​​Description:​​

The GE​​IC697ALG230​​is a high-density 16-channel analog input module designed for the Series 90-70 programmable logic controller system.This module provides precise measurement of analog signals from field devices such as transmitters,sensors,and transducers in industrial automation applications.

​​Application Scenarios:​​

In a chemical processing plant,a batch reactor’s temperature control system began exhibiting erratic behavior,causing inconsistent product quality.The control system used a GE​​IC697ALG230​​analog input module to monitor sixteen critical temperature points throughout the reactor vessel.Investigation revealed that channel 12 on the​​IC697ALG230​​module was providing inaccurate readings due to internal component degradation.This module is responsible for converting analog temperature signals from RTD sensors into digital values for the PLC’s control logic.Replacing the faulty​​IC697ALG230​​module restored accurate temperature monitoring,enabling precise thermal control and ensuring consistent batch quality in the specialty chemical production process.

​​Parameter:​​

|Main Parameters|Value/Description|

|||

|Product Model|​​IC697ALG230​​|

|Manufacturer|GE Industrial Systems|

|Product Category|Analog Input Module|

|System Compatibility|Series 90-70 PLC|

|Number of Channels|16 single-ended channels|

|Input Type|Voltage or current(software configurable)|

|Voltage Range|0-10V DC,±10V DC|

|Current Range|4-20mA,0-20mA|

|Resolution|16-bit(65,536 counts)|

|Accuracy|±0.1%of full scale|

|Update Rate|10ms per channel(160ms for all channels)|

|Isolation|Channel-to-channel and channel-to-backplane|

|Power Consumption|850mA 5V DC(from backplane)|

|Connection|Front-mounted removable terminal block|

|Operating Temperature|0°C to 60°C|

​​Technical Principles and Innovative Values:​​

Innovation Point 1:High-Density Channel Configuration.The​​IC697ALG230​​packs sixteen independently configurable analog input channels into a single module slot,maximizing I/O density and reducing overall system footprint.Each channel can be individually configured for voltage or current input,providing exceptional flexibility for mixed-signal applications without requiring multiple specialized modules.

Innovation Point 2:Advanced Signal Conditioning.The module incorporates high-precision analog-to-digital conversion with automatic calibration and drift compensation.Sophisticated filtering algorithms suppress electrical noise common in industrial environments,ensuring accurate signal acquisition for critical process measurements.The high 16-bit resolution enables detection of minute signal changes for precise monitoring and control.

​​Application Cases and Industry Value:​​

A municipal water treatment facility upgraded their filtration control system using GE Series 90-70 PLCs with​​IC697ALG230​​modules to monitor pressure,flow,and pH levels across multiple filter beds.The high channel density of the​​IC697ALG230​​allowed consolidation of monitoring points that previously required three separate modules,reducing hardware costs by 40%and simplifying wiring.The improved signal accuracy enabled more precise chemical dosing control,resulting in a 15%reduction in chemical usage while maintaining water quality standards.

​​Related Product Combination Solutions:​​

​​IC697CPU782​​:Series 90-70 CPU module that processes​​IC697ALG230​​data

​​IC697CHS797​​:7-slot rack that houses the analog module

​​IC697PWR711​​:Power supply module for the system

​​IC697BEM731​​:Bus extension module for system expansion

​​IC697ALG220​​:8-channel analog input module alternative

​​IC697MDL653​​:Digital I/O modules for complete system integration

​​Installation,Maintenance,and Full-Cycle Support:​​

Installation&Maintenance:The​​IC697ALG230​​module installs into any available slot in the Series 90-70 rack.Use the removable terminal block for convenient wiring of field devices.Ensure proper signal wiring practices including shielding and separation from power cables.Regular maintenance should include verification of calibration accuracy,checking for loose connections,and monitoring for environmental contaminants that could affect performance.

Full-Cycle Support:We supply genuine GE​​IC697ALG230​​analog input modules with full compatibility assurance.Our technical team provides support for system configuration and troubleshooting guidance.Contact us for comprehensive solutions including technical documentation and lifecycle support services for your industrial automation requirements.
