Product Overview
The ORIENTAL MOTOR 4IK60A-BF-E10 is a high-performance 60W induction motor with integrated parallel shaft gearhead and electromagnetic brake, engineered by Oriental Motor as part of the renowned K Series product family. This 4IK60A-BF-E10 is specifically designed for unidirectional continuous operation applications such as conveyor systems, packaging machinery, and material handling equipment where reliable, quiet, and safe operation is essential .
As a “three-in-one” integrated solution, the ORIENTAL MOTOR 4IK60A-BF-E10 combines a 60W three-phase induction motor, a 10:1 ratio parallel shaft gearhead, and an electromagnetic brake in a single factory-aligned assembly. The “BF” designation in the model indicates the inclusion of an electromagnetic brake (Electromagnetic Brake) that engages on power loss, while “E10” signifies the 10:1 gear reduction ratio . This integrated design eliminates the need for customers to perform separate assembly and alignment, reducing installation errors and potential failure points.
The ORIENTAL MOTOR 4IK60A-BF-E10 features a compact 80mm frame size (mounting dimensions based on the 60A frame code) and is rated for continuous S1 duty operation . Its IP55 protection class provides robust resistance against dust ingress and water jets, making it suitable for demanding industrial environments. With F-class insulation, the ORIENTAL MOTOR 4IK60A-BF-E10 can operate reliably in ambient temperatures up to 40°C while delivering stable torque output. This motor exemplifies Oriental Motor’s commitment to precision engineering and quality, offering OEMs and end-users a maintenance-free, plug-and-play drive solution that keeps production moving safely and silently.
Technical Specifications
| Parameter Name | Value |
|---|---|
| Product Model | 4IK60A-BF-E10 |
| Manufacturer | ORIENTAL MOTOR Co., Ltd. |
| Product Type | Three-Phase Induction Motor with Parallel Shaft Gearhead and Electromagnetic Brake |
| Series | K Series / World K Series |
| Rated Output Power | 60 W |
| Supply Voltage | Three-Phase 200 VAC ±10% |
| Rated Frequency | 50/60 Hz |
| Rated Motor Speed | 1500 rpm (50 Hz) / 1800 rpm (60 Hz) |
| Gear Ratio | 10:1 (E10 designation) |
| Output Shaft Speed | 150 rpm (50 Hz) / 180 rpm (60 Hz) |
| Electromagnetic Brake Type | Power-off Brake (Fail-Safe, engages on power loss) |
| Brake Holding Torque | ≥0.49 N·m |
| Protection Class | IP55 (IEC 60529) |
| Insulation Class | Class F (155°C) |
| Cooling Method | Self-Cooling (IC 410) |
| Duty Rating | S1 (Continuous Operation) |
| Noise Level | <55 dB(A) at 1 meter |
| Bearing Type | Maintenance-Free, Lifetime Lubricated |
| Mounting Type | Foot Mounting (with mounting holes) |
| Dimensions | Approx. 6.2 cm × 38.6 cm × 17.3 cm |
| Weight | Approx. 2.62 kg |
Main Features and Advantages
Integrated “Three-in-One” Design
The ORIENTAL MOTOR 4IK60A-BF-E10 offers a fully integrated motor, gearhead, and brake assembly that is factory-aligned for optimal performance. This integration eliminates the need for customers to source and assemble separate components, reducing engineering time, installation complexity, and potential alignment errors. The ORIENTAL MOTOR 4IK60A-BF-E10 is delivered as a complete, ready-to-install unit, simplifying both new equipment builds and field replacements.
Fail-Safe Electromagnetic Brake
The electromagnetic brake is a defining feature of the ORIENTAL MOTOR 4IK60A-BF-E10. It operates on a fail-safe principle: the brake is released when power is applied and engages automatically on power loss or emergency stop . This makes the ORIENTAL MOTOR 4IK60A-BF-E10 ideal for vertical lifting applications, conveyors on inclines, and any system where load holding is critical for safety. The brake responds within 0.02 seconds, providing instant stopping and preventing load drift during power outages. The brake mechanism is designed for a long operational life with millions of cycles and features automatic gap compensation to maintain consistent holding torque without manual adjustment .
Quiet and Durable Operation
The gearhead of the ORIENTAL MOTOR 4IK60A-BF-E10 utilizes helical gears with hardened and ground teeth (HRC58+), ensuring smooth meshing, minimal backlash (typically <30 arcmin), and exceptional wear resistance. This precision gear design contributes to the unit’s ultra-quiet operation, with noise levels below 55 dB(A)—comparable to a quiet conversation. The gearhead’s parallel shaft configuration provides high torque transmission efficiency while maintaining a compact footprint. Combined with the F-class insulation and self-cooling design, the ORIENTAL MOTOR 4IK60A-BF-E10 delivers reliable, maintenance-free performance even in 40°C ambient temperature environments.
