ALTOM Pressure Switch 029.063 242 – Industrial Control Device
Product Overview
TheALTOM 029.063 242represents a precision mechanical pressure switch designed for industrial process control and equipment protection applications.This robust electromechanical device serves as a critical safety and control component in various systems,providing reliable switching action based on preset pressure thresholds.TheALTOM 029.063 242incorporates high-quality materials and precision engineering,ensuring accurate pressure sensing and consistent switching performance in demanding industrial environments.With its durable construction and reliable operation,this pressure switch provides dependable performance for both hydraulic and pneumatic systems where precise pressure monitoring is essential.
As part of ALTOM’s comprehensive pressure control portfolio,theALTOM 029.063 242demonstrates exceptional reliability through its robust sensing element and precision switching mechanism.The switch’s designed construction ensures consistent operation across numerous cycles,while the adjustable set point feature allows for customization to specific application requirements.TheALTOM 029.063 242is engineered for straightforward installation and maintenance,featuring standardized connection interfaces and clear adjustment markings that simplify setup and calibration procedures.This makes theALTOM 029.063 242an ideal choice for industrial applications requiring reliable pressure monitoring and control functionality.
Technical Specifications
Parameter Name Parameter Value
Product Model029.063 242
Manufacturer ALTOM
Product Type Mechanical Pressure Switch
Pressure Range 0-400 bar(adjustable)
Set Point Accuracy±2%of full scale
Electrical Rating 10A 250V AC
Switch Type SPDT(Single Pole Double Throw)
Connection Size G1/4″female
Pressure Port Brass
Housing Material Die-cast aluminum
Operating Temperature-40°C to+80°C
Ingress Protection IP54
Contact Material Silver alloy
Weight 0.35kg
Certification CE,UL
Main Features and Advantages
TheALTOM 029.063 242offers exceptional pressure sensing accuracy with its±2%full scale accuracy rating,ensuring reliable switching at precisely the required pressure points.The switch’s robust brass pressure port and high-quality sensing element provide excellent resistance to pressure spikes and cycling fatigue.The029.063 242features a SPDT switching configuration that offers flexibility for both normally open and normally closed circuit applications,making it suitable for various control and safety functions.The adjustable set point mechanism allows for precise calibration to meet specific application requirements,while the clear scale markings facilitate accurate setup.
Durability and reliability are central to theALTOM 029.063 242design,featuring a die-cast aluminum housing that provides excellent protection against environmental factors and mechanical damage.The IP54 protection rating ensures resistance to dust and water splashes,making the switch suitable for use in challenging industrial environments.The silver alloy contacts provide excellent electrical conductivity and resistance to welding,ensuring long electrical life even under frequent switching conditions.These characteristics make theALTOM 029.063 242a dependable solution for critical pressure monitoring applications across various industries.
Application Field
TheALTOM 029.063 242finds extensive application in industrial hydraulic systems,where it provides pressure monitoring and control for pumps,cylinders,and actuators.The switch’s 400-bar range makes it suitable for high-pressure applications in manufacturing equipment,press machines,and material handling systems.In pneumatic control systems,the029.063 242is used for compressor control,pressure regulation,and system protection functions across various industrial applications.
The switch serves important roles in mobile equipment and machinery,providing pressure sensing for hydraulic circuits in construction and agricultural equipment.TheALTOM 029.063 242is also employed in process industries including water treatment,chemical processing,and energy production where reliable pressure monitoring is essential for system safety and efficiency.Its robust design and reliable performance make it suitable for OEM applications across various sectors requiring dependable pressure sensing solutions.
Related Products
ALTOM pressure gauges:Complementary pressure measurement devices
ALTOM flow switches:Fluid flow monitoring and control devices
ALTOM temperature switches:Thermal monitoring and control units
ALTOM electronic sensors:Advanced sensing solutions
ALTOM mounting accessories:Installation and mounting hardware
Installation and Maintenance
Pre-installation preparation:Before installing theALTOM 029.063 242,verify the pressure range matches application requirements and ensure proper connection fittings are available.Check the switch for any visible damage and confirm electrical specifications match the control circuit requirements.
Maintenance recommendations:Regular maintenance of the029.063 242should include inspection of electrical connections and pressure port integrity.Verify set point calibration periodically and check for signs of leakage or damage.Keep the adjustment mechanism clean and protected from environmental contaminants.
Product Guarantee
We guarantee that everyALTOM 029.063 242pressure switch is genuine ALTOM product,sourced through authorized channels,and meets original equipment specifications.Our technical support team provides comprehensive assistance for product selection and application guidance.We are committed to delivering original pressure control components that ensure optimal performance and reliability in your industrial applications.
