SCHNEIDER 140XBP01600 is the core backplane module in Schneider Electric’s Modicon Quantum series,designed specifically for modular architecture in industrial automation systems.This product serves as the connection hub for Quantum racks,supporting electrical and communication interconnection of multiple types of I/O modules,power modules,and controllers.It is widely used in complex control scenarios in manufacturing,energy,building automation,and other fields.
Main features and advantages
Modular interconnection capability
140XBP01600 provides 16 standardized slot positions,compatible with Quantum series CPU modules(such as 140CPU67160),power modules(such as 140CPS12420),and I/O modules(such as 140ACO02000),and supports hot swapping function for system expansion and maintenance.Its passive circuit board design ensures stable communication between modules and automatically identifies slot numbers without the need for additional configuration.
High reliability and safety
Adopting 16 8mm diameter threaded mounting holes(compatible with half height/full height modules),it complies with industrial grade vibration and impact specifications and is suitable for a wide temperature range of-40°C to 80°C.The backplane integrates Modbus Plus communication cable grounding interface to reduce the risk of signal interference.
Flexible system architecture support
Supports mixed configurations of local I/O,remote I/O,and distributed I/O,expandable to high-density analog inputs(such as 140DDI85300)or high-speed digital outputs(such as 140DDO35300),meeting complex control requirements.
Compatibility and Scalability
Compatible with Modicon Quantum series hot standby modules,supporting redundant configurations to enhance system availability;Compatible with third-party communication protocols,facilitating integration of multiple brand devices.
technical specifications
Parameter item description
Rack size vertical 11.42 inches x horizontal 26.42 inches
16 installation holes(diameter 8mm,half height/full height compatible)
Compatible module types:CPU,power supply I/O、Network interface,hot backup module
Communication interfaces Modbus Plus,EtherNet/IP,Profinet
Working temperature-40°C to 80°C
Protection level IP20(to be used in conjunction with control cabinet)
application area
Industrial manufacturing:As the core component of PLC system,it drives the automation control of production line,integrates sensors,actuators and other equipment.
Energy management:supports real-time monitoring and fault diagnosis of energy equipment such as photovoltaic inverters and energy storage systems.
Building automation:Collaborate with Quantum controllers to achieve centralized control of intelligent lighting and air conditioning systems.
Process control:high-precision process parameter adjustment and safety interlocking applied in the chemical and pharmaceutical industries.
