Product Overview
The BENTLY 135473-01represents a sophisticated four-channel vibration monitoring module within the renowned Bently Nevada 3500 machinery protection system,designed specifically for critical rotating equipment in industrial applications.This advanced monitoring module serves as a vital component in predictive maintenance programs,providing continuous monitoring of vibration and position parameters to detect early signs of mechanical degradation.The 135473-01is engineered to accept inputs from both proximity probes and seismic transducers,making it suitable for comprehensive machinery protection applications including turbines,compressors,pumps,and fans.Its robust design ensures reliable operation in demanding industrial environments where equipment failure can lead to significant production losses and safety hazards.
Designed with operational flexibility in mind,the BENTLY 135473-01features four independent monitoring channels that can be configured for various parameters including radial vibration,axial position,velocity,and acceleration.Each channel incorporates advanced signal processing technology that ensures accurate measurement while providing immunity to electrical interference common in industrial settings.The module’s modular design allows easy integration into 3500 system racks,while its comprehensive self-diagnostic capabilities continuously verify proper operation,providing early warning of potential issues before they affect monitoring accuracy.The 135473-01’s wide operating temperature range and robust construction make it suitable for installation in harsh environments where reliable machinery protection is essential for operational continuity.
Technical Specifications
Parameter Name
Parameter Value
Product Model
135473-01
Manufacturer
Bently Nevada
Product Type
Vibration Monitoring Module
Monitoring Channels
4 independent channels
Input Types
Proximitor,Seismic(Velocity/Acceleration)
Frequency Response
0.5 Hz to 10,000 Hz
Dynamic Range
80 dB minimum
Input Impedance
100 kΩ(Proximitor),10 kΩ(Seismic)
Alarm Setpoints
2 per channel(Alert,Danger)
Analog Outputs
4-20 mA per channel
Power Supply
24V DC(18-30V DC)
Power Consumption
8W typical
Operating Temperature
-30°C to+70°C
Storage Temperature
-40°C to+85°C
Communication Interface
RS-485 Modbus RTU
Module Dimensions
318 mm x 24 mm x 194 mm
Weight
1.2 kg
Certifications
ATEX,IECEx,cULus,CE
Main Features and Advantages
Advanced monitoring capabilities:The BENTLY 135473-01delivers exceptional measurement accuracy through sophisticated signal processing technology that maintains precision across the entire operating range.Each channel features independent signal conditioning with automatic calibration that ensures consistent performance regardless of sensor type or cable length.The module’s wide dynamic range(80 dB)captures both small changes indicative of developing faults and large signals during significant events,providing comprehensive machinery protection.Advanced digital filtering allows selective frequency monitoring,enabling focus on specific mechanical components such as gear mesh frequencies or bearing defect frequencies.
Reliability engineering:Built with industrial-grade components and redundant monitoring circuits,the 135473-01ensures continuous operation in critical applications.The module features comprehensive self-diagnostics that continuously verify channel integrity,power supply health,and processing functionality.Dual alarm setpoints per channel(Alert and Danger)provide staged warning systems that enable proactive maintenance interventions before catastrophic failures occur.The module’s robust construction withstands vibration levels and operates reliably in temperature extremes from-30°C to+70°C.
Integration flexibility:Seamless integration with the 3500 system architecture provides unified monitoring and control through common software platforms.The BENTLY 135473-01supports multiple output options including 4-20 mA analog signals for control system integration,buffered sensor outputs for analysis equipment,and relay contacts for alarm annunciation.The module’s modular design allows easy replacement and maintenance without requiring system recalibration,while its non-volatile memory retains configuration settings during power interruptions.
The BENTLY 135473-01vibration monitoring module delivers reliable machinery protection for critical industrial assets.With its advanced features and robust construction,it ensures accurate condition monitoring while withstanding the challenging conditions of industrial environments.
Application Field
The BENTLY 135473-01finds extensive application in industries where machinery reliability directly impacts operational safety and productivity.In power generation facilities,the monitor protects critical assets including steam turbines,gas turbines,and generators by continuously tracking vibration levels and positional parameters.The module’s four-channel design allows simultaneous monitoring of multiple measurement points on a single machine,providing comprehensive protection for turbine-generator sets.In hydrocarbon processing industries,the 135473-01monitors compressors,pumps,and fans in refineries and petrochemical plants,where its hazardous area certifications enable installation in Class I Division 2 environments.
The BENTLY 135473-01serves critical monitoring functions in heavy industrial applications including metal production,mining,and pulp and paper manufacturing.In steel mills,the monitor tracks vibration in rolling mill drives and auxiliary equipment,detecting misalignment and bearing wear before catastrophic failures occur.The module’s robust construction withstands the high temperatures and contamination levels typical in these environments.For critical pump applications in water treatment and distribution systems,the monitor provides early detection of cavitation,impeller wear,and bearing degradation,enabling planned maintenance during scheduled outages rather than emergency repairs.
