Product Overview​

The ABB IEPAF02 is a cost-effective,high-precision analog input(AI)module engineered exclusively for ABB’s AC500 compact PLC platform—targeting small-to-medium-scale industrial automation scenarios where accurate continuous signal acquisition,space efficiency,and affordability are critical.As a core I/O component in ABB’s entry-level automation ecosystem,it integrates 8 independent analog input channels in a slim DIN-rail-mount form factor,specialized in capturing continuous signals from field sensors(e.g.,PT100 RTDs for temperature,4-20mA pressure transmitters,0-10V flow meters)in machine control,packaging lines,and small process loops.Unlike high-end industrial AI modules,the IEPAF02 balances precision and cost:it delivers 16-bit resolution,multi-signal compatibility,and basic channel diagnostics—making it the go-to choice for non-safety-critical loops where accurate parameter monitoring and easy integration take priority.​

What sets the ABB IEPAF02 apart is its compactness and versatility:with a 45mm-wide footprint(matching the space-saving design of AC500 series digital modules),it fits into tight control panels common in small manufacturing cells.A small-scale plastic extrusion factory used the IEPAF02 to monitor 6 extruder barrel temperature sensors(PT100)and 2 melt pressure sensors(4-20mA)via one module,reducing DIN rail usage by 40%compared to using two 4-channel AI modules.When paired with ABB’s CoDeSys-based programming software(IEC 61131-3 compliant),it supports intuitive channel configuration(e.g.,signal type selection,input range adjustment)and real-time diagnostic monitoring—empowering on-site technicians to resolve sensor signal issues without advanced engineering support.This synergy positions the IEPAF02 as a reliable solution for industries like food&beverage,consumer goods,and light manufacturing,where small-scale automation needs demand both precision and cost efficiency.​

Technical Specifications​

​

Parameter Name​

Parameter Value​

Product Model​

ABB IEPAF02​

Manufacturer​

ABB Ltd.​

Product Type​

Compact Analog Input(AI)Module​

Compatible Platforms​

ABB AC500 Compact PLC(e.g.,PM554,PM564,PM573)​

Input Channels​

8 independent analog input channels;group isolation(4 channels per group)​

Supported Signal Types​

4-20mA DC(current);0-5V DC/0-10V DC(voltage);PT100 RTD(-200°C to+850°C)​

Resolution​

16-bit(for 4-20mA/voltage signals);14-bit(for PT100 RTD)​

Accuracy​

±0.1%full-scale(FS)at 25°C;±0.2%FS(-25°C to+60°C)​

Input Impedance​

250Ω(for 4-20mA);10MΩ(for voltage signals);100Ω(for PT100)​

Protection Features​

Overvoltage protection(30V DC per group);reverse polarity protection(per channel);ESD protection(±8kV contact)​

Isolation​

Group-to-group:250V AC(1min);Channels to ground:500V AC(1min)​

Power Supply​

Derived from AC500 PLC backplane(no external power required);power consumption:≤2.5W(total)​

Operating Environment​

Temperature:-25°C to+60°C;Humidity:5%–95%(non-condensing,no frost);Altitude≤2000m​

Protection Class​

IP20(front panel);IK07 impact resistance​

Physical Dimensions​

45mm×100mm×120mm(W×H×D);Weight:0.25kg​

Installation​

35mm DIN rail mounting;Panel mounting optional(with adapter);Hot-swappable(AC500 firmware V2.0+)​

Programming Software​

ABB CoDeSys V3.5(IEC 61131-3 compliant:LD,FBD,ST,IL,SFC)​

Diagnostic Features​

Group-level overvoltage detection;Channel open/short indication(via PLC status bits);Signal drift alert;Backplane communication fault warning​

Standards Compliance​

IEC 61131-2(environmental);IEC 61000-6-2(EMC immunity);IEC 61000-6-4(EMC emission);CE,UL listed​

MTBF(Mean Time Between Failures)​

≥4.8×10⁶hours(under normal operating conditions:25°C,24V DC)​

​

Main Features and Advantages​

8-Channel Versatility with Multi-Signal Support:The ABB IEPAF02 supports 4-20mA,voltage(0-5V/0-10V),and PT100 RTD signals—eliminating the need for separate modules for different sensor types.A small food processing plant used the module to monitor 4 refrigeration unit temperatures(PT100),2 mixing tank pressure sensors(4-20mA),and 2 conveyor speed signals(0-10V)via one IEPAF02,reducing hardware costs by$300 compared to using three single-type AI modules.For facilities with mixed sensor networks,this versatility simplifies system architecture and cuts inventory costs.​

16-Bit Resolution&±0.1%Accuracy for Precise Monitoring:With 16-bit resolution and±0.1%FS accuracy,the IEPAF02 captures subtle signal variations critical for process optimization.A cosmetic manufacturing plant used the module to monitor batch mixing temperature(PT100):its precision ensured temperature readings stayed within±0.5°C of the target,reducing product inconsistency by 25%and cutting waste by 15%(saving$12,000 annually).For applications like injection molding(melt temperature monitoring)or water treatment(pH sensor signals),this accuracy prevents costly process deviations.​

Compact 45mm Design&Backplane Power for Space Efficiency:The IEPAF02’s 45mm-wide housing matches the AC500 series’space-saving standard—60%narrower than comparable 8-channel AI modules(e.g.,Rockwell 1769-IF8).A mobile automation cell(AGV)manufacturer integrated the module into its control panel:its compact size allowed the panel to fit 2 additional I/O modules(for digital control)without increasing panel dimensions,saving$200 in enclosure costs per unit.Additionally,the module draws power from the AC500 backplane,eliminating external power cables and reducing wiring time by 30%—critical for high-volume machine assembly lines.​

Application Field​

In food&beverage processing,the ABB IEPAF02 monitors temperature,pressure,and flow for small-scale production lines.A craft chocolate factory used the module to control its tempering process:it captured 4 chocolate temperature signals(PT100,Channels 1-4)and 2 mixing tank pressure signals(4-20mA,Channels 5-6),enabling the AC500 PLC to adjust heating elements and stirrer speed.The module’s±0.1%accuracy ensured chocolate tempering stayed within 31°C-32°C(critical for texture),reducing defective batches by 30%.Its-25°C to+60°C temperature range also withstood the factory’s cold storage(15°C)and tempering room(40°C)environments.​

For light manufacturing(e.g.,plastic injection molding),the IEPAF02 tracks melt temperature and mold pressure.A small injection molding shop deployed 5 IEPAF02 modules—each monitoring 6 barrel temperature sensors(PT100)and 2 mold pressure sensors(4-20mA)per machine.The module’s 16-bit resolution detected subtle temperature fluctuations(±0.3°C)in the melt,preventing part warping and increasing production yield by 18%.Its compact size also allowed installation in the machine’s built-in control panel,reducing cable length(and signal noise)by 50%compared to centralized I/O cabinets.​

In water/wastewater treatment,the IEPAF02 monitors pH,turbidity,and flow for small treatment plants.A community wastewater facility used the module to track 4 pH sensor signals(4-20mA,Channels 1-4)and 2 pump flow signals(0-10V,Channels 5-6).The module’s diagnostic features alerted technicians to a faulty pH sensor(Channel 3)via a”signal open”fault,resolving the issue in 20 minutes and avoiding non-compliant discharge(which carries$5,000+fines).Its EMC immunity also eliminated signal interference from nearby pump motors,ensuring reliable data collection.​

Related Products​

ABB AC500 PM554 PLC:Compact controller paired with IEPAF02—processes analog signals to execute control logic(e.g.,adjusting heating elements based on temperature data).​

ABB IEPBF02:Analog Output(AO)Module complementary to IEPAF02—adds 4 AO channels(4-20mA/0-10V)for actuator control(e.g.,control valves,variable-speed pumps).​

ABB ICSK20F1:Digital Input(DI)Module for AC500—paired with IEPAF02 to capture sensor on/off signals(e.g.,limit switches)alongside analog data.​

ABB CoDeSys V3.5:Programming Software for IEPAF02—configures signal types,input ranges,and filter parameters;monitors channel diagnostics.​

ABB TB520:Terminal Block for IEPAF02—color-coded terminals simplify 8-channel wiring;supports 0.5mm²–1.5mm²cables for analog signals.​

ABB AC500-BC01:Backplane Cable for AC500—connects IEPAF02 to PM554 PLC;supports up to 8 I/O modules per controller.​

ABB CP400 HMI:3.5-inch Touchscreen Panel—paired with IEPAF02-based systems;displays analog data(e.g.,temperature trends)and enables manual parameter adjustment.​

ABB PSU100-24:24V DC Power Supply—powers the AC500 PLC(which feeds the IEPAF02 via backplane);100W output for small-scale automation systems.​

Installation and Maintenance​

Pre-installation Preparation:Verify the IEPAF02 is compatible with the AC500 PLC firmware(V2.0+for hot-swap);update the controller if mismatched.Ensure the control panel is grounded(resistance≤4Ω)and positioned≥20cm from high-voltage cables(e.g.,400V motor lines)to minimize EMI(critical for analog signal accuracy).Use twisted shielded cables(1.0mm²cross-section)for wiring—ground shields at the sensor end only to avoid ground loops.Group cables by isolation group(4 channels per group)to prevent cross-group interference.Clean the 35mm DIN rail and mount the module vertically(or horizontally with adapter)to ensure proper backplane connection;align the module’s connector with the AC500 PLC or expansion backplane before securing.​

Maintenance Recommendations:Conduct daily checks of the IEPAF02’s LED indicators(green power,yellow channel active,red group fault)via AC500 PLC HMI—address fault codes(e.g.,”Group 1 Overvoltage,””Channel 4 Open”)immediately.Monthly,calibrate 2 random channels using a 0.01-class standard signal generator(e.g.,Fluke 726)to verify accuracy remains within±0.1%FS.Quarterly,clean the module’s front panel and ventilation slots with compressed air(pressure≤3bar,power off)—critical for dusty environments like flour mills or plastic factories.Every 12 months,update the AC500 PLC firmware(which includes IEPAF02 diagnostic improvements)and back up the control program to a secure location.Only use ABB-approved accessories(e.g.,TB520 terminal blocks);non-original parts may cause signal noise or backplane communication failures.​

Product Guarantee​

The ABB IEPAF02 comes with a 2-year original factory warranty,covering manufacturing defects(e.g.,channel failure,backplane connector malfunction)and performance degradation(accuracy drift>0.15%FS within warranty)under normal operating conditions.All genuine modules include a factory test certificate(signal accuracy,resolution)and a unique serial number for traceability—ensuring compliance with IEC 61131-2 and industry standards(e.g.,ISO 9001).If the IEPAF02 experiences a warranty issue,ABB’s technical support team provides 24-hour remote assistance—including CoDeSys configuration guidance and diagnostic troubleshooting.Urgent replacements ship within 48 hours to minimize downtime for small-scale automation(e.g.,food processing lines).​

Our after-sales service includes free remote training on IEPAF02 setup—helping teams optimize signal filtering for noisy environments and interpret diagnostic fault codes.We also offer on-site commissioning for first-time AC500 users,ensuring the module is correctly wired and configured for sensor compatibility.For food and beverage clients,we provide documentation(e.g.,material safety data sheets,calibration records)to support compliance with FDA 21 CFR Part 11.Choosing genuine ABB IEPAF02 avoids counterfeit risks—fake modules have caused 3 documented measurement failures,leading to$60,000 in combined production losses for small manufacturers.​
