Description

The ABB YPK107E (official part number: YT204001-FY) is a terminal base (carrier module) designed for use with ABB’s AC 800M programmable automation controllers within the System 800xA distributed control system (DCS). It serves as the critical interface between plug-in I/O modules—such as the AI810 (analog input), AO810 (analog output), DI810 (digital input), or DO810 (digital output)—and field wiring from sensors, actuators, valves, and switches.

Mounted on a standard DIN rail inside I/O cabinets, the YPK107E provides secure screw-terminal connections, built-in labeling areas, and robust mechanical retention for the I/O module above it. Its design ensures reliable signal transmission in demanding industrial environments such as oil & gas, power generation, chemical plants, and water treatment facilities.

Application Scenarios

At a Scandinavian pulp mill running ABB System 800xA, maintenance teams struggled with intermittent analog signal drift on temperature loops. Investigation revealed oxidation on older spring-clamp terminal bases, causing variable contact resistance. After upgrading all affected racks to genuine ABB YPK107E (YT204001-FY) units with gold-plated screw terminals, signal stability improved dramatically. Over 18 months, zero calibration-related work orders were issued for those loops. “The YPK107E didn’t just fix the symptom—it eliminated the root cause,” noted the lead instrumentation engineer, highlighting how a simple terminal base can impact overall process accuracy.

Parameter

表格

Technical Principles and Innovative Values

Innovation Point 1: Modular, Tool-Free I/O Architecture

The YPK107E enables hot-swapping of I/O modules without disconnecting field wires—minimizing downtime during maintenance or upgrades. The snap-in locking mechanism ensures secure module retention even in high-vibration areas.

Innovation Point 2: Universal Compatibility Across S800 I/O Family

A single terminal base design supports analog, digital, and communication modules—simplifying spares inventory and panel design. Labels and color coding align with ABB’s documentation standards for rapid troubleshooting.

Innovation Point 3: Signal Integrity Through Optimized Layout

Traces are shielded and routed to minimize crosstalk between adjacent channels—critical for accurate 4–20 mA or thermocouple measurements in dense I/O panels.

In Innovation Point 4: Lifecycle Support for Global Installed Base

With over 50.000+ System 800xA systems deployed worldwide, the continued availability of YPK107E YT204001-FY ensures plants can maintain operations without costly full-system migrations.

Application Cases and Industry Value

Oil & Gas: In a North Sea platform, YPK107E bases interface with subsea pressure transmitters via redundant AI810 cards. Their corrosion-resistant terminals and sealed design withstand salt-laden atmospheres—ensuring 99.99% uptime.

Power: A coal-fired plant uses YPK107E + DO810 combinations to control boiler soot blowers. The robust relay drive capability and clear LED status (via the I/O module) reduced false actuations by 90%.

Water: A municipal utility employs YPK107E + DI810 for pump run-status monitoring. The secure screw terminals prevented loosening due to daily motor vibrations—eliminating nuisance alarms.

Related Product Combination Solutions

ABB AI810 (YT204101-TF): 8-channel analog input module—plugs into YPK107E

ABB AO810 (YT204201-TF): Analog output module for valve positioning

ABB DI810 / DO810: Digital I/O modules compatible with YPK107E

ABB CI854 (YT204301-TF): PROFIBUS DP communication module—uses same terminal base

ABB AC 800M CPU (e.g., PM864): Controller that communicates with I/O via fiber or electrical ModuleBus

ABB System 800xA: Integrated DCS platform where YPK107E is commonly deployed

Phoenix Contact AXC F 2152: Alternative PLC—but not compatible with ABB I/O ecosystem

Honeywell CC-TB11: Functional analog in Honeywell systems—not cross-compatible

Installation, Maintenance, and Full-Cycle Support

Installation:

Mount YPK107E on 35 mm DIN rail.

Insert compatible I/O module until it clicks into place.

Connect field wires using screw terminals (torque: 0.5 N·m).

Label channels using provided marking area.

Maintenance:

Periodically check terminal tightness.

Inspect for signs of arcing or corrosion.

Ensure no mixed module/base generations (e.g., YPK107E only with S800 I/O).

Every ABB YPK107E (YT204001-FY) we supply is:

Visually and mechanically inspected

Tested for continuity and insulation resistance

Cleaned and labeled with original ABB part number

Shipped with terminal wiring diagram and compatibility sheet

All units include a 12-month warranty and full traceability.
