between a five-year life and a two-year life.MRO economics for generator-aux teams.​ When a UNITROL cubicle throws a “regulation board fault” and the plant is a single-gen setup or a peaker that can’t stay offline, the choice is (a) source this ABB 1MRK000161-AAR01​ and swap in under an hour, or (b) wait 8–14 weeks for a replacement cubicle section. For utility MRO planners, the AAR01 belongs in the “generator aux, shelf-spare” tier alongside the cubicle PSU and the power-stage firing board — three SKUs that cover 90% of UNITROL non-power-device failures.

Application Field

The ABB 1MRK000161-AAR01​ clusters in ABB excitation cubicles and ABB protection-IED cabinets, which puts its application field in power generation and HV substation auxiliaries. Hydroelectric units — run-of-river, storage, pumped-storage — standardized on UNITROL 1020 (compact) or 3020 (mid) often carry the 1MRK000161-AAR01​ as the regulation board inside the exciter cubicle that sits next to the thyristor bridge and the field-breaker disconnect. Steam-turbine gensets in cogeneration plants and utility thermal units using UNITROL 3020/6020 for main-exciter or pilot-exciter regulation also land here, especially where the original build BOM called the AAR01 revision. Gas-turbine aux generators and black-start diesel gensets in refinery/terminal/airport settings — wherever the original spec was ABB UNITROL rather than a third-party AVR — can also surface the ABB 1MRK000161-AAR01​ during a mid-life PWA refresh.In the protection-IED usage path, the same 1MRK000161 base can appear inside RELION/RED/REF-class HV bay cabinets where ABB’s BOM splits “IED core” from “cubicle regulation/interface PWA,” and the AAR01 fills that interface role — bridging CT/VT secondary conditioning, cubicle local HMI, and station bus. Across both excitation and protection-host paths, the problem pattern is identical: the cubicle’s “brain” PWA failed, the generator is down or the HV bay is running unprotected, and the 1MRK000161-AAR01​ is the board-level fix that avoids a cubicle-section replacement. For MRO buyers, the caution is the same as the other internal PWAs in this catalog — confirm host BOM, confirm suffix, then buy.
