Product Overview

The Allen-Bradley 800X-ALP​ is a specialized accessory kit designed to provide clear, professional, and customizable labeling for 800F series 22mm pushbutton operators, specifically compatible with models like the 800F-PB22MM. This accessory is an integral part of building a well-organized and user-friendly human-machine interface (HMI) on control panels, machinery, and operator stations. The 800X-ALP​ kit typically includes a durable, transparent legend plate and a set of inserts that can be custom-engraved with text, symbols, or icons to indicate the specific function of the pushbutton, such as “START,” “STOP,” “RESET,” “JOG,” or machine-specific identifiers. The primary purpose of this accessory is to enhance operational safety, efficiency, and accuracy by eliminating guesswork for operators and maintenance personnel, ensuring that every control device is unambiguously identified according to its role in the machine or process.As part of Rockwell Automation’s comprehensive 800F line of pushbutton and signaling devices, the 800X-ALP​ legend plate kit follows a modular design philosophy. It is engineered to snap or mount securely onto the front of the 22mm pushbutton operator, seamlessly integrating with the device’s aesthetic and functional design. The kit transforms a generic pushbutton into a clearly marked, application-specific control point. The value of the Allen-Bradley 800X-ALP​ lies in its ability to provide a standardized, professional, and durable labeling solution that meets industrial safety standards (like those requiring clear identification of emergency stop and other critical functions) and improves overall panel clarity. In complex control panels with dozens of buttons, proper labeling facilitated by the 800X-ALP​ is not just a convenience; it is a critical component for preventing operator error, speeding up troubleshooting, and ensuring compliance with good manufacturing practices and safety regulations. It represents the finishing touch that bridges the gap between electrical functionality and human usability.

Technical Specifications

Main Features and Advantages

The Allen-Bradley 800X-ALP​ legend plate kit offers a simple yet highly effective solution for panel identification with several key advantages. Its foremost feature is the provision of a protected, professional labeling surface. The two-part design—a clear, rugged outer cover and a replaceable inner insert—ensures that the custom engraving is shielded from abrasion, chemicals, UV light, and general wear, maintaining legibility over the long service life of the equipment. This protection is crucial in industrial environments where controls are subject to frequent use, cleaning, and exposure to oils or coolants. The kit enables complete customization; the blank inserts can be engraved in-house using standard engraving equipment or by a panel shop to create any necessary text, acronym, or standard symbol (e.g., IEC/ISO symbols for start, stop, emergency), allowing for precise communication in multiple languages or for specialized functions.Ease of installation and future modification are significant benefits. The 800X-ALP​ is designed for tool-less attachment, snapping securely onto the front of the compatible 800F operator. This allows for labels to be added or changed in the field without disassembling the pushbutton or its wiring, facilitating panel updates, machine repurposing, or correction of legends. The standardized kit ensures a consistent, clean appearance across the entire control panel, contributing to a professional and organized look. This consistency improves the operator’s ability to quickly scan and locate controls, reducing reaction time in normal and emergency situations. By using the Allen-Bradley 800X-ALP, system integrators and panel builders can deliver a finished product that not only functions reliably but also provides an exceptional level of operational clarity and safety, directly contributing to reduced human error and enhanced overall equipment effectiveness (OEE).
