Product Overview

The Allen-Bradley 22B-D010N104​ is a PowerFlex 40 family AC drive (variable frequency drive) manufactured by Rockwell Automation, engineered as a compact, cost-effective motor control solution for 480V-class three-phase induction motors up to 4 kW (5 HP). As a core member of the PowerFlex 40 platform, the Allen-Bradley 22B-D010N104​ accepts 380–480V AC three-phase input at 50/60Hz and delivers 10A continuous output current (10.5A nameplate rating) with an output frequency range of 0–400Hz, making it ideally suited for pumps, fans, conveyors, mixers, and general-purpose machine drive applications across manufacturing and process industries. The Allen-Bradley 22B-D010N104​ combines performance-enhancing motor control with an easy-to-use compact package, embodying the PowerFlex 40 philosophy of simple installation, flexible configuration, and reliable day-to-day operation.The Allen-Bradley 22B-D010N104​ features a Frame B form factor measuring just 180 × 100 × 136mm (7.09 × 3.94 × 5.35 inches), panel-mounted with IP20 / NEMA UL Type Open enclosure rating for installation inside control cabinets. An integral LED display and digital keypad enable local programming, monitoring, and control without requiring additional operator interfaces. Control capabilities include both V/Hz and sensorless vector control modes, delivering high starting torque and excellent speed regulation across a wide speed range, with auto-boost and slip compensation for improved performance under varying load conditions. The built-in RS485 (DSI) communication port facilitates seamless networking with PLCs, HMIs, and PC configuration tools. A dynamic brake IGBT (with external resistor) supports fast deceleration of high-inertia loads, while integrated process PID enables direct closed-loop control of flow, pressure, and temperature without an external controller.It is important to note that Rockwell Automation has officially declared the Allen-Bradley 22B-D010N104​ as End-of-Life, with sales discontinuing as of June 30, 2025, and the engineering replacement product designated as the 25B-D010N104. However, the Allen-Bradley 22B-D010N104​ remains a critically important spare part for the thousands of installed PowerFlex 40 systems operating reliably in plants worldwide. With a power factor of 0.98, operational efficiency up to 97.5%, and Zero Stacking capability for side-by-side mounting at ambient temperatures up to 40°C, the Allen-Bradley 22B-D010N104​ continues to deliver exceptional value as a replacement unit, ensuring production continuity without the capital expenditure and engineering effort required for immediate platform migration. Every Allen-Bradley 22B-D010N104​ supplied is thoroughly tested and backed by a 1-year standard warranty, guaranteeing performance to original factory specifications.

Technical Specifications
