Application Scenarios

In a wide-area pipeline monitoring network stretching across hundreds of kilometers, sequence-of-events (SOE) recording becomes meaningless if the timestamps from different compressor stations cannot be correlated to a common time base. Each station’s ControlLogix chassis hosts a 1756HP-GPS module connected to a roof-mounted active antenna. When a pressure anomaly triggers alarms at three separate stations within a 200-millisecond window, the 1756HP-GPS modules at each site provide UTC timestamps accurate to the microsecond level, allowing the central SCADA system to reconstruct the exact propagation sequence of the event and determine whether the anomaly originated upstream or downstream. Without this satellite-disciplined time reference, the investigation would be reduced to guesswork based on unsynchronized local clocks .

For a utility grid substation where protective relays and merging units must align their sampled values within microseconds, the 1756HP-GPS serves as the local time master when the station‘s PTP grandmaster is unavailable or when the utility requires an independent, satellite-traceable time source that does not depend on the corporate IT network. The module’s holdover performance of 1 µs/s drift means that even if the antenna cable is damaged during a storm, the chassis maintains sufficient timing accuracy for several minutes while maintenance responds .
