Product Introduction

Xycom 83594BD is a high-performance multi axis motion control card based on PCI bus, designed specifically for the industrial automation field, supporting complex motion control requirements. Its core advantages lie in high precision, high scalability, and wide compatibility, making it suitable for scenarios such as CNC machine tools, robots, and automated production lines.

Main features and advantages:

Multi axis linkage control

Support 4-axis synchronous coordinated motion, capable of independently controlling each axis parameter to meet the requirements of precision trajectory planning.

Diversified interpolation function

Provide interpolation modes for straight lines, arcs, and spirals to ensure smooth and seamless motion trajectories, suitable for high-precision machining scenarios.

Flexible control mode

Supporting position, speed, and torque control modes, users can dynamically switch according to actual application needs to enhance system adaptability.

High precision feedback mechanism

Compatible with incremental and absolute encoders, supporting closed-loop control to ensure motion accuracy and stability.

Rich interface configuration

Integrated PCI bus interface (high-speed data transmission) and RS-232/RS-485 communication interface, supporting seamless connection with computers and external devices.

Powerful digital I/O expansion

Provide input ports such as limit switches, origin signals, alarm signals, as well as output ports such as pulse output and direction control to meet complex control logic requirements.

Software development support

Provide SDK toolkits that support programming languages such as C++and VB.net, facilitating secondary development and system integration.

Technical specifications:

Parameter specifications

Control the number of axes with 4-axis linkage

Interpolation type: Straight line, arc, spiral line interpolation

Position control mode: Position, speed, torque

Encoder feedback incremental, absolute

Communication interface PCI bus RS-232/RS-485

Input/output port limit switch, origin signal, pulse output

Software supports SDK toolkits such as C++, VB.net, etc

Application areas:

Manufacturing industry: CNC machine tools, electronic assembly equipment, laser cutting machines.

Automation system: Robot coordinated motion, automated warehousing and logistics.

Precision machining: engraving machines, dispensing machines, semiconductor cutting equipment.

Energy and Environmental Protection: Power Monitoring System, Environmental Protection Equipment Control.

Related products:

Ningde Runheng Automation Equipment Co., Ltd. also provides the following controller models, which complement Xycom 83594BD:

XYCOM 83594B: High performance industrial controller, supporting wide temperature operation and touch screen operation.

MLH200PGL01B: Multi axis servo control module, suitable for high load scenarios.

XUB5BNAWL2: Expand communication interface card to enhance system interconnection capability.

MLH050PGL13A: High precision stepper motor drive card, suitable for low-speed and high torque applications.

产品简介

Xycom 83594BD是一款基于PCI总线的高性能多轴运动控制卡，专为工业自动化领域设计，支持复杂运动控制需求。其核心优势在于高精度、高扩展性及广泛兼容性，适用于数控机床、机器人、自动化生产线等场景。

主要特点和优势：

多轴联动控制

支持4轴同步协调运动，可独立控制每轴参数，满足精密轨迹规划需求。

多样化插补功能

提供直线、圆弧及螺旋线插补模式，确保运动轨迹平滑流畅，适用于高精度加工场景。

灵活的控制模式

支持位置、速度及扭矩控制模式，用户可根据实际应用需求动态切换，提升系统适应性。

高精度反馈机制

兼容增量式与绝对式编码器，支持闭环控制，确保运动精度与稳定性。

丰富的接口配置

集成PCI总线接口（高速数据传输）及RS-232/RS-485通信接口，支持与计算机及外部设备无缝连接。

强大的数字I/O扩展

提供限位开关、原点信号、报警信号等输入端口，以及脉冲输出、方向控制等输出端口，满足复杂控制逻辑需求。

软件开发支持

提供SDK工具包，支持C++、VB.NET等编程语言，便于二次开发与系统集成。

技术规格：

参数项规格

控制轴数4轴联动

插补类型直线、圆弧、螺旋线插补

位置控制模式位置、速度、扭矩

编码器反馈增量式、绝对式

通信接口PCI总线、RS-232/RS-485

输入/输出端口限位开关、原点信号、脉冲输出

软件支持C++、VB.NET等SDK工具包

应用领域：

制造业：数控机床、电子装配设备、激光切割机。

自动化系统：机器人协调运动、自动化仓储物流。

精密加工：雕刻机、点胶机、半导体切割设备。

能源与环保：电力监控系统、环保设备控制。

相关产品：

宁德润恒自动化设备有限公司还提供以下型号控制器，与Xycom 83594BD形成互补：

XYCOM 83594B：高性能工业控制器，支持宽温工作与触摸屏操作。

MLH200PGL01B：多轴伺服控制模块，适用于高负载场景。

XUB5BNAWL2：扩展通信接口卡，增强系统互联能力。

MLH050PGL13A：高精度步进电机驱动卡，适配低速高扭矩应用。
