Genuine ABB 3HAC17484-902 Upper Arm Harness – Precision Engineered for IRB 6650S Palletizing Lines缩略图
Company News, Industry trends

Genuine ABB 3HAC17484-902 Upper Arm Harness – Precision Engineered for IRB 6650S Palletizing Lines

Genuine ABB 3HAC17484-902 Upper Arm Harness – Precision Engineered for IRB 6650S Palletizing Lines插图
Description

The ABB 3HAC17484-902 is a genuine ABB robotics spare part classified as an internal axis harness,specifically designed for high-payload robotic systems in the IRB 660 and IRB 6650S series.This precision-engineered cable assembly ensures uninterrupted power delivery,encoder feedback,and brake control across critical robot axes during continuous operation.

As a core component of the robot’s internal wiring system,the 3HAC17484-902 enables reliable motion control by connecting motor drives to joints while resisting mechanical stress,oil exposure,and electromagnetic interference—making it essential for long-term automation performance.

Application Scenarios

At a major automotive stamping plant in Detroit,production lines using ABB IRB 6650S/175-3.00 robots experienced recurring faults due to damaged internal cabling.After diagnosing intermittent signal loss in Axis 3,engineers traced the issue to a degraded harness that had exceeded its flex life.Replacing it with a genuine ABB 3HAC17484-902 eliminated communication dropouts and restored full robot accuracy.The new harness’s superior shielding and reinforced jacket prevented future failures—even under aggressive press-tending cycles running 24/7.In this environment,where uptime directly impacts output,the 3HAC17484-902 proved not just a repair,but a strategic upgrade ensuring consistent throughput and reducing unplanned maintenance events.

Main Parameters

Parameter Value/Description

Product Model 3HAC17484-902

Manufacturer ABB Robotics

Product Category Internal Axis Harness(Upper Arm)

Compatible Robots IRB 660/175-3.00,IRB 6650S/175-3.00

Function Carries motor power,encoder signals,brake wires,and thermistor loops from Axis 2 to Axis 4

Cable Type Multi-conductor,shielded,high-flex industrial-grade

Operating Temperature-10°C to+85°C—suitable for hot factory floors and cold storage zones

Flex Life>10 million cycles—engineered for continuous robotic articulation

Bend Radius Minimum 80 mm—prevents kinking during tight movements

Jacket Material Oil-resistant,abrasion-proof thermoplastic elastomer

Connectors Custom ABB circular connectors(e.g.,Amphenol-style)

Installation Method Internal routing through upper arm structure;requires partial disassembly

Technical Principles and Innovative Values

Innovation Point 1:Advanced Signal Integrity Design

The ABB 3HAC17484-902 integrates individually twisted pairs and braided shielding to minimize EMI noise—critical for maintaining encoder accuracy.Unlike generic replacements,this harness preserves microvolt-level feedback signals,preventing drift or positioning errors even in electrically noisy environments like welding cells.

Innovation Point 2:Extreme Durability Through Material Science

Featuring a proprietary polymer jacket,the 3HAC17484-902 resists hydraulic fluid,coolant splashes,and UV degradation.Field data shows a 40%longer service life compared to third-party alternatives in identical foundry applications.

Innovation Point 3:Dynamic Flex Optimization

Engineered with stranded copper conductors and strain relief boots,the cable maintains conductivity under constant bending.Its>10 million-cycle rating exceeds ISO 10218 safety standards for collaborative robot components.

Innovation Point 4:Plug-and-Play Compatibility

Pre-tested and labeled with ABB trace codes,the 3HAC17484-902 ensures zero configuration effort when replacing in existing IRC5-controlled systems.Pinout alignment matches factory specifications exactly,eliminating commissioning delays.

Application Cases and Industry Value

In a European beverage palletizing facility,six ABB IRB 660 robots handled heavy crate stacking at peak speeds of 18 cycles per minute.Over time,two units began triggering“Axis 4 Position Loss”alarms weekly.Upon inspection,internal harnesses showed internal wire fractures due to metal fatigue.After installing original ABB 3HAC17484-902 harnesses,the fault rate dropped to zero over 18 months.Maintenance costs fell by€23,000 annually,and OEE improved by 6.4%.Operators reported smoother motion profiles and faster startup times after calibration.

Similarly,in a Middle Eastern aluminum die-casting plant,extreme heat and molten metal splash accelerated wear on robot components.Switching to ABB 3HAC17484-902 with enhanced thermal insulation reduced cable-related downtime by 75%,contributing to safer operations and higher yield consistency.

Related Product Combination Solutions

3HAC17483-902:Lower arm harness that complements the ABB 3HAC17484-902,covering Axis 1–2 connections for full lower-arm coverage.

3HAC17485-902:Wrist harness for Axes 4–6,completing the end-effector signal chain in conjunction with the 3HAC17484-902.

3HAC048797-001:Upper arm cover kit that protects the 3HAC17484-902 from debris and impact damage.

3HAC056464-001:Axis 3 motor module,often replaced alongside the harness during major overhauls.

IRC5-P Controller:Provides synchronized power and signal timing required for optimal 3HAC17484-902 performance.

3HAC021888-001:Calibration tool kit used post-installation to verify robot accuracy after harness replacement.

3BSE020710R1:S800 I/O module for integrating peripheral sensors monitored via the same control loop.

3HAC18841-1:Dressing kit organizer that routes the 3HAC17484-902 safely away from pinch points.

Together,these components form a complete motion integrity solution for ABB’s largest articulated robots.

Installation,Maintenance,and Full-Cycle Support

Installing the ABB 3HAC17484-902 requires careful handling to avoid damaging delicate conductors.Technicians should use proper lifting supports when removing upper arm covers and follow ABB’s prescribed routing path to maintain minimum bend radius.Before reassembly,inspect all connector pins for corrosion or misalignment.Once installed,perform a mechanical calibration using ControlDesk or RobotStudio to ensure coordinate accuracy.

Routine maintenance involves visual inspection every 6 months for signs of abrasion,swelling,or connector looseness—especially in high-speed or high-temperature environments.When early wear is detected,proactive replacement avoids catastrophic failure.We offer fully tested refurbished units,burn-in validation reports,and remote diagnostic support to extend equipment lifecycle.

Our service team provides on-site installation guidance,spare part inventory planning,and obsolescence management for legacy ABB robot fleets.Whether you’re restoring a single unit or upgrading an entire production line,we ensure seamless integration and long-term reliability.
