Overview of the core information of BACHMANN BS203 module,based on technical documentation and industry application data compilation:
product overview
BACHMANN BS203 is an industrial grade power/control module developed by BACHMANN,specifically designed for automation systems.Its core functions include power supply,signal isolation,and modular expansion,suitable for harsh industrial environments such as power,machinery manufacturing,and maritime,and supporting distributed automation system integration.
Core functions and features
Power supply and expansion capability
Power supply compatibility:Supports wide voltage input(85-264V AC/DC),stable power output of 24V DC,maximum power of 17W(can be extended to power other modules).
Modular design:compatible with the BACHMANN M1 controller series,supports hot swappable maintenance,and adapts to compact control cabinet layouts.
Industrial grade protection
Environmental adaptability:Operating temperature from-30℃to+70℃,humidity of 95%(non condensing),and resistance to electromagnetic interference(EMI).
Protection level:IP65(dustproof and waterproof),suitable for dusty and humid environments.
Safety and isolation
Electrical isolation:Independent isolation of input/output circuits to prevent signal interference and short circuit risks.
Overload protection:automatically cuts off abnormal current to ensure equipment safety.
Technical Parameter
Parameter description
Dimensions 190mm(height)x 100mm(width)x 50mm(depth)
Weight 0.8kg(typical value)
Communication interface supports RS-485,CAN bus or Ethernet(optional)
Installation method:DIN rail installation(standard 35mm rail)
Efficiency>85%(typical load)
Typical application scenarios
industrial automation control
Sensor signal power supply(temperature,pressure,flow),actuator drive(motor,valve).
Power system integration
Substation equipment monitoring(circuit breaker status,current and voltage sampling).
Maritime and Wind Energy
Ship automation system power supply,wind turbine control(suitable for high salt spray environment at sea).
Machinery manufacturing
Machine tool PLC signal transmission,robot motion control.
Technical advantages
High reliability:Modular design supports hot swappable maintenance,with a failure rate of less than 0.05%(based on industrial test data).
Intelligent diagnosis:LED status indicator provides real-time feedback on power,communication,and overload status.
Flexible Expansion:Compatible with other modules in the BACHMANN M1 series,such as I/O expansion and memory cards,to meet complex system requirements.
