Description

The Allen‑Bradley 1794‑PS13 is a compact AC‑to‑DC power supply module from Rockwell Automation’s Bulletin 1794 FLEX™ I/O family, engineered to provide regulated 24V DC power to the communication adapter and I/O modules in a FLEX I/O system . With a wide‑range 85‑265V AC input and 1.3A output capacity, this module serves as the dedicated power source for small‑scale distributed I/O nodes, delivering 36 watts of reliable power to operate up to four adapter modules in a daisy‑chained configuration . Its rugged open‑style design and DIN‑rail mounting make it a practical solution for control cabinets in manufacturing, processing, and material handling applications.

Application Scenarios

In a food processing plant, maintenance engineers were struggling with intermittent communication faults on a remote FLEX I/O rack located 200 meters from the main control panel. The rack—equipped with a 1794‑AENT EtherNet/IP adapter and several discrete I/O modules—was powered by a third‑party 24V supply that lacked proper isolation and suffered from voltage sag during motor startups. After replacing the supply with a 1794‑PS13, the team achieved stable 24V DC output with clean, noise‑free power, eliminating the intermittent faults and reducing troubleshooting time by over 80%. The module’s wide input range allowed direct connection to the existing 220V AC supply without additional transformers . Whether deployed in packaging lines, conveyor systems, or remote valve banks, the 1794‑PS13 provides the dependable power foundation that keeps distributed I/O nodes operating without interruption.

Parameters

Technical Principles and Innovative Values

Innovation Point 1: High‑Frequency Switching Topology for Compact Power
The 1794‑PS13 employs a modern high‑frequency switching power supply design that delivers 36W of output power in a compact 69mm wide housing. This high‑density architecture eliminates the need for bulky linear transformers, saving valuable panel space and reducing heat dissipation compared to older power supply technologies. The module draws only 0.7A maximum input current while delivering 1.3A at 24V DC, achieving efficiency that keeps operating costs low .

Innovation Point 2: Wide‑Range Universal Input for Global Deployment
The module accepts 85‑265V AC input voltage without manual configuration or jumper settings, making the 1794‑PS13 suitable for deployment across facilities worldwide—from 120V AC North American systems to 230V AC European and Asian installations . This universal input eliminates the risk of voltage selection errors during installation and simplifies spare parts management across global operations.

Innovation Point 3: Comprehensive Protection for System Safety
The 1794‑PS13 incorporates multiple protection mechanisms to safeguard connected equipment. Overvoltage protection shuts down the output if voltage exceeds approximately 35V DC, preventing damage to sensitive I/O modules . Overcurrent protection limits current to approximately 1.4A, protecting both the power supply and downstream devices from short‑circuit conditions . The 2500V DC isolation between input and output ensures that AC line transients do not propagate to the sensitive 24V DC logic circuits, reducing the risk of communication errors and module damage .

Innovation Point 4: Daisy‑Chain Wiring for Efficient Distribution
The 1794‑PS13 features a unique terminal arrangement that allows 120/230V AC power to be daisy‑chained to adjacent power supplies via terminals D, E, and F . This reduces wiring complexity in multi‑node installations, eliminating the need for separate branch circuits for each power supply and simplifying panel layout.

Innovation Point 5: Hazardous Location Certification for Versatile Deployment
The 1794‑PS13 carries Class I, Division 2, Groups A, B, C, D certification for use in hazardous locations, making it suitable for oil & gas, chemical, and other industries where flammable gases or vapors may be present . This certification expands the module’s applicability beyond standard industrial environments, reducing the need for separate hazardous‑area power solutions.

Application Cases and Industry Value

Case Study: Water Treatment Plant Remote I/O Upgrade (Midwest USA, 2023)

A municipal water treatment facility expanded its monitoring capabilities by adding four remote FLEX I/O nodes across its sedimentation and filtration buildings. Each node required a 1794‑AENT EtherNet/IP adapter and six discrete I/O modules for valve position feedback and pump status monitoring. The engineering team selected the 1794‑PS13 for each node based on its 1.3A capacity (sufficient for four adapter modules) and universal input compatibility .

Installation was completed in two days, with the DIN‑rail mounting and daisy‑chain wiring significantly reducing panel assembly time . Over 14 months of continuous operation, all four power supplies maintained stable output voltage within ±5% tolerance, with zero failures reported. The facility’s maintenance supervisor noted that the green LED status indicator provided instant visual confirmation of normal operation, simplifying routine inspections .

Industry Value Impact:
For system integrators and plant engineers, the 1794‑PS13 delivers immediate value through its compact footprint, universal input compatibility, and reliable 1.3A output for small‑scale distributed I/O nodes. Its hazardous location approval and robust protection features make it suitable for demanding industrial environments. As a core component of the FLEX I/O ecosystem, this power module ensures that communication adapters and I/O modules receive clean, regulated power—a critical factor for maintaining network reliability and reducing unplanned downtime.
