FOXBORO P0971DP Product Introduction
FOXBORO P0971DP is a high-performance input/output module designed by FOXBORO for industrial automation systems, dedicated to temperature signal acquisition and control. It is compatible with multiple types of thermal resistors (such as Pt100, Cu50, etc.) and widely used in DCS (distributed control system), process control, and industrial monitoring fields. Its core function is to achieve high-precision temperature measurement and real-time data transmission, improving the stability and intelligence level of industrial production systems.
1、 Product Overview
P0971DP is one of the core modules in the Foxboro I/A series system, which adopts a modular design and supports thermal resistance signal input and digital output, suitable for harsh industrial environments. This module ensures the accuracy of temperature measurement through high-precision analog circuits and digital signal processing technology, while integrating anti-interference design to adapt to complex electromagnetic environments.
2、 Main features and advantages
High precision temperature measurement: Supports thermal resistance types such as Pt100 and Cu50, with measurement errors below ± 0.1 ℃, meeting the stringent temperature control requirements of industrial scenarios.
Industrial grade reliability: Adopting a wide temperature range design (-25 ℃ to+70 ℃), it can withstand vibration and humidity fluctuations, and is suitable for harsh environments such as power plants and chemical equipment.
Flexible scalability: Through VME bus or industrial Ethernet interface, it can expand multi-channel input and output, compatible with Foxboro and other brand control systems.
Intelligent diagnostic function: Built in self checking module, real-time monitoring of channel status, automatic alarm and recording of fault information when abnormal.
Low power design: Typical power consumption is less than 12W, reducing energy consumption and extending device lifespan.
3、 Technical specifications
Parameter P0971DP
Brand FOXBORO
Model P0971DP
Input type thermistor (Pt100, Cu50, etc.)
Output type: Digital quantity (0-10V or 4-20mA)
Measurement accuracy ± 0.1 ℃ (typical value)
Number of channels: 8 inputs, 4 outputs (expandable)
Working voltage 220V AC (compatible with 24V DC)
Communication interface VME bus, industrial Ethernet (RJ45)
Environmental temperature -25 ℃ to+70 ℃
Protection level IP20 (standard chassis configuration)
Typical power consumption: 12W
4、 Application Fields
Industrial process control: temperature monitoring of chemical reaction vessels, temperature regulation of petroleum refining equipment.
Power system: generator winding temperature monitoring, transformer oil temperature control.
Energy management: temperature protection for solar photovoltaic inverters, thermal management for energy storage batteries.
Mechanical manufacturing: Temperature closed-loop control of metal processing equipment (such as forging furnaces, heat treatment furnaces).
Building Automation: Data Collection and Analysis of Temperature Sensors in Central Air Conditioning Systems.
5、 Related products and compatibility
Supporting modules: Foxboro P0973LN (analog input module), CP40B (communication processor), FMB231 (digital input module).
System integration: compatible with Foxboro I/A series, Siemens S7-1500, ABB AC800M and other control systems.
Extended features: Supports PROFINET, Modbus TCP protocols, and can be connected to Industrial Internet of Things (IIoT) platforms.
FOXBORO P0971DP产品简介
FOXBORO P0971DP是福克斯波罗（FOXBORO）为工业自动化系统设计的高性能输入输出模块，专用于温度信号的采集与控制，兼容多种热电阻类型（如Pt100、Cu50等），广泛应用于DCS（集散控制系统）、过程控制及工业监测领域。其核心功能是实现高精度温度测量与实时数据传输，提升工业生产系统的稳定性和智能化水平。
一、产品概述
P0971DP是福克斯波罗I/A系列系统中的核心模块之一，采用模块化设计，支持热电阻信号输入与数字量输出，适用于严苛的工业环境。该模块通过高精度模拟电路与数字信号处理技术，确保温度测量的准确性，同时集成抗干扰设计，适应复杂电磁环境。
二、主要特点和优势
高精度温度测量：支持Pt100、Cu50等热电阻类型，测量误差低于±0.1℃，满足工业场景对温度控制的严苛要求。
工业级可靠性：采用宽温域设计（-25℃至+70℃），耐受振动与湿度波动，适用于发电厂、化工设备等恶劣环境。
灵活扩展性：通过VME总线或工业以太网接口，可扩展多通道输入输出，兼容福克斯波罗及其他品牌控制系统。
智能诊断功能：内置自检模块，实时监测通道状态，异常时自动报警并记录故障信息。
低功耗设计：典型功耗低于12W，减少能源消耗并延长设备寿命。
三、技术规格
参数P0971DP
品牌FOXBORO
型号P0971DP
输入类型热电阻（Pt100、Cu50等）
输出类型数字量（0-10V或4-20mA）
测量精度±0.1℃（典型值）
通道数量8路输入，4路输出（可扩展）
工作电压220V AC（兼容24V DC）
通信接口VME总线、工业以太网（RJ45）
环境温度-25℃至+70℃
防护等级IP20（标准机箱配置）
功耗典型值12W
四、应用领域
工业过程控制：化工反应釜温度监控、石油炼化设备温度调节。
电力系统：发电机绕组温度监测、变压器油温控制。
能源管理：太阳能光伏逆变器温度保护、储能电池热管理。
机械制造：金属加工设备（如锻造炉、热处理炉）温度闭环控制。
楼宇自动化：中央空调系统温度传感器数据采集与分析。
五、相关产品与兼容性
配套模块：福克斯波罗P0973LN（模拟量输入模块）、CP40B（通信处理器）、FMB231（数字量输入模块）。
系统集成：兼容福克斯波罗I/A系列、西门子S7-1500、ABB AC800M等控制系统。
扩展功能：支持PROFINET、Modbus TCP协议，可接入工业物联网（IIoT）平台。
