Vibro-meter VM600 IOCN 200-566-000-012 200-566-101-012:This I/O module combination is the”nerve center”of your turbine and compressor monitoring system!The IOCN input card connects to eight sensors,while the 200-566-101-012 output card issues commands.Dual-channel,high-precision,it supports shaft vibration,bearing vibration,and speed measurement.Its stability,accuracy,and strong interference resistance ensure the safe operation of your large-scale units!Genuine quality,factory-tested,we’re your go-to for rotating machinery monitoring.No problem!

Number of channels:8 inputs/8 outputs

Signal type:Eddy current,accelerometer,magnetoresistive probe

Output type:4-20mA analog,SPDT relay

Ingress protection:IP20

Operating temperature:-10°C to+60°C

Vibro-meter 200-566-000-012 200-566-101-012 VM600 IOCN Technical Specifications

Product Model:Vibro-meter 200-566-000-012(IOCN Input Module)

Product Model:Vibro-meter 200-566-101-012(IOCN Output Module)

Manufacturer:Vibro-meter(a GE Bently Nevada brand)

Product Type:Vibration Monitoring System I/O Module

System:VM600 Turbine Monitoring and Protection System System

Number of Input Channels:8(IOCN)

Input Signal Type:•Eddy Current Probe

•Accelerometer

•Variable Reluctance Probe

Input Measurement Range:

•Displacement:0-25 mm pk-pk(adjustable)

•Vibration:0-50 g pk(adjustable)

•Speed:1-20,000 RPM

Measurement Accuracy:±0.1%of reading

Sampling Rate:100 kHz per channel(high-speed acquisition)

Output Type:

•8 4-20mA analog outputs(configurable for vibration,speed,etc.)

•8 SPDT relay outputs(alarm,shutdown)

Relay Capacity:5A 250V AC/30V DC

Communication Interface:Modbus RTU(RS-485)

Power Supply:+24V DC(Powered by the VM600 backplane)

Operating Temperature:-10°C to+60°C

Storage Temperature:-40°C to+80°C

Protection Rating:IP20(for installation in a control cabinet)

Mounting Method:DIN rail mount,pluggable within the VM600 rack

Compliant Standards:API 670,ISO 7919,IEC 60947

Vibro-meter 200-566-000-012 200-566-101-012 VM600 IOCN Product Overview

To put it simply,the Vibro-meter VM600 IOCN 200-566-000-012 and 200-566-101-012 are simply the upgraded versions of GE’s Vibro-meter VM600 monitoring system.One module is responsible for”listening to all directions”(8-channel input),and the other is responsible for”issuing eight commands”(8-channel output).Together,they form a high-density,high-performance vibration and speed monitoring I/O solution.

What is this device used for?It’s designed specifically for valuable rotating machinery such as large steam turbines,gas turbines,multi-stage compressors,and generator sets that require a large number of monitoring points.Compared to the four-channel IOC4T,the IOCN offers double the channel density,allowing you to monitor more measurement points with fewer modules and a smaller footprint.It’s particularly suitable for large units with limited space or numerous measurement points.

200-566-000-012 This board is the IOCN input module,which connects to field-provided eddy current sensors(for measuring shaft vibration and axial displacement),accelerometers(for measuring bearing seat vibration and bearing vibration),and reluctance probes(for measuring speed and key phase).It features eight independent,high-precision channels,each capable of high-speed sampling at 100kHz and signal capture with±0.1%accuracy,ensuring detection of everything from minor bearing defects to severe mechanical shock.

The 200-566-101-012 is an IOCN output module,designed for”eight-way response.”When the main controller detects abnormal vibration or speed at eight different locations,it independently issues”alarm”or”shutdown”commands via eight SPDT relays,providing precise zone-specific protection.Furthermore,eight 4-20mA analog outputs enable real-time upload of all monitoring data to a DCS or PLC for trend analysis and historical recording.

Both boards plug into the VM600 chassis and communicate with the main controller(CPU module)via a high-speed backplane bus.With their compact design and strong electromagnetic interference(EMI)immunity,they fully comply with international turbomachinery monitoring standards such as API 670.The VM600 IOCN is the backbone of comprehensive condition monitoring and protection networks in critical facilities such as large combined cycle power plants,integrated refineries,and offshore platforms.

The Vibro-meter VM600 IOCN system serves as the core data acquisition and execution unit for turbine monitoring instruments(TSI)and machinery protection systems(MPS).It provides transparency into the health of large turbine units and ensures accurate and reliable protection actions.

Key Features and Benefits

The core advantages of the Vibro-meter VM600 IOCN 200-566-000-012 and 200-566-101-012 are high density,high accuracy,and high reliability.Its 8-channel design significantly improves rack space utilization,reduces the number of modules and wiring complexity,and reduces overall system costs and points of failure.

With±0.1%measurement accuracy and a 100kHz sampling rate per channel,it represents the cutting-edge of industrial vibration monitoring.It accurately analyzes vibration spectra,providing vibration analysts with high-quality data for fault diagnosis and predictive maintenance.

The input card supports multi-sensor fusion,allowing a single board to process multiple signals,including shaft vibration,bearing vibration,rotational speed,and key phase,with flexible configuration.The built-in signal conditioning circuitry is professional and highly resistant to field noise and ground loop interference.

The output card’s eight SPDT relays,each with a 5A drive capacity,can be directly connected to the control loop for fast and reliable protection action.The eight 4-20mA outputs support independent calibration to ensure the accuracy of remotely transmitted signals.

Supporting Modbus RTU communication,it seamlessly integrates into a plant’s distributed control system(DCS)or asset performance management system(APM),enabling data sharing and remote diagnostics.

In the health management system for large rotating machinery,the Vibro-Meter VM600 IOCN is the source of data and the driving force behind its execution.Every data point it collects is crucial to the safety and efficiency of the unit.

Ultimately,this isn’t just any I/O card.An untested IOCN module can cause multi-channel data drift and relay malfunctions,leading to widespread downtime and significant losses.Therefore,when choosing Vibro-meter 200-566-000-012 and 200-566-101-012,be sure to select genuine,fully functionally tested and calibrated Vibro-meters to ensure a flawless large-scale unit monitoring system.

The Vibro-meter VM600 IOCN modules,including the 200-566-000-012 8-channel input and 200-566-101-012 8-channel output cards,represent the high-density I/O solution for GE’s VM600 turbine monitoring platform.Engineered for large-scale rotating machinery,the IOCN input card provides exceptional signal fidelity with±0.1%accuracy and 100 kHz per-channel sampling across 8 independent inputs,capturing critical data from eddy current probes,accelerometers,and speed sensors.The companion output card delivers 8 channels of reliable 4-20mA analog signals and robust SPDT relay outputs(5A)for comprehensive alarm and shutdown functions.This high-density design maximizes rack space efficiency,reduces system complexity,and lowers lifecycle costs.Fully compliant with API 670 and designed for seamless integration within the VM600 rack,the Vibro-meter VM600 IOCN pair offers unmatched reliability and performance.It is the trusted choice for protecting multi-million dollar turbines,compressors,and generators in power,oil&gas,and petrochemical industries,providing the dense,accurate data acquisition and dependable actuation required for safe,efficient,and continuous operation.
