Product Overview
TheDEIF DPD 01038 PCB 1044500190Crepresents advanced power management technology from DEIF,designed specifically for generator control and protection systems.This sophisticated printed circuit board serves as the intelligent core of power generation control units,providing comprehensive monitoring,control,and protection functions for generator sets.TheDEIF DPD 01038 PCB 1044500190Cintegrates high-performance processing capabilities with robust communication interfaces to deliver reliable performance in demanding power generation environments.As part of DEIF’s comprehensive power management portfolio,this control board is engineered to meet the rigorous requirements of standby,prime,and peak shaving power applications.Featuring a durable design with industrial-grade components,theDEIF DPD 01038 PCB 1044500190Censures stable operation while providing essential system control and efficient power management capabilities.
Technical Specifications
Parameter Name
Parameter Value
Product Model
DPD 01038 PCB 1044500190C
Manufacturer
DEIF
Product Type
Generator Control Board
Processor
32-bit Microcontroller
Memory Capacity
2MB Flash,512KB RAM
Operating Voltage
24VDC±10%
Digital Inputs
16 Channels
Analog Inputs
8 Channels
Communication
CANbus,RS485,Modbus
Measurement Accuracy
±0.5%
Operating Temperature
-25°C to+70°C
Protection Rating
IP40
Power Consumption
5W
Certification
UL,CE,DNV-GL
Dimensions
150x100mm
Mounting
PCB Standoffs
Main Features and Advantages
TheDEIF DPD 01038 PCB 1044500190Coffers exceptional processing power with its 32-bit microcontroller architecture,enabling rapid execution of complex control algorithms and real-time data processing.High measurement accuracy of±0.5%ensures precise monitoring of critical parameters including voltage,frequency,and power values.The board features comprehensive I/O capabilities with 16 digital inputs and 8 analog inputs,providing flexible integration with various sensors and actuators.Advanced communication interfaces including CANbus,RS485,and Modbus support seamless integration with broader control systems and SCADA networks.TheDEIF DPD 01038 PCB 1044500190Cprovides complete generator protection functions including over-voltage,under-voltage,over-frequency,under-frequency,and reverse power protection.User-friendly programming interface and configurable parameters allow customization for specific application requirements.These features combine to make theDEIF DPD 01038 PCB 1044500190Ca versatile and reliable solution for modern power generation control needs.
Application Field
TheDEIF DPD 01038 PCB 1044500190Cfinds extensive application in power generation facilities for controlling diesel and gas generator sets in both prime and standby power applications.In industrial plants,it manages backup power systems ensuring continuous operation during grid outages.The marine industry utilizes theDEIF DPD 01038 PCB 1044500190Cfor main and auxiliary generator control aboard vessels,providing reliable power management at sea.Data centers and telecommunications facilities employ this control board for critical backup power system management.Healthcare facilities rely on theDEIF DPD 01038 PCB 1044500190Cfor emergency power system control in hospitals and medical centers.Commercial buildings use this board for standby generator control and load management applications.The device’s robust design and comprehensive features make it suitable for various applications where reliable power generation control is essential.
Related Products
DEIF AGC-150-Automatic Generator Controller
DEIF PPM-100-Power Protection Module
DEIF MSC-4-Multi-Signal Conditioner
DEIF RCI-1-Remote Communication Interface
DEIF GCP-300-Generator Control Panel
DEIF PCS-3000-Power Control System
DEIF MMC-800-Multi-Master Controller
DEIF WS-500-Weather Station Interface
Installation and Maintenance
Pre-installation preparation:Before installing theDEIF DPD 01038 PCB 1044500190C,verify the control cabinet dimensions and mounting requirements.Ensure proper ventilation space around the board and check that all necessary cables and connectors are available.Confirm that the power supply meets the specified 24VDC requirements and prepare appropriate tools for installation.
Maintenance recommendations:Regular maintenance of theDEIF DPD 01038 PCB 1044500190Cincludes visual inspection of connections and verification of software version.Perform periodic functional tests to ensure all inputs and outputs are operating correctly.Clean the board surface and ensure proper ventilation around the unit.Backup configuration settings regularly and update firmware as recommended by the manufacturer.Always follow the manufacturer’s maintenance guidelines and safety procedures.
Product Guarantee
We guarantee that everyDEIF DPD 01038 PCB 1044500190Ccontrol board is genuine OEM product with full manufacturer warranty coverage.Our technical support team provides comprehensive assistance from product selection through installation and commissioning.We offer complete documentation including original manufacturer specifications,installation manuals,and certification papers.All products undergo rigorous quality verification before shipment to ensure they meet DEIF’s exacting standards for performance and reliability.
