BENTLY 3500/01-03-00-00
BENTLY 3500/01-03-00-00 Product Introduction
summary:
BENTLY 3500/05-01-03-00-00 is the core framework of an industrial grade mechanical condition monitoring system launched by Bently Nevada Corporation,designed for real-time monitoring and protection of vibration,displacement,speed and other parameters of rotating machinery such as turbines,compressors,motors,etc.This framework adopts a modular architecture,supports multiple types of sensor access and data processing,and is widely used in key equipment safety monitoring in the fields of power,petrochemicals,metallurgy,etc.It meets the requirements of API 670 standard.
Main features and advantages:
Modular architecture and high scalability:
The framework supports two specifications:full-size(19 inches,14 slots)and mini(12 inches,7 slots),compatible with flexible configuration of modules such as power supplies,interfaces,monitors,relays,etc.,meeting the expansion needs from small to complex systems.
Industrial grade stability and reliability:
Adopting anti electromagnetic interference design,suitable for a wide temperature range of-40℃to 70℃,supporting redundant power supply configuration,ensuring long-term stable operation.When applied in hazardous areas,internal safety barrier modules(such as 3500/04)can be integrated to meet intrinsic safety requirements.
Multi sensor compatibility:
Support eddy current sensors(3300XL series),speed sensors,accelerometers,etc.,covering key parameter measurements such as shaft vibration,shaft displacement,differential expansion,and speed,compatible with dynamic and static signal processing.
Intelligent monitoring and alarm:
By configuring the alarm threshold through the configuration software(System1),it supports functions such as delayed alarm and locked alarm,which can trigger relay output or linkage control system shutdown to ensure equipment safety.
Technical specifications:
Parameter description
Brand Bently Nevada
Model 3500/05-01-03-00-00-00
Structural form full-size/mini rack
Number of slots:14 full-size and 7 mini slots
The power supply supports 24V DC/AC redundant power supply
Compatible with module types such as power supply,interface,monitor,relay,etc
Communication interface Modbus,Ethernet
Environmental adaptability IP65 protection,vibration/corrosion resistance
Certification standards API 670,CE,ATEX
Application areas:
Power industry:shaft vibration,displacement monitoring and protection of steam turbines and generators.
Petrochemicals and Metallurgy:Real time analysis of the operating status of compressors,pumps,and gearboxes.
Mechanical manufacturing:fault warning and life prediction of motors and fans.
Dangerous area:Integrated with safety barrier modules,suitable for flammable and explosive environments.
Related products:
Bently 3500/15 power module:Provides power to the framework and supports hot swappable redundant configuration to ensure uninterrupted system operation.
Bently 3500/42M Monitor:Four channel vibration/displacement monitoring module,used in conjunction with 3500/05-01-03-00-00 to achieve dynamic signal processing and alarm triggering.
Bently 3500/33 relay module:16 channel relay output,used for interlocking control of alarm signals to improve system response speed.
