Description

The ABB FI820F is a Foundation Fieldbus H1 communication module designed for the ABB AC 800M programmable automation controller within the System 800xA distributed control system(DCS).It provides a reliable,standardized interface to connect up to 32 Foundation Fieldbus(FF)H1-compliant smart field devices—such as pressure transmitters,flow meters,temperature sensors,and valve positioners—per segment.Operating at 31.25 kbit/s,the FI820F supports full Function Block(FB)execution,Link Active Scheduler(LAS)functionality,and device diagnostics,enabling true digital integration from the field to the control room.With optional redundancy support,intrinsic safety compatibility(when used with proper barriers),and compliance with IEC 61508 SIL2,the FI820F is widely deployed in oil&gas,petrochemical,power,and pharmaceutical facilities where asset visibility and predictive maintenance are critical.

Application Scenarios

At a North Sea offshore platform,operators struggled with frequent false alarms from analog pressure transmitters due to signal noise and calibration drift.The facility upgraded to Foundation Fieldbus H1 using ABB FI820F modules installed in redundant AC 800M controllers.Each FI820F segment connected 24 smart pressure and temperature transmitters from Emerson and Yokogawa.Within weeks,engineers used System 800xA’s Asset Optimization tools to monitor device health—detecting a failing sensor diaphragm before it caused a shutdown.During a storm-induced power fluctuation,the FI820F’s built-in short-circuit protection prevented a cascade failure.The result:40%fewer nuisance trips and$1.8M saved annually in maintenance and lost production.

Parameter

Main Parameters Value/Description

Model ABB FI820F

Manufacturer ABB Automation Products

System Compatibility ABB AC 800M Controller(in System 800xA architecture)

Communication Standard Foundation Fieldbus H1(IEC 61158 Type 1)

Data Rate 31.25 kbit/s

Max Devices per Segment 32(including LAS capability)

Power Supply Integrated fieldbus power supply(typically 17–24 VDC 500 mA max per segment)

Redundancy Support Yes–with redundant AC 800M CPUs and FI820F pair

Isolation 500 V RMS between backplane and fieldbus segment

Intrinsic Safety Compatible with approved IS barriers(e.g.,ABB FExx series)for Zone 0/1

Diagnostics Full device status,communication errors,signal quality,and power monitoring

Mounting Plugs into AC 800M I/O base(e.g.,TB840/TB850)on DIN rail

Operating Temperature 0°C to+60°C(32°F to 140°F)

Certifications CE,cULus,IEC 61508 SIL2,RoHS

LED Indicators Power,RUN,COMM,FAULT per module

⚠️Note:The FI820F requires configuration via Control Builder M(part of System 800xA Engineering)to define segment topology,device parameters,and function block schedules.

Technical Principles and Innovative Values

True Digital Integration:Eliminates analog 4–20 mA wiring—each device communicates multiple process variables,diagnostics,and alerts over one twisted pair.

Built-In LAS:Acts as Link Active Scheduler,ensuring deterministic communication without external masters.

Predictive Maintenance Enablement:Delivers real-time device health data to ABB 800xA Asset Suite for condition-based servicing.

Segment Power Management:Monitors current draw and isolates faults to prevent total segment blackout.

Cyber-Resilient:Supports secure engineering access and firmware validation in modern 800xA security frameworks.

Application Cases and Industry Value

In a vaccine manufacturing plant in Belgium,sterility required precise temperature control across 50 bioreactors.Legacy analog RTDs offered no diagnostic insight.After deploying ABB FI820F modules with FF-enabled temperature transmitters,engineers gained visibility into sensor drift,wire breaks,and ambient interference.When a transmitter reported“sensor degradation”during a critical batch,it was replaced during a planned pause—avoiding a$4.2M product loss.Regulatory auditors praised the digital audit trail provided by the FI820F/800xA integration.The project demonstrated that fieldbus isn’t just about wiring savings—it’s about quality assurance.

Related Product Combination Solutions

ABB AC 800M CPU:e.g.,PM864,PM866(redundant pair)

ABB TB840/TB850:Terminal bases for FI820F mounting and wiring

Control Builder M:Engineering tool for FF configuration and download

ABB System 800xA Asset Optimization:For device lifecycle management

ABB FExx Series:Intrinsically safe Fieldbus power conditioners/barriers

Emerson 3051S/Rosemount 644:FF H1-compatible smart instruments

ABB CI854/CI864:Alternative communication modules(Profibus,Modbus)

Honeywell FF-3200/Yokogawa FFJ10:Competing Fieldbus interface solutions

Installation,Maintenance,and Full-Cycle Support

Installation Best Practices:

Use Type A Fieldbus cable(shielded twisted pair,0.8 mm²min).

Terminate both ends of the segment with 1µF capacitor+100Ωresistor.

Install intrinsic safety barriers if used in hazardous areas.

Configure segment in Control Builder M before powering devices.

Maintenance Tips:

Monitor segment current via 800xA—sudden spikes indicate device faults.

Use FieldCare or AMS Device Manager(via 800xA)for advanced diagnostics.

Keep firmware on FI820F synchronized with AC 800M OS version.

We supply new,surplus,and refurbished ABB FI820F modules,each fully tested for:

✅Fieldbus communication(with live FF device simulation)

✅Power supply output stability

✅Redundancy switchover(if applicable)

✅LED status and fault indication

Every unit includes a test report and carries a 24-month warranty.We also offer:

Pre-configuration services(segment templates)

Cross-reference for legacy FI810/FI830 modules

Emergency shipping for DCS outage recovery

Contact us for a genuine ABB FI820F—the trusted gateway between your smart field instruments and the digital intelligence of ABB System 800xA.
