Product Name: YASKAWA JZNC-MRK12-1E

YASKAWA JZNC-MRK12-1E is an industrial grade PROFIBUS redundant link module designed specifically for high reliability automation systems. It supports the mutual conversion between single bus and redundant dual bus and is suitable for complex industrial environments such as power, elevators, automotive manufacturing, metallurgy, etc. Its core function is to enhance the fault tolerance of the bus system, ensuring the stability and real-time performance of data transmission.

technical specifications

Parameter item specification description

Protocol type PROFIBUS DP protocol

Redundancy mode supports single bus to dual redundant bus, or dual redundant bus to single bus conversion

Rate adaptation DIP switch setting rate or adaptive mode (supports 10 commonly used rates)

Isolation protection optocoupler isolation design to reduce electromagnetic interference

Power input DC 9-36V wide voltage range

Protection level IP30, suitable for industrial environments with dust and mild liquid splashes

Installation method: 35mm DIN rail installation

Alarm output relay alarm signal output, supporting fault status monitoring

Working temperature -20 ℃ to 60 ℃

Power consumption ≤ 5W

Main features and advantages

High reliability redundancy design

Through the dual bus redundancy architecture, even if a single bus fails, the system can still maintain operation, significantly reducing the risk of downtime.

Flexible speed adaptation

Supports manual setting or automatic adaptation to 10 PROFIBUS DP rates (such as 9.6kbps to 12Mbps) to meet the communication needs of different devices.

Industrial grade protection capability

The aluminum wavy shell enhances vibration resistance, and the wide voltage input and temperature range ensure stable operation in extreme environments.

Modular scalability

It can be directly integrated into the master or slave station, expanding the system bus topology and simplifying complex network deployment.

application area

Power industry: Used for redundant communication support in substation automation and generator control systems.

Elevators and Machinery: Enhance the fault tolerance of the elevator control system bus to ensure safe operation in emergency situations.

Automotive manufacturing: supports high-speed data exchange and fault self recovery of production line equipment such as robots and conveyor belts.

Metallurgy and Chemical Industry: Ensuring the stability of data transmission between PLC and sensors in high temperature and dusty environments.

Related products

YASKAWA JZNC-TU09

Same series interface module, used to expand the number of bus nodes or adapt to different communication protocols.

JZNC-XIU01B

Redundant power module, used in conjunction with JZNC-MRK12-1E to achieve dual power supply redundancy.

6ES7392-4BC50-0AA0 (Siemens PLC module)

Compatible with PROFIBUS DP protocol, it can work together with JZNC-MRK12-1E as a master station to build a distributed control system.
