📌Product Overview
The OKUMA BL-D75A is a high-performance AC servo drive module,specifically designed for integration into Okuma MDS series CNC control systems.This drive delivers precise position and speed control,high dynamic response,and intelligent diagnostics,making it ideal for driving a wide range of Okuma AC servo motors,including the BL-MP,BL-MH,BL-ME,and BL-MC series.
With support for EtherCAT communication,EnDat/BiSS encoder interfaces,and built-in protection features,the OKUMA BL-D75A ensures smooth motor operation,accurate positioning,and efficient energy management—perfectly suited for applications in CNC machining centers,automated production lines,and robotic handling systems.
🔧Application Scenarios
A precision mold manufacturing plant was experiencing axis synchronization issues and frequent motor overheating due to outdated drive modules.After replacing the original drives with the OKUMA BL-D75A,they achieved improved axis tracking accuracy and reduced thermal faults by over 60%,significantly increasing production uptime and part quality.
This real-world case highlights how the OKUMA BL-D75A enhances system performance and reliability in high-demand industrial environments.
📊Main Specifications
Parameter Value/Description
Model Number BL-D75A
Manufacturer Okuma
Drive Type AC Servo Drive Module
Input Voltage 3-Phase 200–240 V AC
Output Voltage Adjustable PWM Output
Rated Output Current 7.5 A RMS
Peak Output Current Up to 15 A
Control Mode Position/Speed/Torque Control
Encoder Interface EnDat/BiSS/SSI Compatible
Communication Protocol EtherCAT/MECHATROLINK-II(optional)
Protection Class IP20
Cooling Method Natural Air Cooling
Mounting Style DIN Rail or Panel Mount
Safety Protection Overcurrent,Overvoltage,Overheat,Encoder Error Detection
Weight Approx.1.8 kg
💡Technical Principles and Innovative Features
Innovation Point 1:High-Speed Digital Signal Processing
The OKUMA BL-D75A employs advanced DSP(Digital Signal Processor)technology for fast current loop control and real-time feedback adjustment,ensuring optimal motor performance even under variable loads.
Innovation Point 2:Multi-Protocol Communication Support
Supports EtherCAT,MECHATROLINK-II,and EnDat/BiSS encoder interfaces,allowing seamless integration into modern automation architectures and multi-axis synchronized control systems.
Innovation Point 3:Intelligent Fault Diagnostics and Protection
Equipped with built-in diagnostics that detect and report faults such as overcurrent,overvoltage,overheating,and encoder errors—enabling quick troubleshooting and reducing downtime.
Innovation Point 4:Adaptive Tuning and Resonance Suppression
Features automatic gain tuning and notch filter functions to suppress mechanical resonance,improving machine stability and reducing vibration during high-speed operations.
📈Real-World Application Cases
Case 1:Automotive Parts Machining Center Retrofit
An automotive supplier upgraded their CNC lathe system using the OKUMA BL-D75A drive modules.The result was a 20%improvement in cutting accuracy and smoother axis movement,reducing tool wear and enhancing surface finish quality.
Case 2:Semiconductor Wafer Handling System Upgrade
A semiconductor equipment manufacturer integrated the OKUMA BL-D75A into their robotic arm control system.The drive provided ultra-precise position control with±1μm repeatability,significantly improving process yield and reducing maintenance frequency.
These cases demonstrate how the OKUMA BL-D75A contributes to increased productivity,superior part quality,and reduced maintenance across various industries.
🔗Compatible Product Solutions
Okuma MDS-D-SVJ3 Controller:Central motion controller compatible with the BL-D75A for full-axis coordination.
Okuma L8NA-B100G HMI Panel:Operator interface for parameter setting and system monitoring.
Okuma BP6A101A-ENG OPUS7000 CNC Controller:Full-featured CNC control unit that integrates with the BL-D75A for multi-axis synchronization.
Okuma BSV2 Series Servo Motors:Compatible with a wide range of Okuma servo motors including BL-MP,BL-MH,BL-ME,and BL-MC series.
Okuma D22/1006-1232 VACIII-Drive Unit:Mixed-servo drive option for systems requiring both linear and rotary motion control.
Okuma BL-D75A-C/UNMC-C:Brake-equipped version for vertical axis holding applications.
Okuma BL-D75A-K/UNMC-K:Smart variant with embedded condition monitoring sensors for predictive maintenance.
Together,these components form a complete,high-performance motion control ecosystem powered by the OKUMA BL-D75A as the core drive solution.
⚙️Installation&Maintenance Guidelines
Installation Preparation:
Ensure proper grounding and electrical isolation before installation.Confirm compatibility between the BL-D75A and connected motor.Use shielded cables for encoder and power connections to prevent EMI interference.
Maintenance and Support:
Routine checks should include verifying power supply voltage,inspecting for signs of overheating,and confirming communication status with the controller.Thanks to its modular design,faulty units can be quickly replaced to minimize downtime.
Full Lifecycle Service Commitment:
At Shenzhen Changxin Automation,we provide comprehensive lifecycle support for the OKUMA BL-D75A,including technical consultation,firmware updates,spare parts supply,and on-site commissioning services.Our team ensures seamless integration and long-term reliability of your automation systems.
