SBS VME-IP-CARRIER VIPC616 91611524 Product Introduction

Product model: SBS VME-IP-CARRIER VIPC616 91611524

Brand: SBS

Manufacturer: SBS

Series: Control System

product overview

SBS VME-IP-CARRIER VIPC616 91611524 is a high-performance industrial carrier module designed specifically for carrying and connecting various industrial equipment. This module complies with VMEbus specification C1 (compatible with IEEE P1014/D1.2 and IEC 821 bus), adopts a 6U “double height” form factor, provides reliable mechanical support and electrical interfaces, and is suitable for automation control and system integration in harsh industrial environments. Its modular design ensures flexible system expansion, compatibility with multiple industry standard buses, and meets the requirements of complex industrial application scenarios.

Main features and advantages:

High performance electrical interface: supports I/O, ID, memory, and interrupt cycle functions, and achieves efficient data exchange through four sockets on the 6U board.

Flexible compatibility: Compatible with the IndustriePack logical interface specification, supporting 4 single width or 2 double width industrial modules (slots A, B, C, D), suitable for various IndustriePack devices.

Stable connection design:

The front panel I/O adopts unshielded right angle ribbon connectors, paired with 50 pin flat cables to ensure stable signal transmission.

Each slot is equipped with an active LED and power display to monitor the operating status in real-time.

Customized interrupt management: Supports PLD programming to customize IRQ mapping, pairing with VMEbus’s 7-level interrupt requests through jumper blocks, and flexibly adapting to different system requirements.

Anti interference and durability:

The six layer PCB structure reduces electromagnetic interference (EMI), and the CMOS logic design reduces thermal and electrical noise.

Gold plated splitters, sockets, and pins enhance long-term reliability and adapt to industrial grade environments.

Intelligent power management: integrating filtering and integrating power rails to ensure power supply stability and optimize system energy efficiency.

technical specifications

Parameter specifications

Shape factor 6U (double height)

Number of slots: 4 single width or 2 double width Industry Pack slots (A/B/C/D)

Electrical interface VMEbus P2 backplane connector+front panel 50 pin ribbon cable

Support functions I/O, ID, memory, interrupt cycle

Interrupt configuration with 8 interrupt request lines, supporting 7-level VMEbus interrupts, programmable PLD mapping

Power requirements: Filter and fuse power rails, support DC 5V~35V power supply

Environmental adaptability: Operating temperature range of -25 ℃ to+85 ℃, humidity of 95%, no condensation, anti vibration design

The physical dimensions comply with the Eurocard standard 6U size (height x width: 233mm x 160mm)

Connection characteristics: Locking right angle socket, snap in installation, supporting hot plugging

Logical compatibility complies with VMEbus specification C1 and IndustriePack interface specification

application area

Manufacturing automation: integrated into production line control systems to achieve real-time monitoring and precise control of equipment.

Industrial process control: a distributed control system suitable for energy, chemical and other fields, ensuring the coordinated operation of multiple devices.

Transportation and Infrastructure: Support data collection and command transmission for rail transit and intelligent logistics systems.

Testing and Measurement Equipment: As the core carrier module, it is applied to high-precision industrial testing instruments.

SBS VME-IP-CARRIER VIPC616 91611524产品简介

产品型号：SBS VME-IP-CARRIER VIPC616 91611524

品牌：SBS

制造商：SBS

系列：控制系统

产品概述

SBS VME-IP-CARRIER VIPC616 91611524是一款高性能工业载体模块，专为承载和连接各类工业设备而设计。该模块符合VMEbus规范C.1（兼容IEEE P1014/D1.2与IEC 821总线），采用6U“双高”形状因子，提供可靠的机械支撑与电气接口，适用于严苛工业环境中的自动化控制与系统集成。其模块化设计确保系统扩展灵活，兼容多种行业标准总线，满足复杂工业应用场景需求。

主要特点和优势：

高性能电气接口：支持I/O、ID、内存和中断周期功能，通过6U板上的4个插孔实现高效数据交互。

灵活兼容性：兼容IndustryPack逻辑接口规范，支持4个单宽或2个双宽工业模块（插槽A、B、C、D），适配多种IndustryPack设备。

稳定连接设计：

前面板I/O采用无屏蔽直角丝带连接器，搭配50针扁平电缆，确保信号传输稳定。

每个插槽配备活动发光二极管与电源显示器，实时监控运行状态。

定制化中断管理：支持PLD编程定制IRQ映射，通过跳线块与VMEbus的7级中断请求配对，灵活适配不同系统需求。

抗干扰与耐用性：

六层PCB结构降低电磁干扰（EMI），CMOS逻辑设计减少热噪与电噪。

镀金分流器、插座及引脚提升长期可靠性，适应工业级环境。

智能电源管理：集成过滤与融合电力轨，保障供电稳定性，优化系统能效。

技术规格

参数规格

形状因子6U（双高）

插槽数量4个单宽或2个双宽IndustryPack插槽（A/B/C/D）

电气接口VMEbus P2背板连接器+前面板50针丝带电缆

支持功能I/O、ID、内存、中断周期

中断配置8条中断请求线，支持7级VMEbus中断，可PLD编程映射

电源要求过滤与融合电力轨，支持DC 5V～35V供电

环境适应性工作温度-25℃至+85℃，湿度95%无凝结，抗振动设计

物理尺寸符合Eurocard标准6U尺寸（高×宽：233mm×160mm）

连接特性锁定直角插座、卡入式安装，支持热插拔

逻辑兼容性符合VMEbus规范C.1及IndustryPack接口规范

应用领域

制造业自动化：集成于生产线控制系统，实现设备实时监控与精准控制。

工业过程控制：适用于能源、化工等领域的分布式控制系统，确保多设备协同运行。

交通与基础设施：支持轨道交通、智能物流系统的数据采集与指令传输。

测试与测量设备：作为核心载体模块，应用于高精度工业测试仪器。
