Application Scenarios
Consider a packaging machine manufacturer that produces custom control panels for food processing lines. Each panel requires dozens of illuminated push buttons with varying functions—start, stop, reset, and mode selection—distributed across multiple machine sections. When a customer requests a change from momentary start buttons to maintained mode-select buttons two weeks before delivery, the production team faces a costly rework of pre-wired panels. With the 800X-ALP-800F-PB-22MM actuator head paired to the appropriate 800F contact block, the modification becomes a simple component swap: the actuator head disconnects from the front without disturbing panel wiring, and a different contact block is clicked into place from behind. What would have required three days of panel rewiring is completed in under an hour. This modularity directly addresses the pain point of late-stage design changes and field upgrades, where the cost of rework often exceeds the value of the switches themselves.
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | 800X-ALP-800F-PB-22MM |
| Manufacturer | Eaton (Cutler-Hammer) |
| Product Category | Illuminated Push Button Actuator Head |
| Compatibility | Eaton 800F series switch bodies only |
| Actuator Type | Flat push button (PB) |
| Mounting Diameter | 22 mm standard panel cutout |
| Illumination | Green LED integrated into actuator |
| LED Power Source | Supplied by 800F switch body via multi-pin connection |
| Lens Material | Translucent plastic with permanent legend capability |
| Protection Rating | IP65 or higher when properly installed |
| Mechanical Life | ≥ 1,000,000 operations |
| Operating Temperature | -25°C to +70°C |
| Certifications | cULus, CE |
Technical Principles and Innovative Values
Innovation Point 1: Tool-Free Actuator Replacement. The 800X-ALP-800F-PB-22MM uses a plug-in connection to the 800F switch body, allowing the actuator head to be removed from the panel front by hand after the locking ring is released. This design eliminates the need to access the rear of the panel for routine actuator replacement, reducing maintenance time from 15 minutes to under 2 minutes per switch in densely packed enclosures.
Innovation Point 2: Integrated LED with Body-Sourced Power. The green LED within the 800X-ALP-800F-PB-22MM derives its power from the 800F switch body through a dedicated pin connection, rather than requiring separate external wiring to the actuator head. This architecture simplifies panel wiring and ensures that LED status accurately reflects the contact state or control circuit condition as configured at the body level.
Innovation Point 3: Modular Separation of Function and Interface. The 800X-ALP-800F-PB-22MM embodies the 800F system’s core philosophy: the contact block handles electrical switching, while the actuator head handles human interaction. This separation allows a single actuator design to work with momentary, maintained, or multi-circuit contact blocks, and it enables field replacement of worn lenses or failed LEDs without touching the electrical connections.
Innovation Point 4: Permanent Legend Capability. The translucent button cap of the 800X-ALP-800F-PB-22MM accepts permanent marking through laser etching or molded legends, ensuring that labels remain legible after years of operation. This contrasts with adhesive labels that peel or fade in industrial environments, reducing the risk of operator error caused by ambiguous button identification.
