​Product Overview​​

The​​ABB DVC500 R05 BVC1HRCP005AAP​​represents cutting-edge valve control technology from ABB,designed as a high-performance digital valve controller for precise process control applications.This sophisticated positioner serves as the intelligent interface between control systems and final control elements,providing accurate valve positioning and real-time diagnostics.The​​ABB DVC500 R05 BVC1HRCP005AAP​​incorporates advanced microprocessor technology and non-contact position sensing to ensure reliable operation in demanding industrial environments.As part of ABB’s comprehensive DVC500 series,this unit is engineered to meet the rigorous requirements of process industries where precise flow control is critical.Featuring robust construction and industrial-grade components,the​​ABB DVC500 R05 BVC1HRCP005AAP​​delivers exceptional performance while providing essential diagnostic and monitoring capabilities for modern process automation systems.

​​Technical Specifications​​

Parameter Name

Parameter Value

Product Model

​​DVC500 R05 BVC1HRCP005AAP​​

Manufacturer

ABB

Product Type

Digital Valve Positioner

Input Signal

4-20mA/HART

Supply Pressure

1.4-7 bar

Air Consumption

<0.01 NL/min

Positioning Accuracy

±0.5%of span

Response Time

<1 second

Enclosure Rating

IP66/NEMA 4X

Operating Temperature

-40°C to+80°C

Communication

HART Protocol

Mounting

ISO 5211

Material

Aluminum Housing

Certification

ATEX,IECEx,SIL2

Weight

2.1 kg

Dimensions

210×110×85 mm

​​Main Features and Advantages​​

The​​ABB DVC500 R05 BVC1HRCP005AAP​​offers exceptional control precision with±0.5%positioning accuracy and fast response time under 1 second,ensuring precise flow control in critical process applications.Its non-contact position sensing technology eliminates mechanical wear and ensures long-term calibration stability.The positioner features automatic setup and adaptive tuning capabilities that simplify commissioning and optimize valve performance across various operating conditions.The​​ABB DVC500 R05 BVC1HRCP005AAP​​incorporates advanced diagnostic functions including valve wear monitoring,packing friction analysis,and performance trending.Its robust IP66/NEMA 4X enclosure provides complete protection against harsh environmental conditions,while HART communication enables seamless integration with asset management systems.These features combine to make the​​ABB DVC500 R05 BVC1HRCP005AAP​​a reliable and intelligent solution for modern valve control requirements.

​​Application Field​​

The​​ABB DVC500 R05 BVC1HRCP005AAP​​finds extensive application in process industries where precise flow control is essential.In oil and gas production,it controls choke valves,wellhead valves,and pipeline control valves.The chemical processing industry utilizes the​​ABB DVC500 R05 BVC1HRCP005AAP​​for reactor feed control,distillation column regulation,and mixing operations.Power generation facilities employ this positioner for turbine bypass control,feedwater regulation,and steam control applications.Water and wastewater treatment plants rely on the​​ABB DVC500 R05 BVC1HRCP005AAP​​for flow modulation,level control,and chemical dosing operations.The unit’s robust design and high accuracy make it particularly suitable for applications in hazardous areas and extreme environmental conditions.

​​Related Products​​

​​ABB Positioner Accessories​​-Mounting kits and accessories

​​ABB Pressure Regulators​​-Air supply components

​​ABB Limit Switches​​-Position feedback devices

​​ABB Solenoid Valves​​-Emergency shutdown components

​​ABB Field Communicator​​-Configuration tool

​​ABB Asset Management​​-Monitoring software

​​ABB Service Kits​​-Maintenance components

​​Installation and Maintenance​​

Pre-installation preparation:Before installing the​​ABB DVC500 R05 BVC1HRCP005AAP​​,verify valve compatibility and ensure proper mounting hardware is available.Check air supply quality and pressure requirements to ensure optimal performance.

Maintenance recommendations:Regular maintenance of the​​ABB DVC500 R05 BVC1HRCP005AAP​​includes periodic calibration checks and air filter inspection.Recommend quarterly performance verification and annual comprehensive diagnostics using HART communicator.Always follow safety procedures when performing maintenance on energized systems.

​​Product Guarantee​​

We guarantee that every​​ABB DVC500 R05 BVC1HRCP005AAP​​positioner is genuine OEM product with full manufacturer warranty coverage.Our technical support team provides comprehensive assistance from product selection through installation and commissioning.We offer complete documentation including original manufacturer specifications and installation manuals.All products undergo rigorous quality verification before shipment to ensure they meet ABB’s exacting standards for performance and reliability in process control applications.
