Description:

The HONEYWELL TC-ODK161​is a 16-channel discrete(digital)output module designed for the Experion Process Knowledge System(PKS)C Series I/O.It functions as a critical interface,converting control signals from the Experion controllers into physical on/off commands to activate field devices such as solenoid valves,motor starters,pumps,and alarms within a process automation environment.

Application Scenarios:

In a large wastewater treatment plant,the automated control of dozens of chlorine dosing valves,filter backwash pumps,and alarm indicators is essential.The plant’s Experion PKS controller determines when a specific pump needs to start.This logical command is sent via the control network.The HONEYWELL TC-ODK161​module,housed in a remote I/O marshalling cabinet near the filter beds,receives this command.One of its 16 output channels energizes,sending 120V AC power to the coil of the pump’s motor starter contactor.The contactor closes,starting the pump.This application of the TC-ODK161​provides the vital,reliable link between the digital control system’s logic and the physical action in the field,enabling precise and automated process control across vast industrial facilities.

Parameter:

Main Parameters

Value/Description

Product Model​

TC-ODK161​

Manufacturer​

Honeywell

Product Category​

Discrete Output(DO)Module/I/O Card

Compatible System​

Honeywell Experion PKS C Series I/O

Number of Channels​

16 discrete outputs

Output Type​

Triac(Solid-State)switching elements

Output Voltage​

120V AC

Current Rating per Channel

0.5 A continuous

Point-per-Point Isolation

Channel-to-channel and channel-to-logic isolation

Status Indication​

LED per channel(Output On,Fault)

Communication​

Interfaces via the C Series I/O bus to the Field Bus Module(FBM)

Connection​

Front-removable terminal block for field wiring

Mounting​

Plugs into a C Series I/O carrier plate within a DIN rail mountable assembly

Technical Principles and Innovative Values:

Innovation Point 1:High-Density,Solid-State Reliability.The TC-ODK161​packs 16 individually isolated output channels into a single,compact module.It utilizes solid-state Triac switches instead of electromechanical relays.Triacs have no moving parts,resulting in silent operation,extremely fast switching speeds(enabling rapid control sequences),and a vastly longer operational life—typically hundreds of millions of cycles.This makes the module ideal for applications requiring frequent on/off cycling,such as batch processes or alarm signaling,where a mechanical relay would quickly wear out.

Innovation Point 2:Comprehensive Fault Diagnostics and Point Isolation.Each channel is equipped with LED indicators providing immediate visual status of the output state.More importantly,the module features sophisticated fault detection circuitry.It can diagnose and report conditions like open load(broken wire)or short-circuit on a per-channel basis back to the Experion control system.This allows operators to be proactively alerted to field wiring issues before they cause process upsets.The point-per-point isolation prevents a fault on one channel(e.g.,a short circuit)from affecting any other channel or the control system logic,ensuring fault containment and overall system resilience.

Innovation Point 3:Hot-Swappable Design for Maximum Uptime.Designed for critical process environments,the TC-ODK161​and the entire C Series I/O platform support hot-swapping under certain conditions.This means a faulty module can be replaced without requiring a full shutdown of the associated process loop or the entire control system.An engineer can remove the module by releasing the terminal block and extracting the unit,then insert a new one.The system automatically recognizes the new hardware and downloads the configuration,minimizing process interruption and supporting exceptional plant availability.

Application Cases and Industry Value:

Case Study:Pharmaceutical Cleanroom Environmental Control.A biotech facility requires ultra-precise control of room pressure cascades to prevent cross-contamination.Dozens of motorized dampers and variable fan drives must actuate based on differential pressure sensor readings.

The facility’s control system,centered on a Honeywell Experion PKS,uses multiple TC-ODK161​modules distributed in panels near the air handling units.Each module controls a group of damper actuators(on/off for isolation)and provides start/stop signals to fan system components.The solid-state reliability of the TC-ODK161​is critical,as these outputs cycle frequently to maintain pressure.During a scheduled test,a short circuit was induced on one damper actuator wire.The specific channel on the TC-ODK161​immediately detected the fault,de-energized safely,and sent a precise diagnostic alarm to the control room,identifying the exact damper.Maintenance resolved the issue within the hour without any impact on the cleanroom’s validated state.The facility’s engineering team highlighted the module’s diagnostic capability and rock-solid reliability as key to maintaining their strict FDA-compliant environmental conditions.

Related Product Combination Solutions:

The TC-ODK161​is one component in the Experion C Series I/O family.Key related products include:

Field Bus Module(e.g.,TC-FLOx):​The communication head that manages a group of I/O modules like the TC-ODK161​and interfaces with the Experion controller.

Carrier/Baseplate(e.g.,for C Series I/O):​The physical mounting unit that provides power and data bus connection for the I/O modules.

Discrete Input Modules(e.g.,TC-IDK161):​16-channel input cards for reading field switch and contact status,often used in conjunction with output modules.

Analog I/O Modules(e.g.,TC-AAI161,TC-AOI161):​For interfacing with 4-20mA or voltage signals from transmitters and to valve positioners.

Redundant Power Supply:​Ensures continuous operation for critical I/O groups.

Experion Control Software:​The configuration,programming,and monitoring environment where the points for the TC-ODK161​are defined and logic is created.

Honeywell Termination Panels:​Pre-wired marshalling cabinets designed to neatly organize field wiring connections to the I/O modules.

Installation,Maintenance,and Full-Cycle Support:

Installation involves mounting the C Series carrier on a DIN rail,plugging the TC-ODK161​module into its assigned slot,and securing the front-terminal block.Field wiring for the 120V AC load connections is then landed on this block.Configuration is performed entirely within the Experion control software,where each channel is assigned a tag name,aligned with the control logic,and placed into service.The hot-swap capability is a key installation and maintenance feature.

Routine maintenance involves periodic visual inspection of LED status indicators and reviewing system diagnostics for any reported faults.The solid-state design requires no periodic calibration.If a module fault is indicated,the hot-swap procedure allows for replacement with minimal downtime:the new module is inserted,and the system automatically recognizes it and applies the stored configuration.We provide end-to-end support for the TC-ODK161.Our modules are sourced from certified supply chains.Prior to shipment,each unit undergoes functional testing to verify channel operation and LED functionality.We offer technical expertise for integration planning and troubleshooting,supporting the long-term reliability of your Experion PKS infrastructure.
