XYCOM 8320 OPEROTOR PANEL 94321-002 Product Introduction

product overview

XYCOM 8320 OPEROTOR PANEL 94321-002 is an industrial grade human-machine interface device designed specifically for automation control systems, suitable for interactive management of process control stations, operator stations, and intelligent field devices. Its core functions include real-time data monitoring, operation instruction input, and system status feedback, supporting multi protocol communication and flexible hardware expansion to meet the requirements of high reliability industrial scenarios.

Main features and advantages

Industrial grade durable design

Adopting a modular structure and a wide temperature range working environment (-20 ° C to 60 ° C), it supports vibration resistance, dust and water resistance (IP65 rating), and is suitable for complex industrial environments.

Multi protocol communication compatibility

Integrated with RS-232, RS-485, Ethernet (TCP/IP), and USB interfaces, supporting industrial protocols such as EtherCAT and Profinet, it can seamlessly interface with PLC, DCS systems, and intelligent devices.

Graphic programming and interface customization

Supports IEC 61131-3 standard programming language (ladder diagram, function block diagram, etc.), provides user-defined function block library and macro library, and supports importing PROFIBUS device configuration through GSD files.

High resolution display and interaction

Equipped with a high brightness industrial display screen, supporting touch operation and multilingual interface, it can display production data, alarm information, and trend curves in real time.

technical specifications

Parameter specifications

Product Model XYCOM 8320 OPERATOR PANEL 94321-002

Screen size 10.4 inches (1024 x 768 resolution)

Input method: touch screen+physical buttons

Communication interfaces RS-232, RS-485, Ethernet USB

Working voltage 24V DC ± 10%

Storage capacity 256MB DDR3 SDRAM

Working temperature -20 ° C to 60 ° C

Protection level IP65

application area

Process Industry Control

A DCS system operator station used in industries such as chemical and energy to monitor production parameters and perform emergency shutdown operations.

Intelligent manufacturing equipment

Integrated into equipment such as robotic arms and CNC machines, providing visual operation interfaces and fault diagnosis functions.

Rail Transit

As an auxiliary operation panel of the train control system, it supports real-time feedback of signal status and emergency command input.

Warehouse logistics

Used for AGV navigation systems and automated sorting equipment to achieve interaction between path planning and task scheduling.

Related products

XYCOM 94321-002 CPU module: works in conjunction with the current operation panel, responsible for logic control and data processing.

XYCOM 8320 Counting Module: Extended high-speed counting function, suitable for high-precision sensor data acquisition.

XYCOM 9465-KPM Industrial Computer: As the core of the control station, it supports multitasking and network communication.

XYCOM 8320 OPERATOR PANEL 94321-002产品简介

产品概述

XYCOM 8320 OPERATOR PANEL 94321-002是一款工业级人机界面设备，专为自动化控制系统设计，适用于过程控制站、操作员站及智能现场设备的交互管理。其核心功能包括实时数据监控、操作指令输入及系统状态反馈，支持多协议通信与灵活的硬件扩展，满足高可靠性工业场景需求。

主要特点和优势

工业级耐用设计

采用模块化结构与宽温域工作环境（-20°C至60°C），支持抗震动、防尘防水（IP65等级），适用于复杂工业环境。

多协议通信兼容

集成RS-232、RS-485、以太网（TCP/IP）及USB接口，支持EtherCAT、Profinet等工业协议，可无缝对接PLC、DCS系统及智能设备。

图形化编程与界面定制

支持IEC 61131-3标准编程语言（梯形图、功能块图等），提供用户自定义功能块库与宏库，支持通过GSD文件导入PROFIBUS设备配置。

高分辨率显示与交互

配备高亮度工业显示屏，支持触控操作与多语言界面，可实时显示生产数据、报警信息及趋势曲线。

技术规格

参数项规格

产品型号XYCOM 8320 OPERATOR PANEL 94321-002

屏幕尺寸10.4英寸（1024×768分辨率）

输入方式触控屏+物理按键

通信接口RS-232、RS-485、以太网、USB

工作电压24V DC±10%

存储容量256MB DDR3 SDRAM

工作温度-20°C至60°C

防护等级IP65

应用领域

流程工业控制

用于化工、能源等行业的DCS系统操作员站，实现生产参数监控与紧急停机操作。

智能制造设备

集成于机械臂、CNC机床等设备，提供可视化操作界面与故障诊断功能。

轨道交通

作为列车控制系统的辅助操作面板，支持信号状态实时反馈与紧急指令输入。

仓储物流

用于AGV导航系统与自动化分拣设备，实现路径规划与任务调度交互。

相关产品

XYCOM 94321-002 CPU模块：与当前操作面板协同工作，负责逻辑控制与数据处理。

XYCOM 8320计数模块：扩展高速计数功能，适用于高精度传感器数据采集。

XYCOM 9465-KPM工业计算机：作为控制站核心，支持多任务处理与网络通信。
