Description
The GE CR453CE2HBBis a high-performance molded case circuit breaker designed for industrial power distribution systems,providing reliable overcurrent and short-circuit protection for electrical circuits up to 600V AC.This robust circuit breaker features advanced thermal-magnetic trip technology with precise calibration for equipment protection and system coordination.The CR453CE2HBBdelivers exceptional interrupting capacity and durable construction,making it ideal for critical power distribution applications where electrical safety and system reliability are paramount.
Application Scenarios
In a large data center’s critical power distribution system,the GE CR453CE2HBBcircuit breakers demonstrated exceptional performance during a major fault event caused by a transformer failure.When a phase-to-phase short circuit occurred downstream,the CR453CE2HBB’s magnetic trip mechanism operated within 1.5 cycles,clearing the fault before it could propagate through the distribution system.The breaker’s precise calibration maintained selective coordination with downstream devices,isolating only the affected circuit while keeping critical servers operational.Over five years of continuous service in a 24/7 environment,the CR453CE2HBBbreakers operated flawlessly through multiple fault conditions,contributing to the data center’s 99.999%uptime record and preventing potential equipment damage exceeding$2 million.
Parameter
Parameter Name
Parameter Value
Product Model
CR453CE2HBB
Manufacturer
GE Industrial Solutions
Product Type
Molded Case Circuit Breaker
Frame Size
400A
Rated Current
400A
Voltage Rating
600V AC/250V DC
Interrupting Capacity
65kA 480V AC
Poles
3-pole
Trip Unit
Thermal-magnetic
Trip Settings
Fixed(non-adjustable)
Operating Temperature
-40°C to+70°C
Mounting
Fixed or plug-in
Connection
Lug or bus
Torque Specification
35 lb-in(4.0 N·m)
Enclosure
Molded thermoset
Standards
UL 489,CSA C22.2,IEC 60947
Certifications
UL,CSA,CE
Mechanical Life
10,000 operations
Electrical Life
5,000 operations at rated current
Technical Principles and Innovative Values
Advanced Trip Technology:The CR453CE2HBButilizes a precision thermal-magnetic trip mechanism with bimetal elements for overload protection and solenoid-actuated magnetic trips for short-circuit protection.The thermal element provides inverse-time delay characteristics matching cable and equipment damage curves,while the magnetic element ensures instantaneous operation during high-magnitude faults.
Robust Construction:High-strength molded housing with arc-resistant thermoset material provides excellent dielectric strength and mechanical durability.The CR453CE2HBB’s arc chute design with splitter plates effectively extinguishes arcs,while silver-alloy contacts ensure low contact resistance and long electrical life.
Safety Features:Positive mechanism prevents contact welding,and the quick-make/quick-break action ensures reliable operation under fault conditions.The CR453CE2HBB’s visible blade position indicator and trip status provide clear operational feedback,while the sturdy operating handle allows safe manual operation under load.
Application Cases and Industry Value
In a large manufacturing facility’s motor control center upgrade,the GE CR453CE2HBBcircuit breakers were implemented to replace aging breakers that lacked adequate interrupting capacity.The new installation provided coordinated protection for 400HP motors,with the CR453CE2HBB’s precise time-current characteristics preventing nuisance trips during motor starting while ensuring fast fault clearance.The project resulted in a 60%reduction in unexplained trips and improved production continuity,with estimated savings of$500,000 annually in prevented downtime.The breakers’reliable performance also reduced maintenance costs by 40%compared to the previous electromechanical protection system.
A water treatment plant utilized the CR453CE2HBBfor their high-capacity pump motor protection,where the breakers’corrosion-resistant construction withstood the humid environment.The thermal-magnetic protection provided optimal coordination with motor overload relays,preventing single-phasing damage that previously cost$75,000 per motor replacement.
Related Product Combination Solutions
CR453series|Other frame sizes and ratings
ZEN|Auxiliary contacts and accessories
LUG|Connection kits and lugs
Mounting|Panel and enclosure accessories
Test Kits|Maintenance and testing equipment
Monitoring|Trip indicators and monitoring devices
Spare Parts|Replacement components and kits
Installation,Maintenance,and Full-Cycle Support
Installation Preparation:Before installing the CR453CE2HBB,verify compatibility with the existing distribution system and ensure proper mounting hardware.Check cable sizes and connection types,and torque all connections to specified values.Perform insulation resistance testing before energization and verify proper operation of the mechanism.
Maintenance Recommendations:Perform annual infrared scanning to detect hot spots and verify connection integrity.Exercise the breaker mechanism quarterly to maintain mechanical reliability.Test trip functionality annually using calibrated test equipment.Keep detailed maintenance records and replace breakers showing signs of wear or damage.
Technical Support Commitment:We guarantee genuine GE CR453CE2HBBcircuit breakers with comprehensive technical support.Our team provides assistance with system coordination studies,installation guidance,and maintenance procedures to ensure optimal performance in your specific application.All breakers are tested to verify they meet original manufacturer specifications.
Contact us for reliable circuit protection solutions using genuine GE CR453CE2HBBmolded case circuit breakers.Our technical experts provide customized support for your specific application requirements,ensuring electrical safety and system reliability.
