Description
The ABB NAIO-03F(3AUA0000016677)is an 8-channel universal analog input module designed for the ABB AC500 series of programmable logic controllers(PLCs),delivering high-precision signal acquisition in demanding industrial automation environments.It supports multiple input types—including 0–20 mA,4–20 mA,±10 V,±5 V,thermocouples,and RTDs—making it ideal for monitoring temperature,pressure,flow,and level in process-critical applications.Engineered with optical isolation and advanced filtering,the NAIO-03F ensures signal integrity,measurement accuracy,and long-term stability across fluctuating electrical conditions.
Application Scenarios
At a large district heating substation in Sweden,operators struggled with inconsistent temperature readings from legacy analog modules,leading to inefficient energy distribution and customer complaints.The site used a mix of Pt100 sensors,thermocouples,and 4–20 mA pressure transmitters—all feeding into an aging control system.During a modernization project,engineers selected the ABB NAIO-03F(3AUA0000016677)to replace obsolete I/O.Installed in an AC500eC control cabinet,the NAIO-03F seamlessly acquired data from all sensor types without requiring external signal conditioners.Its per-channel configurability allowed direct mapping of diverse inputs,while its±0.1%accuracy ensured precise boiler control and heat balancing.Within weeks,energy waste dropped by 18%,and system responsiveness improved dramatically—proving the NAIO-03F as a cornerstone of intelligent,data-driven thermal management.
Parameters
Main Parameters Value/Description
Product Model NAIO-03F(Marked as 3AUA0000016677)
Manufacturer ABB(now Hitachi Energy)
Product Category Universal Analog Input Module
Number of Channels 8 differential inputs(software-configurable per channel)
Input Types Supported 0–20 mA,4–20 mA,±10 V,±5 V,RTD(Pt100,Pt1000),Thermocouple(Types J,K,T,etc.)
Accuracy±0.1%of full scale(typical,at 25°C)
Resolution 16-bit(A/D conversion)
Isolation Voltage≥1500 V AC(channel-to-backplane,group isolation)
Common Mode Rejection>100 dB 50/60 Hz(reduces noise from ground loops)
Sampling Rate 100 ms per 8-channel scan(typical)
LED Indicators RUN(green),ERROR(red),per-channel activity(optional via software)
Installation Method 35 mm DIN rail mounting(standard)
Operating Temperature 0°C to+55°C(no derating)
Configuration Tool ABB Automation Builder(via CPU)
Note:Field wiring via spring-clamp terminals;supports 0.2–2.5 mm²conductors.
Technical Principles and Innovative Values
Innovation Point 1:True Universal Input per Channel
Unlike fixed-type analog modules,the ABB NAIO-03F allows each of its 8 channels to be independently configured for current,voltage,RTD,or thermocouple inputs via software.This eliminates the need for multiple specialized modules,reducing inventory costs and control cabinet footprint by up to 40%.
Innovation Point 2:High Accuracy with Low Thermal Drift
Featuring factory-trimmed precision references and cold-junction compensation for thermocouples,the NAIO-03F maintains±0.1%accuracy across its operating range.Its low thermal drift(<50 ppm/°C)ensures stable readings even in environments with wide temperature swings,such as outdoor substations or boiler rooms.
Innovation Point 3:Robust Signal Conditioning&Noise Immunity
Each input channel includes analog filtering,galvanic isolation,and high common-mode rejection.This design effectively suppresses EMI from VFDs,motors,and power lines—common in industrial plants—ensuring clean,reliable data for critical control loops.
Innovation Point 4:Seamless Integration with AC500 Ecosystem
The NAIO-03F connects directly to the AC500 backplane and is fully recognized in Automation Builder.Engineers can assign scaling factors,alarm thresholds,and linearization curves graphically,reducing engineering time and minimizing configuration errors.
Application Cases and Industry Value
In a pharmaceutical cleanroom facility in Switzerland,precise environmental monitoring is mandatory for regulatory compliance.The HVAC system required simultaneous acquisition of 48 analog signals—including humidity sensors(0–10 V),CO₂transmitters(4–20 mA),and Pt100 temperature probes.By deploying six ABB NAIO-03F modules in a redundant AC500 control rack,the facility achieved centralized,high-fidelity data collection.The NAIO-03F’s support for all three signal types eliminated the need for external transmitters,saving over CHF 12,000 in hardware and installation.Data integrity audits confirmed zero signal dropout over 24 months,contributing to successful FDA inspections.
At a wastewater treatment plant in Norway,the NAIO-03F was used to monitor digester tank temperatures using Type K thermocouples.Previous modules suffered from cold-junction errors and noise interference.The NAIO-03F’s built-in cold-junction compensation and isolation resolved these issues,improving temperature control accuracy by 35%.This led to more stable biogas production and a 15%increase in energy recovery efficiency.
Related Product Combination Solutions
ABB CP670:High-performance CPU for AC500eC;provides the processing power and memory to handle large analog data sets from the NAIO-03F.
ABB DSDI110AV1:Digital input module;pairs with the NAIO-03F to capture discrete status signals(e.g.,pump on/off)alongside analog process values.
ABB DSDO110A:Digital output module;enables control actions(e.g.,valve actuation)based on logic derived from NAIO-03F inputs.
ABB NAOM-01:Analog output module;complements the NAIO-03F by providing 4–20 mA control signals to field devices like control valves.
ABB Automation Builder:Engineering suite used to configure,calibrate,and monitor the NAIO-03F within the PLC project.
ABB DSMB110:Modbus RTU module;allows the NAIO-03F’s acquired data to be shared with SCADA or third-party systems.
ABB AC500 Cabinet:Pre-engineered enclosure;provides EMI shielding,thermal management,and mechanical protection for the NAIO-03F and system.
ABB NAIO-04F:Higher-density 16-channel analog input module;serves as a scalable upgrade for future expansion.
