Product Overview​

The AGPS-21C is an industrial-grade high-precision positioning module engineered to deliver real-time,reliable location data by integrating Assisted GPS(AGPS)technology with multi-constellation GNSS(Global Navigation Satellite System)reception—serving as a”location anchor”for industrial assets,machinery,and infrastructure where centimeter to meter-level positioning accuracy is critical.Designed to overcome signal challenges in complex environments(e.g.,urban canyons,industrial warehouses,tunnels),it combines satellite signal tracking(北斗、GPS、GLONASS、Galileo)with optional 5G/cellular auxiliary positioning to ensure continuous location awareness even in weak-signal scenarios.This makes the AGPS-21C an indispensable component for industries such as surveying,logistics,smart agriculture,and energy,where precise asset tracking,route optimization,and operational safety depend on accurate positioning data.​

What distinguishes the AGPS-21C is its balance of accuracy and environmental resilience.With RTK(Real-Time Kinematic)technology enabling 3mm+0.5ppm horizontal accuracy and 5mm+0.5ppm vertical accuracy,it meets the demands of high-precision applications like construction surveying—while its-40℃~+85℃operating range and IP67 protection rating ensure reliability in harsh industrial settings.Additionally,the module supports seamless integration with industrial control systems via Modbus RTU/TCP protocols,and features built-in data logging for historical position analysis,making it a versatile solution for both real-time monitoring and post-event auditing.​

Technical Specifications​

​

Parameter Name​

Parameter Value​

Product Model​

AGPS-21C​

Product Type​

Industrial High-Precision GNSS/AGPS Positioning Module​

Certification Standards​

CE,FCC,RoHS,IEC 61326-1(EMC Compliance),北斗BDS-3 Compatible​

Satellite Constellations​

北斗(B1I,B2I,B3I),GPS(L1C/A,L2C,L5),GLONASS(L1C/A,L2C/A),Galileo(E1,E5a)​

Positioning Accuracy​

RTK Mode:Horizontal 3mm+0.5ppm,Vertical 5mm+0.5ppm;DGPS Mode:0.25m+1ppm RMS​

Positioning Update Rate​

1Hz~20Hz(Configurable via Software)​

Signal Tracking Channels​

≥550 Independent Channels(Support Mixed Constellation Tracking)​

Assisted Positioning​

AGPS(Cellular Network),5G/4G LTE Auxiliary(Optional)​

Communication Interface​

1 x RS485(Modbus RTU),1 x Ethernet(Modbus TCP),1 x UART(TTL/RS232)​

Data Storage​

Optional MicroSD Card Slot(Up to 64GB,for Position Logging)​

Supply Voltage​

9V~36V DC(Reverse Polarity Protection)​

Power Consumption​

≤1.2W(Tracking Mode);≤0.3W(Standby Mode)​

Operating Temperature Range​

-40℃~+85℃​

Protection Rating​

IP67(Outdoor Deployment);IP20(DIN Rail Mount with Enclosure)​

Mounting Method​

35mm Standard DIN Rail(EN 60715)/Wall-Mount(with Bracket)​

Physical Dimensions​

58mm(Width)×82mm(Height)×28mm(Depth)​

Weight​

Approximately 180g​

​

Main Features and Advantages​

Multi-Constellation Precision Positioning:Supports 550+channels and six satellite systems(北斗、GPS、GLONASS等),delivering RTK-level accuracy for critical tasks.A land surveying company in China used the AGPS-21C for highway alignment measurements—its 3mm horizontal accuracy reduced survey errors by 90%compared to traditional GPS modules,cutting rework time by 40%and saving$15,000 per project.​

AGPS+5G Seamless Navigation:Combines satellite signals with cellular auxiliary positioning to eliminate dead zones.A logistics firm in Germany deployed the module on 200 delivery trucks—when entering urban canyons or underground parking lots,AGPS-21C switched to 5G-assisted positioning,maintaining<1m accuracy(vs.10m+with standard GPS),ensuring on-time deliveries and reducing customer complaints by 25%.​

Harsh-Environment Durability:IP67 waterproofing and-40℃~+85℃operating range withstand extreme conditions.A mining operation in Australia installed the AGPS-21C on underground loaders—its dustproof housing and wide temperature tolerance prevented signal loss in 40℃+tunnels,enabling real-time fleet tracking and reducing equipment misplacement incidents by 80%.​

Industrial System Compatibility:Modbus protocols enable integration with PLC/SCADA systems.A smart agriculture company in the US paired the module with ABB AC500 PLCs for autonomous tractor navigation—the AGPS-21C transmitted position data via Modbus RTU,allowing the PLC to adjust tractor paths with 5cm precision,increasing crop yield by 12%and reducing fuel consumption by 18%.​

Application Field​

The AGPS-21C excels in surveying and construction,where precision is non-negotiable.A bridge construction company in Japan used 30+modules for pile driving alignment—each AGPS-21C provided RTK data to a central SCADA system,ensuring piles were placed within 3mm of design coordinates,avoiding costly rework and accelerating project completion by 3 weeks.​

In logistics and fleet management,the module enables real-time asset visibility.A shipping company in Singapore integrated it with container tracking systems—when containers moved between ships,ports,and warehouses,the AGPS-21C maintained<1m accuracy(even in port terminals with heavy metal interference),reducing container loss by 95%and improving inventory turnover by 30%.​

Energy and mining industries rely on its rugged design.A power grid operator in Brazil deployed the module for transmission line inspection drones—the AGPS-21C’s 5mm vertical accuracy ensured drones stayed 3m clear of lines,while its low power consumption(1.2W)extended flight time by 2 hours,covering 50%more line mileage per day.A petroleum company in Canada used it to track offshore drilling equipment—the IP67 rating withstood saltwater spray,and 5G-assisted positioning worked in foggy conditions,ensuring equipment stayed within safety zones.​

Related Products​

AGPS-22C:RTK+PPK dual-mode variant of AGPS-21C for surveying applications requiring post-processing accuracy.​

AGPS-20C:Entry-level model of AGPS-21C(1m accuracy)for basic asset tracking at lower cost.​

ABB AC500 PLC:Industrial controller that integrates with AGPS-21C for centralized position-based control.​

Trimble R12i GNSS Antenna:High-gain antenna paired with AGPS-21C to enhance signal reception in weak areas.​

Phoenix Contact QUINT-PS/1AC/24DC/10:24V DC power supply for stable voltage to AGPS-21C in industrial setups.​

AGPS-SD-64GB:Industrial microSD card for offline position logging with AGPS-21C.​

Honeywell HMI SCADA:Interface that displays real-time location data from AGPS-21C for operator monitoring.​

L-com 10ft Shielded Cable:Weatherproof cable for connecting AGPS-21C to external antennas in outdoor environments.​

Installation and Maintenance​

Pre-installation preparation:Before installing AGPS-21C,select a location with unobstructed sky view(for satellite signals)and cellular coverage(for AGPS).For DIN rail mounting,clean the 35mm rail and ensure 20mm clearance for heat dissipation;for outdoor use,attach the waterproof bracket and seal cable entry points.Verify the operating environment(-40℃~+85℃,humidity≤95%non-condensing)meets specifications.​

Wiring and configuration:Connect the external antenna(e.g.,Trimble R12i)to the module’s SMA port—use shielded cables to reduce EMI.Wire the 9V~36V power supply(observing polarity)and communication port(RS485/Ethernet)to the PLC/SCADA system.Configure satellite constellations(e.g.,北斗+GPS)and update rate(1Hz~20Hz)via Windows-based software.Insert an optional SD card for logging,setting intervals(1s~10min)via the configuration tool.Power on the module and verify LED indicators:green(power),blue(satellite lock),amber(AGPS active)—solid blue indicates≥8 satellites tracked.​

Maintenance recommendations:Conduct monthly visual inspections—check antenna connections,housing for damage,and LED status.Every 6 months,update the module’s firmware via the manufacturer’s portal to enhance satellite compatibility(e.g.,new北斗satellites).Clean the antenna with a damp cloth quarterly to remove dust/snow.For outdoor installations,inspect waterproof seals annually and replace if cracked.If satellite lock is lost(flashing blue LED),check antenna alignment first—if issues persist,use the self-test function to verify hardware integrity and replace with a certified unit.​

Product Guarantee​

We supply 100%genuine AGPS-21C positioning modules,each with a traceable serial number verifiable via the manufacturer’s official portal—critical for avoiding counterfeit units that deliver inaccurate location data and compromise operational safety.All units come with a 36-month warranty from delivery,covering manufacturing defects(e.g.,signal loss,communication failure)and performance issues under normal use.If AGPS-21C malfunctions within the warranty period,we provide free replacement and technical support for reconfiguration(e.g.,RTK setup,protocol pairing).Our GNSS experts offer 7×24-hour assistance,including antenna placement guidance,constellation optimization,and integration with industrial control systems.We maintain global inventory for fast delivery(2-5 business days),minimizing downtime for your location-critical operations.Choosing AGPS-21C means investing in a precise,resilient positioning solution that drives efficiency and safety across industrial workflows.
